(Manufactory) Free sample high gain car navigation GPS/bike gps locator antenna

FOB Reference Price:Get Latest Price
US $2-8 / Pieces | 20 Piece/Pieces GPS GSM Antenna (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Type:
Gps Antenna
Use:
Automotive
Screen Size:
GPS GSM Antenna
Function:
gps antenna
Place of Origin:
Zhejiang, China (Mainland)
Brand Name:
JIASHAN JINCHANG
Model Number:
JCB057
Warranty:
1 Years
Size:
59X52X15mm
Cable:
RG174 3m/5m or others
Connector:
SMB or others
Mounting:
Magnet/Adhesive
Cable Length:
car gps antenna
Gain(dB):
28
Frequence Range:
1575.42
Car Make:
all
V.S.W.R(min):
<2.5
Mechanical Cable:
RG174
SupplyAbility
SupplyAbility:
10000 Piece/Pieces per Day GPS GSM Antenna
Packaging & Delivery
Packaging Details
70*32*15.5CM
Port
SHANGHAI
Lead Time :
5-7 days

  BACK TO HOME  ≥≥≥



(Manufactory) Free sample high gain car navigation GPS/bike gps locator





JCB057



ItemSpecifications
GPS AntennaDielectric
 Antenna
Center Frequency1575.42±1MHz
Band WidthCF±5MHz
PolarizationRHCP
Gain2dBic(Zenith)
V.S.W.R<1.5
Impendance50Ω
Axial Ratio3dB(max)
LNAGain28±2dB
Noise Figure<1.5
Ex-band Attenuation12dB@CF+50MHz/16dB@CF-50MHz
V.S.W.R<2.0
Supply Voltage2.2~5V DC
Current Consumption5~15mA
GSM AntennaFrequency Range824~960MHz/1710~2170MHz
V.S.W.R(min)<2.5
PolarizationLinear
Gain2dBi
Impendance50Ω
MechanicalCableRG174
ConnectorSMA/MCX/FAKRA or others
Radome MaterialABS
Mounting MethodMagnet/Adhesive
EnvironmentalOperating Temperature-40℃~+85℃
Relative HumidityUp to 95%
Ingress ProtectionIP65~IP66
Vibration10 to 55Hz with 1.5mm amplitude 2hours
Environmentally FriendlyROHS Compliant





Q: Are you a manufacturer or a trading company?

A: We have been professional antenna manufacturer for 20 years.



Q: Can I get one sample?

A: Yes, sample is for free.



Q: Have gps gsm combo antenna 100% assembles well in stock?

A: No, all gps gsm combo antenna will be newly assembled according to your orders including the samples.



Q: What's the delivery time?

A: 1-4 days for the sample, 5-10 days for quantity below 5K, 10-30 days for the quantity below 20K.



Q: Could I use my own LOGO or design on goods?

A: Yes, customized logo and design on mass production are available.



Q: What's the payment term?

A: T/T, Paypal, western union etc.



Q: Where is your factory located? Can I visit your factory?

A: Factory address: #398 Zhenye Road, Jiaxing Economic Development Zone, Nanhu District, China. Just call us, we will pick you up with no delay.



Q: How long of the warraty?

A: One year and can repair for the whole life.
