0.1-2L Double Rotating Flask New Condition Rotary Thin Film Evaporator With High Precision

Feedback Ratings
US $1235.00 / Set | 1 Set (Min. Order)
Model Number:
RE-2000A
US $1235.0
- +
available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
5 day(s) after payment received
Contact Supplier
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Automatic Grade:
Automatic
Type:
Reaction Kettle
Place of Origin:
Shaanxi, China (Mainland)
Brand Name:
TOPTION
Voltage:
220V/50HZ
Power(W):
1.5kw
Dimension(L*W*H):
66*42*83cm
Weight:
45KGS
Certification:
CE ISO
Warranty:
1 Year
After-sales Service Provided:
Engineers available to service machinery overseas
Rotating Flask(L):
2L+1L
Optional Rotating Flask(L):
0.1L,0.25L,0.5L
Receiving Flask(L):
1L
Lifting Type:
Automatic lifting
Condenser:
Vertical
Rotation Speed(rpm):
20-200
Reachable Vacuum Rate:
0.098Mpa
Bath Power(kw):
1.5kw
Staic Temp. Control Range & Wave(℃):
RT-99±2
Power:
220V, 50/60Hz

Packaging & Delivery

Selling Units:
Single item
Single package size:
76X70X57 cm
Single gross weight:
45.0 KG
Package Type:
packing with standard wooden box
Lead Time :
Quantity(Set) 1 - 1 >1
Est. Time(day) 5 To be negotiated
Product Description

0.1-2L Double Rotating Flask New Condition Rotary Thin Film Evaporator With High Precision

Rotary evaporator is mainly used for pharmaceutical, chemical and bio−pharmaceutical industry concentration, crystallization, drying, separation and dissolution of coal recovery. The principle is: in a vacuum condition, constant temperature heating, to rotate bottles constant rotation, the material in the sidewall formation of large area thin film, high evaporation. Solubilization by high glass condenser vapor cooling, recovery in the collection bottle, greatly improve the efficiency of evaporation, particularly easy to use in high−temperature decomposition of the variability of biological products was concentrated and purified.

• A quick comparison between different models:

Technical Specification
Model
RE-2000A
RE-52AA
Rotating Flask(L)
2L+1L
0.5L
Optional Rotating Flask(L)
0.1L,0.25L,0.5L
0.1L,0.25L,1L or 2L
Receiving Flask(L)
1L
0.5L
Lifting Type
Automatic lifting
Automatic lifting
Condenser
Vertical
Vertical
Rotation Speed(rpm)
20-200
0-150
Reachable Vacuum Rate
0.098Mpa(SHB-III Vacuum Pump)
Bath Power(kw)
1.5kw
1.1kw
Staic Temp. Control Range & Wave(℃)
RT-99±2
RT-99±2
Power
220V, 50/60Hz
220V, 50/60Hz

* The voltage and power can be customized.

Key feature

1. High evaporation, high recovery, conversion and use of advanced electronic speed control to ensure stable operation of the motor;
2. Bath list the pot, reduce breakage, evaporation of low boiling point, the collection bottles can be immersed in an ice bath to reduce the secondary evaporation;
3. Collection bottle milling port connection, can be easily removable, sealing the fine;
4. High temperature long- lasting sealing, dynamic sealing system to ensure high temperature corrosion resistance and long list, particularly good air tightness
5. Japanese technology AC induction motor, variable speed, no brush no spark, can work effectively for a long time.
6. Chassis, bath pot, main bar, stainless steel shaft made of high quality, attractive appearance corrosion;
7. Intelligent temperature control, water and oil bath dual-use, more widely used. Temperature fluctuation is only 0.2 degree, evaporation is more stable, not easily washed material;
8. Whole series modular design, scalability, easy instabllation and maintenance;
9. According to user needs, electrical part can be produced with explosion-proof configuration

Detailed Images
Packing & Delivery

Packaging and Shipping

-The main parts will be wrapped with foam,then put into the carton; the mainbody portion will be packed in wooden cases
-Both neutral and customized packaging can be available
-We can ship the goods to you by International Express such as DHL,UPS,TNT,EMS and so on, you can also choose the appropriate one based on your timeline and budget. Besides,you can choose to use your own shipping agent

Certifications

TOPTION as a professional lab solution provider is specialized in manufacturing and selling photochemical glass reactor ,UV glass reactor system, xenon glass reactor, single-layer glass reactor,double-layer glass reactor, three-layer glass reactor,thermostatic equipment, ice maker, ultrasonic instrument, spray dryer, air dryer,extracting device and so on, who are work in chemistry, biology, pharmaceutical, environment analysis, food, academic research, etc. Regardless of the field you work in, we keep striving for the same goal: to provide you with the most suitable solutions & products, to make your research more accurate & efficient.

TOPTION has passed the “ISO9001:2008 Quality Management System”certification and most of our products have passed CE certification,the quality can be assured.

Our Service

Pre-Sales Service

1.Inquiry and consulting support
2.Quick response with detailed quotation
3.Confirm price, quantity, shipment, lead time and payment terms
4.Make order and sealed PI. (Trade assuranceorder is recommend to new clients for securing payment)

After-Sales Service

1.One year warranty for the products described here.
2.Beyond the warranty period, product problems can also be solved by our company, but charge component cost and maintenance cost properly.
3.Reliable quality and thoughtful after-sale service:If you encounter problems when using our products,please contact us by telephone or e-mail,we will be ready to provide consulting,maintenance and other services immediately.

Our Company

Toption Instrument Instrument Co., Ltd is a famous manufacturer of lab equipment, located in the central china. We specialized in rotary evaporator, jacketed glass reactor, single layer glass reactor, high-pressure reactor, photochemical reactor, ultrasonic dispenser/homogenizer, freeze dryer(lyophilizer), spray dryer and so on.

FAQ

Q: What is your MOQ of the rotary evaporator?
A:1 set.

Q: How long is your delivery time of rotary evaporator?
A: Generally it is within 3 working days after receiving the payment if the goods are in stock. Or it is 5-10 working days if the goods are not in stock, depending on order quantity.

Q: How to choose suitable rotary evaporator?
A:tell us your work flow and requirements ,then we will recommend you suitable equipment according to yourrequirements, application experience and feedback from our clients.

Q: How to solve the equipment trouble during using ?
A:Please email us about problem with pictures or a small video will be better,we will find the problem and solve it. If broken, we will send you a new free part if in the warranty period.
