19v 45w 2.37a dc adapter 100-240v 50-60hz desktop switching ac adaptor 19v2.37a adapter for laptop ac adapter power charger

FOB Reference Price:Get Latest Price
$6.00 - $7.00 / Pieces | 200 Piece/Pieces (Min. Order)
Plug Type:
AU EU UK Universal US
Lead Time:
Quantity(Pieces) 1 - 100 >100
Est. Time(days) 10 Negotiable
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
YHY
Model Number:
YHY-DS19023700
Usage:
Game Player
Output Type:
DC
Connection:
Desktop
Product Name:
19v2.37a adapter for laptop ac adapter power charger
output:
single
output voltage:
19V
output current:
2.37A
power:
45w
type:
desktop
input:
100-240vac
frequency:
50/60hz
ac cable:
1.2m
usage:
switching
Supply Ability
Supply Ability:
100000 Piece/Pieces per Quarter
Packaging & Delivery
Packaging Details
packing:White box
Port
shenzhen
Lead Time :
Quantity(Pieces) 1 - 100 >100
Est. Time(days) 10 To be negotiated
Video Description

19v 45w 2.37a dc adapter 100-240v 50-60hz desktop switching ac adaptor 19v2.37a adapter for laptop ac adapter power charger



Detailed Images

Dear Customers, Welcome to Shenzhen Yinghui Yuan Electronic Co.,Ltd



Desktop AC Power Adapter

-100-240VAC Universal Input Range

-Meets Doe Efficiency Level VI

-Desktop Styles

-19V Single Output 2.37A

-Regulated Output with Low Ripple

-Impact-Resistant Polycarbonate Enclosure

-No load Power Consumption <0.25W

-Limited Power Source

-Certified to UL/EN/IEC60950-1





Specifications

Input Voltage Range

VAC

100-240Vac 50/60Hz

Inrush Current at 110VAC, 25℃

A



Input Current(Max)

A

2.0A(100VAC Input)

Power Factor

-

Meets EN61000-3-2

Leakage Current(220VAC 60Hz)

mA



Hold Up Time at 110VAC input, full load

ms



Temperature Coefficient

±0.05%/℃

Voltage Accuracy

%

±2%

Adjustment Range

-

None

Min. Load

A

None

Total Regulation

-

±5%

Ripple & Noise

mV

120mV

Short Circuit Protection

%

Continuous - hiccup mode

Over Voltage Protection

110-150% of nominal (Cycle input power to reset)

Efficiency at Average Load

-

88% min

Operation Temperature

-

0 to +60℃, derating linearly to 50% load above 40℃

Storage Temperature

-

-10 to +85℃

Humidity (non condensing)

-

10-90% RH

Cooling

-

Convection

Withstand Voltage

-

Input to Ground 1.5kVAC, Input to Output 3kVAC (Output is connected to Ground)

Vibration (non condensing)

-

23.52m/s2 (10 - 55Hz: constant sweep 1 min X, Y, Z for 1 hour)

Shock

-

< 196.1 m/s2 (20G)

Safety Agency Certifications

-

UL60950-1, EN609501-1, IEC60950-1, CE Mark

DOE Regulation

-

VI

Off-Load Power Consumption

mW

<210mV

Conducted & Radiated EMI

-

EN55023-B, FCC Class B

Immunity

-

EN55024

Weight

G

280g

Size(WxLxH)

mm

115x50x30mm

Cable Length and Thickness

mm

1200mm

AC Input Connector

-

IEC 320-C6 / IEC 320-C8/ IEC 320-C14

Output Connector

mm

5.5x2.1mm (Accept more request)

MTBF 100%, 25℃

Hours

50,000 hours

Warranty

Years

3 years

Hot sale Products

CLICK AND VIEW MORE



POWERMODEL NO.INPUTOUTPUTAC
VOLTAGECURRENTPlug-inDesktop
12W SeriesYHY-05002500100-240VAC5V         2.5A        AU
EU
UK
US
KR
JP
Interchangeable
C6
C8
Two Cord
YHY-060020006V2.0A
YHY-090013009V1.3A
YHY-1200100012V1.0A
YHY-2400050024V0.5A
YHY-3000040030V0.4A

24W SeriesYHY-05003500100-240VAC5V3.5AAU
EU
UK
US
KR
JP
Interchangeable
C6
C8
Two Cord
YHY-060030006V3.0A
YHY-090026009V2.6A
YHY-1200200012V2.0A
YHY-1500160015V1.6A
YHY-1800130018V1.3A
YHY-2400100024V1.0A
YHY-3000080030V0.8A

36W SeriesYHY-05004000100-240VAC5V4.0AAU
EU
UK
US
KR
JP
Interchangeable
C6
C8
C14
Two Cord
YHY-060040006V4.0A
YHY-090040009V4.0A
YHY-1200300012V3.0A
YHY-1500240015V2.4A
YHY-1800200018V2.0A
YHY-2400150024V1.5A
YHY-3000120030V1.2A

48W SeriesYHY-05005000100-240VAC5V5.0AAU
EU
UK
US
KR
JP
Interchangeable
C6
C8
C14
Two Cord
YHY-060050006V5.0A
YHY-090040009V4.0A
YHY-1200400012V4.0A
YHY-1500320015V3.2A
YHY-1800260018V2.6A
YHY-2400200024V2.0A
YHY-3000160030V1.6A

60W SeriesYHY-05006000100-240VAC5V6.0AAU
EU
UK
US
KR
JP
Interchangeable
C6
C8
C14
Two Cord
YHY-060060006V6.0A
YHY-090050009V5.0A
YHY-1200500012V5.0A
YHY-1500400015V4.0A
YHY-1800330018V3.3A
YHY-2400250024V2.5A
YHY-3000200030V2.0A

72W SeriesYHY-05007000100-240VAC5V7.0A ---C6
C8
C14
Two Cord
YHY-060070006V7.0A
YHY-090060009V6.0A
YHY-1200600012V6.0A
YHY-1500480015V4.8A
YHY-1800400018V4.0A
YHY-2400300024V3.0A
YHY-3000240030V2.4A

100W SeriesYHY-05008000100-240VAC5V8.0A ---C6
C8
C14
Two Cord
YHY-060080006V8.0A
YHY-090080009V8.0A
YHY-1200800012V8.0A
YHY-1500650015V6.5A
YHY-1800550018V5.5A
YHY-2400400024V4.0A
YHY-3000330030V3.3A

120W SeriesYHY-05010000100-240VAC5V10A ---C6
C8
C14
Two Cord
YHY-060100006V10A
YHY-090100009V10A
YHY-1201000012V10A
YHY-1500800015V8.0A
YHY-1800660018V6.6A
YHY-2400500024V5.0A
YHY-3000400030V4.0A

150W SeriesYHY-12012500100-240VAC12V12.5A ---C6
C8
C14
Two Cord
YHY-1501000015V10A
YHY-1800830018V8.3A
YHY-2400600024V6.0A
YHY-3000500030V5.0A

Our Services
  • Your inquiry related to our products or prices will be replied in 24hrs.
  •  Well-trained and experienced staffs to answer all your enquires in fluent English
  • OEM&ODM, any your custo mized lightings we can help you to design and put into product.
  • Distributoership are offered for your unique design and some our current models
  • Protection of your sales area, ideas of design and all your private information
FAQ

 1.Q: Do you offer samples for testing?

A: Yes,we offer samples for testing with cost paid by buyer.Besides we welcome our customers to take sample as we believe seeing is believing.

2.Q: What's your MOQ?
A:we have no moq if stocked and 2000pcs if OEM order.

3.Q:Do you have warranty?
A :Yes,we have warranty of 3 year period.

4.Q:Do you have certificates for your products?
A:Yes,we have UL/CUL,FCC,RoHS,CE,KC,SAA,TUV GS,PSE,KCC,NOM Certifications.

5. Can you design the new housing based on our design?
A: We can design. one week make up sample. 30days sample test 45days start to MP?

6. What's the main product of you factory?
A: We are the supplier for 0-500W global power adapter, including wall plug adapter,usb adapter/charger,desktop adapter, metal case switching power supply,led power supply, waterproof power supply,led driver,open frame power supply and ect.

7. Do you have some new product coming?
A: We will design more and more new product with differenct high quality.





8.Q: What's your payment item?

A: Our standard payment is T/T in advance, Credit Card , E-Checking, Paypal and Western Union.
