60mm 400w AC 220V servo motor

  • 2-15 Pieces
    $155.00
  • >=16 Pieces
    $147.00
Output Power:
400W
- +
available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
9 day(s) after payment received
Contact Supplier
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Zhejiang, China
Brand Name:
MiGE brand
Model Number:
60AST-M01330
Type:
Servo Motor
Frequency:
50-60HZ
Phase:
Single-phase
Certification:
CE, ISO
Protect Feature:
Drip-proof
AC Voltage:
208-230 / 240 V
Efficiency:
IE 3

Packaging & Delivery

Selling Units:
Single item
Single package size:
24X22X20 cm
Single gross weight:
2.9 kg
Package Type:
packed in carton or plywood case
Picture Example:
package-img
Lead Time :
Quantity(Piece) 1 - 50 >50
Est. Time(days) 9 To be negotiated
Video Description

60mm frame 400w ac motor has a very compact structure and attractive appearance. The motor has some good features, such as high efficiency, energy-saving, high starting torque and easy maintenance.



They are widely used in digit control machine tools, laser processing machines, computer embroidery machines, textile machinery, printing machinery, packaging machinery, markers, engraving machines, winding machines, three-coordinates measuring machines, XYZ three- dimensional tables, industrial robots, medical equipment, woodworking machinery, ceramic machinery and other industries.







Packaging & Shipping








Product Description



Motor model

60AST-M01330

Rated power(W)

400

Rated voltage(V)

220

Rated current(A)

2.8

Rated speed(rpm)

3000

Holding torque(N.m)

1.27

Peak torque(N.m)

3.9

Voltage constant(V/1000r/min)

29.6

Torque coefficient(N.m/A)

0.45

Rotor inertia(Kg.m²)

0.29*10-4

Line-line Resistance(Ω)

2.35

Line-line Inductance(mH)

14.5

Mechanical time-constant(Ms)

6.17

Weight(Kg)

1.63

Encoder line number(PPR)

2500

Insulation class

Class B

Safety class

IP65

The operating of

Environmental conditions

Temperature:-20°C~+40°C

Humidity: Below 90%RH No dewing


Company Information





Hangzhou Mige Electric Co., Ltd. is a professional manufacturer of high technology. We are engaged in the R&D, production and sales of hybrid stepping motors, permanent magnet ac servo motors and other related products.

Our main products are two and three phase composite stepping motors, drivers, and exchange servo motors. Products are complete in specifications, with powerful and dependable performance and good price. Our products are in a higher position in the field.

Our composite stepping motors, optimizing structure design with excellent synthesized function. Our high speed torques set has good dynamic state, stable working condition in low velocity. Our products have been widely used in digit control machine tools, laser processing machines, computer embroidery machines, textile machinery, printing machinery, packaging machinery, markers, engraving machines, winding machines, three-coordinates measuring machines, XYZ three- dimensional tables, industrial robots, medical equipment, woodworking machinery, ceramic machinery and other industries.
