AHD 720P 960P 1080P 2.1mm lens wide angle surveillance IR mini hd car camera

  • 30-99 Pieces
    $14.00
  • >=100 Pieces
    $13.50
Memory Capacity:
None
Color:
- +
available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
5 day(s) after payment received
Customization:
Customized logo (Min. Order: 200 Pieces)
cable length (Min. Order: 200 Pieces)
Contact Supplier
Samples - $15.00 /Piece, 1 Piece (Min. Order): Buy Samples
Loading... Add To Cart
Report Suspicious Activity
Overview
Quick Details
Certification:
CE
Place of Origin:
Guangdong, China
Brand Name:
KOPDA
Model Number:
KD-MINIAHD004-960P
Warranty:
1 Years
Car Fitment:
Universal
Model:
Universal
Year:
Universal
IR LED:
10PCs F5
IR distance:
10Meters
Lens:
2.8mm F2.0
Waterproof:
IP66
item:
car camera
resolution:
960P
material:
metal
keyword:
mini camera car
item name:
mini ir camera
keyword 2:
wide angle security camera

Packaging & Delivery

Selling Units:
Single item
Single package size:
10X10X10 cm
Single gross weight:
0.6 kg
Package Type:
on piece per color box
Lead Time :
Quantity(Piece) 1 - 30 >30
Est. Time(days) 5 To be negotiated
Video Description
Product Description

AHD 720P 960P 1080P 2.1mm lens wide angle surveillance IR mini hd car camera

Specification:

Use 1.3MP progressive scan CMOS, capture motion-free images
Support coaxial HD output, clear and exquisite images
Illumination, 0.1Lux @ (F1.2, AGC ON), 0LUX with IR
Support IR-CUT switch, CDS external control, day and night surveillance
Support OSD menu control for user-defined settings
Support for digital WDR
Adaptive digital noise reduction, 2D-DNR
Aviation connector

Technical Parameters:

Parameters: 1.3MP HD surveillance cameras in 1 coaxial module
Module Parameters

Sensor Type: NVP2431+ 1/3" AR0130

System format: PAL / NTSC
Effective pixels: 1280 (H) x720 (V)
Minimum illumination: 0.1Lux @ (F1.2, AGC ON), 0LUX with IR
IR LED:10PCs F5
IR Distance: 10Meters
Lens: 2.1/2.5/2.8/3.6mm
Shutter: AUTO
Day and night modes: External Control (default) / Auto / color / B & W
Synchronization: Internal synchronization
Frame rate:  960P @ 25fps / 960P @ 30fps
Video Output: AHD / TVI / CVI / CVBS switchable
Menu Control
Came to light: brightness / exposing mode / gain
White Balance: ATW / manual white balance
Day & Night: IR / Internal Auto / color / B & W
Video settings: contrast / sharpness / saturation / DNR / video format / digital WDR
Language: Chinese / ESPANOL / Traditional Chinese / ITALIANO / ENGLISH
reset
Menu Switch Mode: The factory default AHD signals:
Top: AHD: CVI Left: TVI Right: CVBS (press 5 seconds release the switch).
Standard switching:
PAL / NTSC switch directly inside the menu.

General Specifications

Operating temperature: -20 degrees Celsius to 60 degrees Celsius
Humidity: relative humidity less than 90%
Power - Current: DC12V (± 20%) - 50MA
Size: 32 * 32/38 * 38 (mm)

chipset
NVP2431+ 1/3" AR0130
resolution
960P
lens
2.8mm
IR LED
10pcs F5
Detailed Images
Main products

HDD recording

SD card recording

720P/960P/1080P

720P/960P/1080P

720P/960P/1080P

English and Arabic.

7inch and 9inch optional

Use for public bus
Factory

About us

We (Shenzhen KOPDA Surveillance Electronic Ltd.) are manufacturing and trading combo in CCTV system since 2003. Our products sell well in the USA, Canada, Mexico, Brazil, Peru, Australia, Sweden, Poland, Germany, Ireland, Nigeria, Cambodia, Singapore, etc.



Our main products are mobile DVR and security camera, and we have more experience in school bus monitor system project, trunk monitor system project, public bus system project and taxi monitor project. We supply OEM of the mobile DVR and security camera, R&D the function according to your request.


Beside mobile DVR and security, we are wholesale of smart home IP camera and NVR, and all related CCTV accessories. All our goods have one year warranty, and all life time maintenance


Having been abiding by the principle of "customer first, quality first", we have adopted the "people-oriented, continuous innovation, expanding market" management approach and "improve quality, quality for survival, sincere service" quality policy.

SMT Machine 1

All the chip made by SMT machine,and most machine is made by Yamaha.

SMT Machine 2
All the chip made by SMT machine,and most machine is made by Yamaha.

SMT Machine 3
All the chip made by SMT machine,and most machine is made by Yamaha.

Chip testing

All the chip test before moving to  next produce line.

Part Welding

Some part can't be made by machine, we will welding it by manual.

Part Welding

Some part can't be made by machine, we will welding it by manual.

Produce line

assembled the chip,case,cable and all accessories.

Produce line

testing all finished items

Testing

Again Testing all items before ship.

Certificate

CE EMC

All the mobile DVR and security camera has approved the CE EMC certificate.

CE LVD

All the mobile DVR and security camera has approved the CE LVD certificate.

FCC

All the mobile DVR and security camera has approved the FCC certificate.

FAQ

Is the sample free?
Not, the sample is cost.

How long will it take for sample?
1~3 working days

Do you have MOQ ?
No.

Do you accept PAYPAL?
For sample order and small order, we accept PAYPAL.

Can we laser our Logo?
We have MOQ 30PCs for laser Logo.

Do you accept dropshipping?
Yes

Hong long is your warranty?
One year

Do you accept OEM?
Yes


Can you supply CO.(Certificate of Origin)

Yes


Can you supply SASO?

Yes
