Big Capacity Carob Seed Gravity Destoner Machine

  • 1-2 Sets
    $6,600.00
  • >=3 Sets
    $6,500.00
Model Number:
5QSC-7.5
$
- +
available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
7 day(s) after payment received
Customization:
Customized logo (Min. Order: 1 Sets)
Customized packaging (Min. Order: 1 Sets)

More

Graphic customization (Min. Order: 1 Sets) Less
Samples: $6,600.00 /Set, 1 Set (Min. Order): Buy Samples
Contact Supplier
Samples - $6,600.00 /Set, 1 Set (Min. Order): Buy Samples
Loading... Add To Cart
Report Suspicious Activity
Overview
Quick Details
Type:
Farm Equipment
Use:
Agriculture
Place of Origin:
Hebei, China
Brand Name:
HELIDA
Certification:
CE SGS BV ISO
Condition:
New
Applicable Industries:
Manufacturing Plant, Machinery Repair Shops, Farms, Energy & Mining
Color:
Customized
Application:
Remove Stones
Name:
Seed Gravity Destoner
Product name:
Seed Gravity Destoner
Usage:
Remove Stones
Function:
Remove Stones
Capacity:
8T/H
Raw material:
Carbon Steel
Power:
6.6Kw
Weight:
600kgs
After-sales Service Provided:
Engineers available to service machinery overseas

Packaging & Delivery

Selling Units:
Single item
Single package size:
30X30X30 cm
Single gross weight:
50.0 kg
Package Type:
Nude or Wooden Box Packing
Lead Time :
Quantity(Sets) 1 - 10 >10
Est. Time(days) 7 To be negotiated
Big Capacity Carob Seed Gravity Destoner Machine

photobank (10).jpg

The princple of the machine:
It is based on the proportion of grain crop and cobble density differences, by adjust the pressure and vibration frequency separate the stone and grain. The machine is equipped with a multi blade fan with high accuracy,The lighter grain crops will be suspended state, and the larger proportion of the stones will cling to the stainless steel mesh by adjusting the air pressure, and then by adjusting the frequency that Stoner table vibrates so as to achieve the purpose of separation. The machine equipped with frequency conversion control device can be subtle regulation, even if the proportion of the difference is very small, stones also will be separated.

The data:

ModelProductivityPowerWeightDimensionScreen area
QSC-10X10000KG/H9KW1100kg2800X1700X1800MM1300X1500MM
QSC-7.57500KG/H8KW900KG2700X1600X18001300X1500MM
QSC-55000KG /H 6.6KW 600kg2800X1500X1800mm 1300X1500MM

 The detail:

photobank (11).jpg

photobank (12).jpg



Product Overviews

1. 5XZC-5DX Seed Cleaner & Grader

Seed cleaner & grader is used for cleaning and grading seeds, grains, cereals, and other granule products. It can be equipped to suit a variety of special jobs and purposes.

Dust and light impurity are removed by aspirator fan. Material falls on sieve layers and was separated by sieves according to width and thickness difference. All the oversize and underside impurities were discharged from outlets.

2. 5XZ-5 Gravity Separator

High performance and durable quality

Easy installation, operation and maintenance

Inclination and oscillation adjustable

Available deck for many different material

Dust cover available to protect environment

Deck is designed for optimum distribution of air

3. QSC-5X Destoner

QSC-5X Seed Destoner Machine is used to remove heavy foreign impurity like stone, metallic and glass pieces etc on the principle of weight difference.

With the combination of fluidization and deck oscillation, heavy particles migrate to upper levels of the deckdischarged from outlets and the light particles move to the lower level of the deck.

Excellent performance and high capacity

Wide application for all kinds of seeds, beans, raw materials

Elevator available

Durable quality with favorable pwheat

Easy operation and maintenance

4PG-5D Polishing Machine

The PG Series bean polishing machine can remove the dust , soil on the surface of beans, make beans to have bright gloss, improve the quality of products.

It is suitable for most kinds of round beans, such as red bean, mung bean, soybean etc.
