Cheap 1000W ipg fiber laser source for CNC fiber laser cutting machine

  • 1 - 4 Sets
    $25,000.00
  • >=5 Sets
    $23,000.00
Model Number:
RLFCL-808nm RLFCL-915nm RLFCL-976nm others upon request
Power(W):
1000w
Lead Time:
Quantity(Sets) 1 - 10 >10
Est. Time(days) 30 Negotiable
Report Suspicious Activity
Overview
Quick Details
After-sales Service Provided:
Online support
Applicable Material:
Metal
Laser Type:
Fiber Laser
Cutting Area:
1300*2500mm, 3000*1500
Cutting Speed:
25m/min
Graphic Format Supported:
AI
Application:
Laser Cutting, Metal processing/3D printing/Scientific research
Applicable Industries:
Machinery Repair Shops
Condition:
New
Cutting Thickness:
0-30mm
CNC or Not:
Yes
Cooling Mode:
Water Cooling
Control Software:
Cypcut
Place of Origin:
Jilin, China (Mainland)
Brand Name:
Rays
Certification:
CE
Warranty:
1 Year
Laser Source Brand:
Coherent
Laser Head Brand:
HIGHYAG
Guiderail Brand:
THK
Control System Brand:
Beckhoff
Key Selling Points:
Automatic
Power:
1kW/Other customized output power
Wavelength:
808nm/915nm/976nm/Other customized wavelength
Package Type:
Bars combining/ single emitters combining, Fiber-coupled
Fiber Parameter:
Fiber core diameter: 400μm, NA0.22, QBH adapter
Working Mode:
CW
Quality:
Germany/American laser chip
Product name:
Fiber-coupled diode laser source
Port:
Beijing
Payment:
T/T
Supply Ability
Supply Ability:
10 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
Aluminum case for metal surface heat treatment or box, 30cm*30cm*20cm, 10 pcs in one box
Port
Beijing
Lead Time :
Quantity(Sets) 1 - 10 >10
Est. Time(days) 30 To be negotiated

Cheap 1000W ipg fiber laser source  for CNC fiber laser cutting machine

kW Fiber-coupled diode laser source Quick Details

1 Output from fiber, QBH fiber adapter

2 Diode laser single emitter chip from Germany
3 lifetime: over 10000hours

4 Single wavelength or two wavelength

kW Fiber-coupled diode laser source is widely used in  metal material processing, welding, cladding and 3D printing. Rays Laser has  particular emitters combining patent and output power of fiber-coupled diode laser can be up to 2000W. Typical wavelengths are 915nm, 976nm (others upon request). Rays Laser can also customize some wavelength combining source upon our client's requirements.

kW Fiber-coupled diode laser source  Working Principle

Fiber-coupled diode laser module is high-power laser souce by combining. The beam output from fiber, so big power density can be gotten. Besides, it is convenient in application,and customers can use them to processing metal material.

kW Fiber-coupled diode laser source Advantage

1 Rays Laser's team have researched laser packaging for more than 20 years and have laser producing patents

2 Diode laser chip from Germany

3 Customized optional output power and wavelength

4 Standard dimension or  customized dimensions

5 Adding optical system after fiber for special customers' requirements

6 Refurbishment and repair service for any other diode laser brand module



Product Description



Highest output power of high-power fiber-coupled diode lasers reachs 2kW, wavelength 9xxnm.

Features

High power conversion efficiency,Small dimension,Low maintenance cost,High metal absorption

Applications

Gear welding,Mold welding,Sheet metal welding,Bearing welding,3D printing





Optical Parameters
Center Wavelength (nm)       9xx
Output Power (W)1000(CW)
Fiber Core Diameter (μm)200 / 800 (Optional)
Numerical Aperure (NA)0.22
Electrical Parameters

Power Conversion Efficiency

(%)

45
Input Voltage Range(V)220~380

Voltage / Current Adjusting

Mode

Digital Programming Control or External 0-5v

 Analog Control

Communication InterfaceRS485 Serial Communication
Indication Voltage, Current, Alerting, Output, etc
Start / Stop Contact. Open: Output OFF; Short: Output On
Thermal Parameters

Operating Temperature Range

(℃)

20~40

Storage Temperature Range

(℃)

0~55
Cooling Water-cooled
Coolant Tap Water
Dimension
Outside Dimension (mm3)540×420×283



click to find more information

↑↑↑Every product has a interlinkage, you can choose one to learn more.↑↑↑

Advantages





1 Jilin Province Changguang Rays Laser Technology Co.Ltd. has established by high-power diode laser team of Changchun Institude of Opitcs,

     Fine Mechanics and Physics, Chinese Academy of Sciences and has top high-power diode technology.

2 Our team has researched the diode laser for more than 20 years, and we are famous in China in diode laser field.

3 Rays Laser holds a number of proprietary patents in laser turf.

4 Quality is also assured by sophisticated cutting-edge instrumentation and 1800 square meters ultra-clean room, with high volume production capacity.
