Copper Tube Straightening and Cutting Machine for HVAC Application

$25,000.00 / Set | 1 Set (Min. Order)
Model Number:
XZJ-4
$25,000.00
- +
available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
15 day(s) after payment received
Contact Supplier
Report Suspicious Activity
Overview
Quick Details
Applicable Industries:
Manufacturing Plant
Place of Origin:
Jiangsu, China
Brand Name:
WONDERY
After-sales Service Provided:
Online support, Field installation, commissioning and training, Field maintenance and repair service
Warranty:
1 Year
machine name:
Aluminum Tube Straightening and Cutting Machine
use:
to decoil, straighten and cut tubes
application field:
HVAC system; air-conditioner
copper diameter:
max 19.05mm
Type:
servo type
Color:
customized
Weight:
1000Kg
Power:
1.5kw
size:
3.1*2.15*1.7m
pipe material:
copper
Product Certification Verified
CE Certified.
Valid from 2017-12-28 until 2022-12-27

Packaging & Delivery

Selling Units:
Single item
Single package size:
310X215X170 cm
Single gross weight:
1000.0 kg
Package Type:
wooden case suitable for sea transportation
Picture Example:
package-img
Lead Time :
Quantity(Set) 1 - 1 >1
Est. Time(days) 15 To be negotiated
Product Description
Model Choice for Copper Tube Straightening and Cutting Machine
Machine Type
2-Tube Type
4-Tube Type
6-Tube Type
Copper Tube Diameter
dia 4.76~19.05mm
Working Cycle
6times/min (based on 1m copper tube)
Copper Tube Straightening and Cutting Machine
1 Cut-to-length: one time feeding length at 1000mm; final product length unlimited;
2 Feeding method: servo motor+ ball screw;
3 Decoiling method: automatic motorized decoiling (tube coil)
4 Tube collection stand: pneumatic cylinder tube fall-out;
5 Electrical control: PLC control and touch screen display;

Main Features


   The copper pipe straightener machine is comprised of decoiler, straightening and cutting body, and tube collection device. The machine is controlled by PLC and touch screen. The copper pipe straightener machine is also called as copper tube straightener machine, copper tube straightener, or copper tube straightening and cutting machine.
a) The cut-to-length of the tube is set through the human-machine interface.
b) The straightening mechanism of the copper pipe straightener machine can be adjusted both horizontally and vertically.
c) The feeding mechanism employs servo motor and ball screw, which ensures an accurate feeding length and allows convenient adjustment. The machine can cut the tubes without burrs. Each cutter can be adjusted separately, and can be used repeatedly by polishing. (cutter outer diameter:φ25)
d) The tube collection stand of the copper tube straightening and cutting machine is controlled by a pneumatic cylinder. There is a natural slant for the tube fall-down.
e) The mechanical system of the copper pipe straightener machine is in fully-automatic operation. The finished product quality is stable and reliable.
f) The overall structure of the copper tube straightening and cutting machine is well designed to ensure workers' safety.

Our Company

Wuxi Wondery Trading Co., Ltd is a comprehensive equipment supplier cooperating with various domestic factories. We can supply the heat exchanger production line for auto radiators, condensers, oil-coolers, heaters, or other products, and HVAC condensers and evaporators.


Auto Condenser Production Line
Including: collecting pipe single-punch mold; collecting pipe automatic forming machine; aluminum one-end or two-end chamfering machine; semi-automatic core builder; condenser side plate forming machine; collecting pipe slitting machine; flat tube straightening and cutting machine; aluminum brazing furnace.

Auto Radiator Production Line
Brazing radiator machines: fin machine, radiator core
builder machine, plastic tank clinching machine, leak detector, header and side plate mold, continuous brazing furnace;
mechanical radiator machines: high speed fin punching machine, fin die, tube-to-fin expansion machine, tube-to-header expansion machine, plastic tank clinching machine, etc;

Evaporator Production Line
Including: fin die (single-punch type or progressive type); serpentine tube bender; evaporator core builder machine;

HVAC Equipment:
Including: heat exchanger bending machine; Long/short U-tube bending machine; copper tube straightening and cutting machine; fin press line; progressive fin die; vertical/horizontal expansion machine; others.

Molds: aluminum header plate mold, aluminum radiator plastic tank radiator, fin die (air conditioner fin die), etc;
