DOZ-7600 water analyzers O3 meter ozone sensor online ozone meter

Feedback Ratings
  • 1-19 Sets
    $1,176.00
    $1,470.00
  • 20-49 Sets
    $1,096.00
    $1,370.00
  • >=50 Sets
    $960.00
    $1,200.00
20% OFF Discount ends in : : :
Model Number:
DOZ-7600
- +
available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
15 day(s) after payment received
Contact Supplier
Report Suspicious Activity
Overview
Quick Details
Brand Name:
nobotech
Material:
ABS
Weight:
1KG, 0.9kg
After-sales Service Provided:
Video technical support
Warranty:
1 Year
Application:
Industry Water Treatment
Measurement range:
Ozone 0-20mg/L(ppm ) Temprature 0-60°C
Power supply:
220VAC±10% 50/60HZ
Resolution:
0.01mg/L,0.1°C
Accuracy:
pecede ±1%or ±0.01mg/L,±0.5
Dimensions:
96*105*168mm
Hole size:
92*92mm
Cable length:
3m
Usage:
Water Content

Packaging & Delivery

Selling Units:
Single item
Single package size:
44X30X20 cm
Single gross weight:
2.0 kg
Package Type:
carton
Lead Time :
Quantity(Set) 1 - 100 >100
Est. Time(days) 15 To be negotiated
Product Description

                Intelligent dissolved ozone in water analyzer is widely used in water treatment plant, canning factory, beverage factory, swimming pool, water cooling etc. It is designed for continuous detection and control of amounts of ozone in liquid.

Detailed Images
Main Features
◇Protection Grade:IP65 (waterproof, dust-proof and damp-proof)
◇Digital LCD display and English operation menu .
◇The main components are imported  from foreign famous brand.
◇High accuracy  , high stability and strong anti-jamming.
◇Temperature compensation function: manual/automatic.
◇Watchdog:make sure the meter does not  go dead.
◇ABS plastic casing (waterproof, dust-proof and damp-proof).
◇Analog output: 4~20mA
◇Multi- parameters showed at the same time:Ozone value, temperature, output current, and alert of range ability etc.
◇Using advanced new-style constant voltage sensor. No need to change mebranes and reagents. It is easy to maintain, high sensitivity, high stability and quick response.
Technical Parameters
◇ Protection Grade
IP65 (waterproof, dust-proof and damp-proof)
◇Measuring range
ozone 0-20.00 mg/L(ppm), temperature:0~60℃
◇Resolution
0.01mg/L, 0.1℃
◇Accuracy
±1% or ±0.01 mg/L, ±0.5℃
◇Temperature compensation function
0~60℃(manual/automatic).
◇Control interface
Two groups of ON/OFF relay contact, divided into  high and low alarm control
◇Analog output
4~20mA
◇Relay
the relay lag value can be set freely. Relay load :3A 220VAC/24VDC.
◇Working conditions
environmental temperature of 0~60℃, relative humidity ≤90%
◇Output load:<750Ω(4-20mA)
◇Working voltage: 220VAC10%,50/60Hz.
◇Dimension :96x105×168 mm
◇Hole size:92×92mm
