Domestic Self-primming Water Jet Pumps, HJSW

FOB Reference Price:Get Latest Price
US $20-300 / Piece | 100 Piece/Pieces (Min. Order)
Supply Ability:
600 Piece/Pieces per Week
Port:
Ningbo
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Zhejiang, China (Mainland)
Brand Name:
HT
Model Number:
HJSW
Theory:
Jet Pump
Structure:
Single-stage Pump
Usage:
Water
Power:
Electric
Standard or Nonstandard:
Standard
Fuel:
electric
Pressure:
Low Pressure
Application:
water supply
Brand:
HT
Pump body:
Cast iron
Motor:
Two-pole induction
Insulation:
Class B
Protection:
IP44
Weight:
Light
Quality:
Stable
Appearance:
Beautiful
Size:
Small
Use:
Safe
Packaging & Delivery
Packaging Details
Standard Carton For Export.
Delivery Time
4-6 Weeks After Order Confirmed

Specifications

Domestic JET Pumps, with brass or norly impeller
Head up to 55 m
Flow up to 90 l/min
Power 0.5 to 1.5 Hp(0.37 to 1.1 kW)

Domestic JET Pumps, JET Pump, HJSW Pump



Operating Limits
Liquid Temperatureup to 60 Cent. Degree
Ambient Temperatureup to 40 Cent. Degree



Motor
Two-pole induction motor (n-2900 rpm)
Insulation Class B
Protection IP44

Structures Features
Cast iron pump body
Stainless steel mechanical shaft seal (graphite to ceramic)
Noryl impeller (Brass impeller option)
Noryl (PPO) diffuser
Superior steel or stainless steel shaft
With thermal protector for all single phase motor

Installation and Application
These pumps are self-priming centrifugal pumps, self-priming is achieved using an ejector, housed in the pump body, the total delivery produced by the closed centrifugal impeller is sent only partly to the delivery opening, the remaining water is recirculated through the ejector, which is connected to the suction piping and eliminate any air pockets, when the pump is started up the water in the pump body circulates through the ejector and transfers any air from the suction to the delivery chamber, expelling it through the delivery piping. At the same time the vacuum generated causes the water to rise in the suction piping.
Since the self-priming system operates continuously, these pumps are practically un affected even by the presence of large amounts of entrained air in the fluid being pumped.

It is always advisable to install a foot valve or non-return valve on the suction opening.

Those pumps should be installed in a covered area, protected against the weather.

Technical Data at n=2850

Pump Model

Power

Inlet/

Outlet

M3/h

0

0.6

1.2

1.8

2.4

3.0

3.6

4.2

4.8

kW

Hp

l/min

0

10

20

30

40

50

60

70

80

HJSW/1C-E

0.37

0.50

1"X1"





H(m)

33

27

20

16

14

11







HJSW/1B-E

0.50

0.75

1"X1"

38

30

23

19

17

13







HJSW/10M

0.75

1.0

1"X1"

42

38

35

32

29

27

22





HJSW/10H

0.75

1.0

1"X1"

56

45

38

31

26

22







HJSW/15M

1.1

1.5

1"X1"

48

44

39

36

32

27

22





HJSW/15H

1.1

1.5

1"X1"

72

62

50

42

37

32
