EPS-500W off grid Pure Sine Wave DC 12V to AC 110V 220v 230V power inverter for solar home appliance

Feedback Ratings
  • 50-199 Sets
    $97.00
  • >=200 Sets
    $92.50
Quantity:
- + Sets available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
15 day(s) after payment received
Customization:
Customized logo (Min. Order: 100 Sets)
Contact Supplier
Samples - $120.00 /Set, 1 Set (Min. Order): Buy Samples
Loading... Add To Cart
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
SDX
Model Number:
EPS-500W
Output Power:
≤450W
Output Type:
Multiple
Size:
255*200*68MM
Weight:
2.27KG
Input Voltage:
80~264V customized
Output Voltage:
100V-240V customized
Type:
DC/AC Inverters
Output Frequency:
50/60 Hz customized
Output Current:
≤30A
control algorithm:
PWM
Output waveform:
Prue Sine Wave
Max solar charging power:
18V 360W
working mode suppport:
(AC input)Electric Supply and (DC input) Solar Power Supply
support auto switch working mode:
yes
battery capacity:
larger than12V/60AH
indication way:
LCD display
output power range:
DC 2W~70W & AC: ≤500W
Output interface:
DC12V*4 USB5V*2 AC*1
AC input & output:
should be customized

Packaging & Delivery

Selling Units:
Single item
Single package size:
43.5X37.5X34 cm
Single gross weight:
10.5 kg
Package Type:
Inside carton: 365*210*80mm Outside carton including: 8PCS/carton Outside carton: 435*375*340mm Outside carton G.W/N.W: 12.6KG/10.5KG
Lead Time :
Quantity(Set) 1 - 200 >200
Est. Time(days) 15 To be negotiated
Product Description


EPS-500W Pure Sine Wave Automatic Switching  Solar Inverter System

This is a EPS inverter system.The inverter can automatically transform the working model between Electric Supply (AC input) and Solar Power Supply (DC input) .


Product Feature Of The Auto Switch Solar Inverter


1 Electric Supply Mode(AC input) as main power supply way:When there is power cut,switch to Solar Power Supply Mode automatically.

1.1 If power cuts stop for a long time,the whole system will stop after the battery power has been exhausted.


1.2 If the black out was not very long time,when the power up again, the EPS inverter will switch back to Electric Supply Mode(AC input) automatically.At the same time,solar system keeps charging to full the battery.


2 Solar Power Supply Mode as main power supply way:Firstly,set a battery discharging limit.When battery power is less than the limit,the EPS inverter will switch to Electric Supply Mode(AC input) automatically.After the battery is full again,the EPS inverter will switch back to Solar Power Supply Mode.


2.1 Example:If we set the battery discharging limit as 50%,while the battery power is less than 50%,the EPS inverter will switch to Electric Supply Mode(AC input) automatically.After the battery is full again,then the EPS inverter will switch back to Solar Power Supply Mode.



Advantage


1 Lightweight for easy carrying design.


2 Environment friendly energy saving.


3 3.2"LCD monitor is very clear to display the status of the inverter system about battery capacity,charging and discharging indication,error indication,precedence mode setting.


4 Our inverter supports intelligent control.It can automatically switch off  and protect the system to against short circuit,over load,over flow or over discharge etc.


5 This EPS-500W inverter system supports multiple power supply mode.We can set the Electric Supply Mode (AC input) or Solar Power Supply (DC input) as priority selection for the system.


6 The EPS-500W inverter system has USB output,DC output and AC output for all kinds of electrical appliances.Such as TV, LED light,USB fan,  MP3, MP4, IPAD, handphone etc.


Product paramete

Model NO.: EPS-500W

output power(W): 500
battery voltage(Vdc): 12V or 24V (customized)

battery capacity range suggested:

larger than 12V/60AH (customized)


solar controller parameter


control algorithm: PWM
Max solar input power(W): 18V 450W
Max input current(A):30
Max output currrent(A):30

Output: USB 5V/2A, DC:12V/ 2W~70W,   AC:80V~264V ( Customized, for example: 195V~240V AC input for 220V AC output )


AC input parameter


input voltage range(Vac): 80V~264V

( Customized, for example: 195V~240V AC input for 220V AC output )

input frequency(Hz): 50/60 (customized)

AC charge current(A): 7


inverter parameter

output voltage(Vac): 220/230(other voltage 100-110V,240V can be customized)

output frequency(Hz): 50/60 (customized)
Max efficiency:88%
overload capability:120%
output wave: pure sine wave

Basic Parameter
output interfac
AC*1  DC12V*4  USB5V*2
display way
3.2" LCD Monitor
display content
battery capacity,charging and discharging indication, error indication,precedence mode setting.
protection
overload,under-voltage,surge,short circuit,over charge,over discharge and over temperature,etc.
cooling ways
fan cooling
noise dB(A)
<60
working temperature range(℃)
-15℃-50℃
storage temperature range(℃)
-5℃~30℃
working temperature
0-90℃(no condensation)
operate altitude(M)
<2000m
dimension MM
255*200*68
package size MM
370*210*80
Net weight KG
2.27
Gross weight KG
2.67


Other Solar Inverter


EPS-1000W

output power(W): USB 2A , DC 2W~70W ,

                                AC 80V~264V ( Customized)
battery capacity range :over 12V/150AH
Max solar input power(W):18V/720W
Max input current(A):12V/40A

inverter output wave:pure sine wave
output interfac:AC*2 DC12V*4 USB5V*2
AC input voltage range(Vac):80V~264V ( Customized, for example: 195V~240V AC input for 220V AC output )

Packing and Shipping


A complete set included:   1pc*solar inverter     2pcs*3W LED light

2pcs* 5M cable with switch for LED light

Our Serivces

If there is any need,please feel free to contact Lydia.


Our Company

Shenzhen SDX new energy technology CO.,LTD is a company integrated research,design and manufacturing of products like solar panel,Off-grid and On-grid power station,solar led street light,garden light,portable solar lighting system,solar camping lantern,solar key chain,,solar gifts and solar related application products."SDX" series products are self-innovated and manufactured.It is a hi-tech Enterprise which combines sales and services.The company now had developed good sales network,with products distributed to domestic provinces,remote areas,as well as European countries,Africa,Middle East,South Asia and South Africa.

FAQ
1.Q: Who are you?
Shenzhen SDX New Energy Technology Co., Ltd , located in shenzhen Guangming new district, is a company integrating research, design and manufacturing of solar products. Welcome OEM and ODM, 20 R&D engineers do services for you.
2.Q:What is the payment terms,delivery port and MOQ of products?
We can provide EXW, FOB, CRF and CIF price depends on your requests. The delivery port can be Shenzhen or Hongkong. We accept T/T, L/C, Western union, Paypal, etc.
3.Q:Can I get some samples? ?
Yes,of course. We are honored to offer you samples,usually samples can be ready in 3~7 days.
4.Q:How long is the warranty of your products? How to guarantee the after-sale services?
A: We guarantee most of our products for 1 year, the solar panel for 5 years.
We will prepare 3‰ to 5‰ accessories for easy damage parts. We will help you solve all the technology problems through email, phone, video, etc.

5.Q: Can I order less than MOQ?

A: Yes, you can. However, we will adjust price according to production cost.
