Electro hydraulic pusher with best price for sale

Feedback Ratings
  • 1-9 Pieces
    $100.00
  • >=10 Pieces
    $90.00
Quantity:
- + Pieces available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
1 day(s) after payment received
Contact Supplier
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Jiangsu, China (Mainland)
Brand Name:
Betten
Model Number:
DYTZ seriese
Type:
Electric hydraulic pusher
Application:
For Tractors, Trucks and Agricultural Use
Stroke:
50-3500mm
Thrust Force(10N):
450-20000
Pulling Force(10N):
310-15000
Material:
Carbon Steel/stainless steel
Pushing Speed:
25-110mm/s
Pulling Speed:
35-140mm/s
Power Consumption:
0.75-15kw
Warranty:
12 Months

Packaging & Delivery

Selling Units:
Single item
Single volume:
50 cm 3
Single gross weight:
20.0 kg
Package Type:
1. Wrap by Plastic film then waterproof paper, finally the wooden case. 2. Single carton packing was specially for small piece. 3. As the clients' requirment.
Picture Example:
package-img
Lead Time :
1
Product Description

 Betten Electro Hydraulic Pusher:

DYT series electro-hydraulic pusher is a set machine, electricity, liquid as one of the hydraulic driving device, can be widely used in metallurgy, building materials, chemical industry, lifting the transport and port handling machinery, the valve gate, reversing, tilting, swing and other mechanical drive control amount, can replace the traditional electric putt, hydraulic cylinder ( with a hydraulic station drive ) and cylinder ( by pump station drive control ).

Electric Pusher

Electric Hydraulic Ram

Electric Hydraulic Ram

Main characteristics

1, compact structure, convenient installation, small occupied space, easy maintenance;
2, circuit is provided with a bidirectional pressure self-locking device, can be in the range of travel stop in any position and self locking, and maintain constant output force;
3, when the accident off, push rod can be automatically locked in this position, to avoid the generation of accidents;
4, all concentrated in the hydraulic device inside the body, without external pipelines, oil seal are imported brand-name seal, the sealing effect is good, no liquid leakage pollution, and long service life;
5, simple electronic control, through the addition of a limit switch, is easy to realize the remote and dangerous regional operations control, automatic control and computer ( PLC ).

Technical Data
Model
Pushing Power
(10N)
Pulling power
(10N)
Push Speed
Pull Speed
Motol Type
Stroke
(mm)
DYTZ450-/110
450
310
110
140
Y802-0.75KW
50-800
DYTZ700-/110
700
510
110
140
Y90S-4-1.1KW
50-1500
DYTZ1000-/110
1000
750
110
140
Y90L-4-1.5KW
50-1500
DYTZ1750-/90
1750
1300
90
115
Y100L1-4-2.2KW
50-2000
DYTZ2500-/90
2500
2050
90
115
Y100L2-4-3KW
50-2000
DYTZ3000-/90
3000
2500
90
115
Y100L2-4-3KW
50-2000
DYTZ4000-/80
4000
2950
80
100
Y112M-4-4KW
50-2000
DYTZ5000-/60
5000
3300
60
90
Y112M-4-4KW
50-2000
DYTZ6000-/60
6000
3800
60
90
Y132S-4-5.5KW
50-2500
DYTZ7000-/50
7000
4500
50
75
Y132S-4-5.5KW
50-2500
DYTZ8000-/50
8000
5000
50
80
Y132M-4-7.5KW
50-2500
DYTZ10000-/40
10000
6500
40
60
Y132M-4-7.5KW
50-2500
DYTZ15000-/35
15000
11000
35
45
Y132M-4-7.5KW
50-2500
DYTZ20000-/25
20000
15000
25
35
Y132M-4-7.5KW
50-2500
Related Products

80% quality of REXROTH with 30% Price
Custom hydraulic cylinders to fit your need.


As an experienced Hydraulic Cylinder Supplier, Betten hydraulic manufacturing Hydraulic products include Small Hydraulic cylinder Customized, long stroke hydraulic cylinders, spare parts(hydraulic cylinder tube/ piston rods/ bearings), pneumatic cylinders, hydraulic system, are widely used in various fields:

Supplying China Top Quality:
Propotional valves, directional valves, pressure relief valves, pressure reducing valves

Supplying Hydraulic system pump station/ Hydraulic Power Pack

Spare Parts

Supplying Honed Tube/ Piston Rod/ Rod End/Seal Kits for long stroke hydraulic cylinder

Packing & Delivery


whether you require delivery FOB to a port in China or CIF to a port near you, we are happy to quote and supply cardan drive shaft whichever way you choose.
- Utilizing your own freight-forwarder
- FOB to a port in China
- CIF to a port near you

Our Service

1.Design Services
Our design team has experience in cardan shaft relating to product design and development. If you have any needs for your new product or wish to make further improvements, we are here to offer our support.

2.Product Services
raw materials → Cutting → Forging →Rough machining →Shot blasting →Heat treatment →Testing →Fashioning →Cleaning→ Assembly→Packing→Shipping


3.Samples Procedure
We could develop the sample according to your requirement and amend the sample constantly to meet your need.

4.Research & Development
We usually research the new needs of the market and develop the new model when there is new cars in the market.

5.Quality Control
Every step should be special test by Professional Staff according to the standard of ISO9001 and TS16949.

6.Certification
Should your products require testing and certification to comply with international standards, we can arrange this with independent, fully recognized testing companies such as SGS, Intertec, Bureau Veritas, Lloyd's Register or the testing company of your choice.

Our Company

Betten Hydraulic—Built Hydraulic Products to Fit Your Needs

As an experienced Hydraulic Cylinder Manufacturer and distributer, Betten Machinery is built to develop the overseas business of Boli Hydraulic & Pneumatic Technology Co., Ltd which is known as a professional manufacturer of Oil Cylinder,Pneumatic Cylinder, Hydraulic System and Related Spare Partsin East China.

Our factory cover an area of over 5000 square meters and have around 100 stuff including a technical team with more than 20 engineers. Our workshop equipped with over 30 sets of manufacturing and testing machines including machining center, numerical control machine, argon welding machine, plasma cutter etc. Betten has gained the certification of ISO 9001:2008 and certification of Product Quality Supervision and Inspection Center of Wuxi City. Meanwhile, Betten also got customers’ satisfaction for reasonable price, timely delivery and good after-sale service.

With the fast development in the past 20 years, we have gained much experience and technology in making various types of long hydraulic cylinder with our expert team. Our products are widely used in equipment such as machine tool, metallurgical equipment, forging machine, kiln equipment, brick machine, plastic machine, car manufacturing machine, construction equipment for road and bridge, wielding machine, port facilities, test machine, fully auto line and we have gained a lot of world famous customer like XCMG, LIUGONG Machinery, Chalco,BOSCH, Haier, SAINT-GOBAIN, Shanghai Boiler, HTC etc.

FAQ

What is the application for your double cardan shaft?


Heavy-duty machinery Metallurgical machinery

Mining machinery Agriculture machinery

Chemical machinery Petroleum machinery

Lifting transport machinery Textile machinery

Printing machinery Automotive

Tractor Marine

Pump Fan

Compressor Reducer
