FP10000Q 4 Channel Professional Audio Amplifier Pro Pa Power Amp

FOB Reference Price:Get Latest Price
US $700-900 / Piece | 1 Piece/Pieces (Min. Order)
Supply Ability:
500 Piece/Pieces per Month
Port:
huangpu
Overview
Quick Details
Brand Name:
SANWAY
Model Number:
FP10000Q
Type:
Professional Amplifier
Channels:
4
Place of Origin:
Guangdong, China (Mainland)
wideband voltage:
220v version can run from 135v to 265v voltage range
heat sink:
pure copper
low impedance:
2.67ohms
packing:
2 layers carton
FP10000Q:
4 Channel Professional Digital Audio Amplifier Pro Pa Power Amp
Warranty:
2 years
broadband voltage:
110v version amps can run from 65v to 135v voltage range
Power plug:
European or American
Net weight:
12.5KG
Gross Weight:
18kg
Packaging & Delivery
Packaging Details:
FP10000Q 4 Channel Professional Audio Amplifier Pro Pa Power Amp CARTON: 57.5X55X14CM

FP10000Q 4 Channel Professional Audio Amplifier Pro Pa Power Amp





Product Description





FP10000Q 4 Channel Professional Digital Audio Amplifier Pro Pa Power Amp

ITEM
FP6000Q
FP10000Q
Output Power
20-20kHz, 1W with 1 khz
8ΩStereo Power(RMS)
625WX4
1350WX4
4ΩStereo Power(RMS)
1250WX4
2100WX4
2ΩStereo Power(RMS)
1500WX4
2500WX4
8ΩBridged Power(RMS)
2500WX2
4200WX2
4ΩBridged Power(RMS)
3000WX2
5000WX2
Frequency Response(+o/-0.3dB,1W/8Ω)
20 Hz - 34 kHz
THD 20 Hz - 20 kHz for 1 W
<0.1%
Signal-to-Noise Ratio
>112 dBA
Channel separation (Crosstalk) at 1 kHz
>70 dB
Input Connectors (per channel)
3-pin XLR, electronically balanced
Output Connectors (per channel)
Binding Posts 2-pole
Class
TD
TourClass ProtectionACL,IGM,AutoRamp,short cricuit,DC voltage,turn-on/off transient,current,inrush
Operating voltage
130-265 V / 65-135 V selectable
Voltage Gain(dB)
23, 26, 29, 32, 35, 38, 41, 44 dB selectable
Input impedance
20 kOhm
Level adjustment (per ch.)Front-panel potentiometer, 31 position detented from -inf to 0 dB
Dimensions (W×H×D)
483×88×396mm
Packing dimension
560×180×500mm
Net weight(kg)
12
Gross weight(kg)
18

Packaging & Shipping

  FP10000Q 4 Channel Professional Audio Amplifier Pro Pa Power Amp
