HS-63216 Fully Automatic Wire Cutting Strip Crimp Both Ends Terminal Crimping Machine

FOB Reference Price:Get Latest Price
  • 1 - 4 Sets
    $88,000.00
  • 5 - 9 Sets
    $85,000.00
  • >=10 Sets
    $83,000.00
Customization:
Customized logo (Min. Order: 2 Sets)
Customized packaging (Min. Order: 2 Sets)
Samples:
$88,000.00 /Set | 1 Set (Min. Order) | Buy Samples
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Zhejiang, China
Brand Name:
HongSheng
Model Number:
HS-63216
Usage:
Crimping
wire size:
0.3sqmm - 1sqmm
capacity:
18pcs/min six wires (wire length less than 500mm)
cutting length:
60mm-500mm
power:
AC220V 50HZ single phase
cutting accuracy:
less than (0.2mm+cutting length*0.2%)
crimping capacity:
2.0T
air pressure:
0.6-0.7MPa
Supply Ability
Supply Ability:
1 Set/Sets per Month
Packaging & Delivery
Packaging Details
export packing, export wooden case
Port
Ningbo Port, Shanghai Port
Video Description
Product Description

automatic terminal crimping machine (one end insert plastic case, wire twist & tin machine)    HS-63216   More videos, please click here.

Fully automatic wire cut strip terminal crimping machine , crimp both ends HS-63216 on exhibition

Main Features

1) It can continuous automatic processing the automatic feeding of wire pulling and cutting, one end stripping twisting and tinning, the other end stripping, crimping terminals, inserting plastic case.

2) The main electric elements of equipment are imported. The operation is accurate and simple, the performance is stable, the labor is saved, and the quality stability is guaranteed.

3) It adopts touching human-computer interface to adjust conveniently and quickly.

Model
HS-63216
Power
AC220V 50HZ  Single phase
Function
wire cutting, one end stripping twisting & tinning, the other end striping, crimping & inserting plastic case.
Capacity
18pcs/min  six wires (wire length less than 500mm)
Wire size
0.3sqmm - 1sqmm
Cutting length
60mm - 500mm (the wire more longer, the speed more lower)(customized for special for wire length more than 500mm)
Stripping length
1mm - 10mm
Twisting length
3mm - 10mm
Tinning length
3mm - 10mm
Cutting accuracy
less than (0.2mm + cutting length*0.2%)
Crimping capacity
2.0T,  customerized for special
Detection device
lack of wire or knotted, terminal crimping detection the terminal inserting the plastic case in plastic detection
Air pressure
about 0.6-0.7MPa, dry and clean air
Dimensions
2500L*2100W*1600H (mm)
Weight
about 500 KGS
Other
choose pressure management device or terminal visual inspection (it is best to choose one

After

One end wire will twist and tin.

After

Another end will automatic terminal and insert the plastic case.

Certifications
Company Show
Our Service

Pre-Sales Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.

After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.

By express: DHL, UPS, TNT, FEDEX, EMS, etc.
We will search the most economical and reliable shipping company to transport the goods safely.
By air: when your order is more than 100kg which will be more economical than express
By sea: when your order is large quantity, we can help you to deliver the goods by sea
Port: Ningbo Port or Shanghai Port

FAQ

Q: HongSheng is one trading company or one factory?
R: HongSheng is one factory, and we also can export our equipment to aboard directly.

Q: HongSheng, can do OEM or not?
R: Yes. HongSheng can produce the equipment based on the requests from the customers.
HongSheng has one good team that can research and develop our equipment, including the software.

Q: How about the certificate?
R: Now, we have CE ROHS and ISO, future, if you need more certificates, we also can apply it.

Q: How about the after-sales service and the guarantee?
R: One-year warranty, full-life service

Packing & Delivery
Packaging
Size
2500 (L) * 2100 (W) * 1600 (H)
Weight
about 0.5 T



Packaging Details
1, Inner package, stretch film;
2, Outside Package, standard export wooden cases that should be fumigated.
3, If container is too tight, we will use pe film for packing.
4, We also can pack it based on the customers requests.

By Air or by Sea, it depends on the weight and the freight cost. We can discuss and confirm it together.
