High-Cr iron roll as Work roll in the roughing and previous-finishing stands of hot strip continous rolling mill

FOB Reference Price:Get Latest Price
$900.00 - $2,000.00 / Tons | 1 Ton/Tons (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Hebei, China (Mainland)
Brand Name:
WEILANG
Type:
Casting Parts
Material:
Alloy
Plating:
Chrome
Certification:
DIN
Name:
Cast High-Cr Iron Centrifugal Rolls of Mill Roll Made in China
Work Layer:
12-22% chrome
Core material:
Nodular cast iron and grey iron
Process:
Centrifugal casting
Conditon:
new
Cladding material:
Metal Alloy
Structure of matrix:
sorbite,troostite, bainite or martensite
Main Application:
Work roll in hot strip continuous rolling mills
Advantage:
Professional teams,strictly check, competitive price
Factory:
we have our own factory and welcome to visit
Supply Ability
Supply Ability:
1500 Ton/Tons per Month
Packaging & Delivery
Packaging Details
brush antirust oil---wrap a plastic cloth---wrap a PVC sheet---tie with iron straps---fix on pallet or in wooden case
Port
Tianjin port,Shanghai port
High-Cr iron roll as Work roll in the roughing and previous-finishing stands of hot strip continous rolling mill

The high-Cr cast iron rolls are made by centrifugal casting process,the work layer contains 12-22% Chromium.Through rational chemical composition allocations and different heat treatments,the matrix can be controlled as sorbite,troostite,bainite or martensite and certain kinds of carbides,such as Cr7C3 eutectic carbides,Cr23C6 second carbides,Mo2C carbides etc.According to diferent purposes of use,the material of the core could be nodular iron or grey iron.We make this type of roll by centrifugal cast double poured.In this case,we can achieve an excellent wear resistance in the shell with flake graphite,bainite & martensite and primary carbide type M7C3+ secondary carbide in the microstructure.Besides the excellent wear resistance,it is also good against fire cracking thanks to the oxide flm Cr203 formed on the body surface while roling.At the same time,the core is strong enough to assure the roll can work safely.The hi-Cr iron rolls are mainly used as work rolls in the roughing & previous -finishing stands of hot strip continuous roling mills;work rolls in the roughing & finishing stands of the plate mills;work rolls in temper mills and cold strip mills;rings in the large universal mills;work rolls in the finishing stands of small section mills and bar mils.



Chemical Composition

Grade

C

Si

Mn

P

S

Cr

Ni

Mo

Mg

HCr I

2.30-3.30

0.30-1.00

0.50-1.20

≤0.10

≤0.05

12.00-15.00

0.70-1.70

0.70-1.50

0.00-0.60

HCr II

2.30-3.30

0.30-1.00

0.50-1.20

≤0.10

≤0.05

15.01-18.00

0.70-1.70

0.70-1.50

0.00-0.60

HCr III

2.30-3.30

0.30-1.00

0.50-1.20

≤0.10

≤0.05

18.01-22.00

0.70-1.70

1.51-3.00

0.00-0.60

CORE  2.90-3.70 1.20-2.60 0.50-1.00 ≤0.15 ≤0.03 ≤0.08  ≤0.15 ≤0.05 ≥0.04


Mechanical Properties

Tensile Strength (kg/mm²)

400-700

Bending Strength (kg/mm²)

650-1000

Elongation (%)

0.2-0.6





1.which countries or areas have your peoducts been exported to?
Europe. south and north america.oceania.asia.etc. more than 36 countries all over the world.

2.how about the delivery time?
Delivery date is on time according to the customer's requirements.

3.how to control the quality?
We have our own strict QC system at every stage of production, for example dimension test, hardness test; chemical composition test; UT test;metallographic test;mechanical property and so on.

4.is weilang a trading company or a factory?
Tangshan Weilang is an industry and trade integration company.

5.our service
If you have any problems in your use, we will provide free technical support promptly.
