High speed 3d Wood working engraving Atc cnc router machine kit 1325 1530 2030 4*8 atc spindle vacuum

  • 1 Sets
    $13,500.00
  • 2 Sets
    $13,000.00
  • 3 Sets
    $12,500.00
  • >=4 Sets
    $12,000.00
Model Number:
LXM1325-D
- +
available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
7 day(s) after payment received
Customization:
Customized logo (Min. Order: 1 Sets)
Customized packaging (Min. Order: 1 Sets)

More

Graphic customization (Min. Order: 1 Sets) Less
Contact Supplier
Samples - $1.00 /Set, 1 Set (Min. Order): Buy Samples
Loading... Add To Cart
Report Suspicious Activity
Overview
Quick Details
Condition:
New
CNC or Not:
CNC
Place of Origin:
Shandong, China
Brand Name:
UNICHCNC
Voltage:
380V
Dimension(L*W*H):
3500*2300*1800mm
Certification:
CE
Warranty:
24 Months
After-sales Service Provided:
Video technical support
Control system:
Syntec 6MB
Inverter:
Fuling inverter
Driver:
YASKAWA
Spindle motor:
HQD
spindle cooling:
air cooling
vacuum pump:
Junran
vacuum pump Cooling:
Water cycle cooling
Guide rail:
Taiwan CSK
Ball Screw:
Taiwan TBI
Working table:
Double vacuum adsorption table
Power(W):
21.5KW
Weight:
2500kg

Packaging & Delivery

Selling Units:
Single item
Single package size:
350X230X180 cm
Single gross weight:
2500.0 kg
Package Type:
Plywood case box
Picture Example:
package-img
Lead Time :
Quantity(Set) 1 - 1 >1
Est. Time(days) 7 To be negotiated
Video Description
Product Description

High speed 3d Wood working engraving Atc cnc router machine kit 1325 1530 2030 4*8 atc spindle vacuum

Specification

1325 CNC

Notes

Machine Size(L*W*H)mm

3500*2300*1800



Working Area(X*Y*Z) mm

1300*2500*200



Spindle motor

Brand

HQD

18000-24000r/min

Power

9KW/unit

Cooling

Air Cooling

Working speed

18000-24000rpm/Min

Drive system

Type

High performance servo



Driver motor

YASKAWA

Driver

YASKAWA 850w

Inverter

Brand

Fuling inverter



Power

11KW/unit



Control system

            Syntec 6MB

16 Servo knife tool changer

Guide rail

Taiwan CSK



Ball Screw

Taiwan TBI



Working table

Double vacuum adsorption table



Lubrication

Automatic central centralized lubrication system



Position cylinder

X:2pcs Y:3pcs

tool auto-checking



Reduce gear

Japan Xinbao imported reduce



X transmission

30 square guide 1.5M high accuracy helical tooth reduce 8:1



Y transmission

30 square guide 1.5M high accuracy helical tooth reduce 8:1



Z transmission

30 square guide  high precision helical tooth reduce 8:1



Rack

Xinyue rack



vacuum pump

Brand

Junran



Power

11KW



Cooling

Water cycle cooling



dust collector

5.5Kw



Electrical cable

Shanghai cable



Wiring standards

CE standard



Electrical

Zhengtai



magnetic valve

Germany imported



 air cylinder

        Germany imported



Platform structure

Platform steel bracket square pipe100*100,side 150*250



Body

Heavy body(Tempering treatment)



Unload running speed

X axis

50-90m/Min(120 alarm)



Y axis

50-90m/Min(120 alarm)



Z axis

6m/Min



Maximum processing speed

X axis

10-25m/Min

According to different materials, cutting tools and processing speed are different

Y axis

10-25m/Min

Z axis

6m/Min



Tool shank type

ISO 30



Power type

380V



Weight

2.5 t



Total Power(approximately)

21.5KW



Available tool shank diameter

Φ12.7

Max Φ20

Application
