Most popular hot air gun preheating bga rework station reballing machine for lead and lead-free WDS-620

$3,980.00 / Set | 1 Set (Min. Order)
Model Number:
WDS-620
$3,980.00
- +
available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
3 day(s) after payment received
Contact Supplier
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Machine Type:
Welding Positioner
Applicable Industries:
Machinery Repair Shops, Manufacturing Plant, Retail, Construction works , Energy & Mining
Place of Origin:
Guangdong, China
Brand Name:
WDS(Wisdomshow)
Voltage:
220/110V
Current:
50/60hz
Rated Capacity:
N
Rated Duty Cycle:
N
Dimensions:
L650*W630*H850mm
Weight:
60KG
Usage:
mobile phone/laptop BGA/IC rework and repair
Certification:
CE
After-sales Service Provided:
Video technical support, Online support
Warranty:
1 Year
Product name:
hot air gun preheating bga rework station
Function:
Repair Motherboards
Electrical Material:
Driving motor+PLC smart temp.controller+ HD camera
Total Power:
5300W Max
PCB size:
Max410*380mm Min10*10mm
BGA Chip Size:
Max.70*70mm / Min 1*1Mm
Power:
Ac220v ±10%,50/60hz
Heater power:
Upper temp.one 1200w,second temp.zone1200w,IR temp.zone 2700w
Weight of machine:
60kg
Color:
White+blue
Product Certification Verified
CE Certified.
Valid from 2019-10-16 until 2049-12-31

Packaging & Delivery

Selling Units:
Single item
Single package size:
69X81X89 cm
Single gross weight:
80.0 kg
Package Type:
hot air gun preheating bga rework station wds620 is packed by Wooden Box
Picture Example:
package-img
package-img
Lead Time :
Quantity(Set) 1 - 1 >1
Est. Time(days) 3 To be negotiated
Most popular hot air gun preheating bga rework station reballing machine for lead and lead-free WDS-620
Product Description
Our BGA Rework Station/ BGA reballing station are widely used to replace and repair the BGA chip in laptop, mobile phone,xbox360,ps3,etc.
The main user is repairing shops and factory to provide the after-sales service and rework.
Main Features
BGA Rework Station
Model:WDS-620

♦ Automatic&Manual operation system
 5 million CCD camera optical  alignment system mount precision ±0.01mm
 MCGS touch screen control
 Laser position
 Repair success rate 99.99%

Independent 3 heating zones temperature control system
1.The upper and lower hot air heating,which can heat up at the same time from the top of the component to the bottom of the PCB; bottom IR heating, temperature precision control within ±1℃.8 segment temperature control independently.
2.Hot air district heating for BGA and PCB at the same time,and large area IR heater preheating up for the bottom of PCB to avoid completely PCB deformation during reworking,the upper or lower temperature zones could be used alone and combine freely the energy of up and lower heating element.
3.Adopted high precision K-type thermocouple close-loop control and PID parameter self-setting system;4 temperature curves can be displayed with instant curve analysis function and multi-group user data can be saved;temperature can be tested precisely through external measurement interface,curves can  be analysed、set and correct on the touch screen at any time.
Precision optical alignment system
Using high definition and adjustable CCD color optical alignment system,beam split、amplification 、lessening、fine adjustment and auto focus with the function that automatic color aberration resolution and brightness adjustment,adjustable image contrast;equipped with 15 ” high definition LCD monitor.
Multi-functional and humanized operation system
1.Adopting the HD touch human-machine interface;upper heating head and mounting head designed 2 in 1;providing many kinds of titanium alloy BGA tuyere can be rotated in 360 degree for easy installation and replacement.
2.X、Y and R angle adopted micrometer fine-tuning,accuracy locating,precision can reach ±0.01mm.
Superior safety protection function
With the alarm function, after the BGA welding, the machine can alarm by itself.In the case of temperature abuse, the circuit can power off automatically with the double over-temperature protection.Temperature parameter has  password protection to prevent any modification.

How to separate BGA chip from motherboard?
How to replace a new BGA chip?

Repair steps:
1) Separate the BGA chip from motherboard –we called desoldering
2) Clean Pad
3) Reballing or replace a new BGA chip directly
4) Alignment/Positioning – Depend on experience ,silk frame ,optical camera
5) replace a new BGA chip - we called Soldering
Product Paramenters
Power supply
AC 220V±10% 50/60Hz
Total power
Max 5300W
Heater power
Upper temp.zone 1200W,second temp.zone 1200W,IR temp.zone 2700W
 Electrical material
Driving motor+PLC smart temp.controller+HD camera
Temperature controlling
(high precision K-sensor)(Closed Loop),independent temp.controller,the precision can reach ±2℃
Locating way
V shape slot,PCB support jigs can adjust,laser light do fast centering and position
PCB size
Max 410×380mm Min10×10mm
Applicable chips
Max 70×70mm Min1×1mm
Overall dimension
L650×W630×H850mm
Temperature Interface
1 pcs
Weight of machine
60KG
Color
White&blue
Work mode
5 modes for choose,auto/manual work mode can be changed freely
Detailed Images
Packing&Shipping
1, Standard Export Wooden cases
2, Delivery in 2 workdays after payment confirm;
3, Shipping by TNT,DHL,FEDEX , or by air or by sea
4, Loading port: Shenzhen or Hongkong.
