Mypin 12V DC battery Electronic weight indicator for floor scales/truck scales(LM8E-VRD)

  • 1-9 Pieces
    $39.00
  • 10-99 Pieces
    $37.00
  • >=100 Pieces
    $36.00
Type:
Crane Scale Floor Scale Hanging Scale Lift Truck Scale Truck Scale Mechanical Scale Drum Scale
Rated Load:
9999
Accuracy:
1g/1000g
$
- +
available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
5 day(s) after payment received
Customization:
Customized logo (Min. Order: 100 Pieces)
Customized packaging (Min. Order: 100 Pieces)

More

Graphic customization (Min. Order: 100 Pieces) Less
Contact Supplier
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China
Brand Name:
Mypin
Model Number:
LM8E-VRD
Power Supply:
12V DC
Display Type:
4 digits LED display
Power consumption:
<5VA
Sampling speed:
16 times/sec.
Analog output:
0-10V DC
Alarm output:
relay
Accuracy:
0.1%
Power:
12V DC
Dimension:
48*96*80mm
Scale weighting indicator:
Scale weighting indicator

Packaging & Delivery

Selling Units:
Single item
Single package size:
11X5.5X10.5 cm
Single gross weight:
0.31 kg
Package Type:
each pieces packed in box lined with plastic bag, then every 50 box in carton
Picture Example:
package-img
Lead Time :
Quantity(Piece) 1 - 10 11 - 100 >100
Est. Time(days) 5 7 To be negotiated

Mypin Truck scale weighing indicator( LM8E-VRD)















1, Features available



u input: 1-4 pcs  load cells,force load cells ,      domestic and overseas market.

0.8" red LED 4 digits measurement,0.1%F.S..

        Fast response, stable display, with Tare weight clearance function.

 RS232/RS485 MODBUS RTU interface for your choice,

        which enables to connect with other indicator,PC or PLC.

 analog output are digitally transferred automatically. Analog range set freely by  user.

Panel lamp indicator: Alarm 1(AL1), Alarm 2(AL2), Analog output(OUT);

4 no.s of Press-buttons to modify the inner menu.Friendly operation interface, easy to learn.

Anti-shake parameter designing to ensure better performance

Panel press-button RST & terminals RST in the backside to reset.

Boot automatically reset

Strong anti-interference ability, suitable for industrial field. Its widely used in various automatic

        control for build-in filling dosing weighing control system/load scale in industrial of Cement,

         Food packing,Chemical,etc..



2, Specifications



Model no.: LM8E-VRD

Dimensions: 96W×48H×80L mm

Input Signal:1 ~4 no.s of load cell

Analog output:0-10V DC

Ouput: 1 no.s of relay output----for control output:H/L alarm or slow/fast control

Aux. power:5V/80mA

Power supply:12V DC

Gross Weight: about 310g





3, Technical Parameters



Power supply:12V DC/120mA

Work environment: 0~50°C10~85%RH(No condensate)

Digital display: 4 digits red LED display, range:-1999~9999

u Analog output:0-10V DC

Control output: 1 no.s of RELAY, capacity: AC 250V/5A,resistance load,

Isolation resistance:100MΩ(DC 500V  between terminal and outer-shell)

Compression strength: AC 1500 1min(DC 500V between terminal and outer-shell)

Aux. Power:5V/80mA,(4 load cells input at most)

Sampling speed:16 times/sec.

Accuracy:0.1%FS



4, Functions for choice



  •  Analog output:0-10V / 4-20mA
  •  Communication interface: RS232 / RS485
  •  Input signal: 0-10V / 4-20mA
  •  Control output: SSR/RELAY/0-10V DC/4-20mA



5, Diagram(subject to that in the real item)

6,More choices





Packaging & Shipping





1.The complement packing contains 1 meter, 1 manual and 1 pair of brackets.

2.Items are usually shipped within 3 to 15 business days after payment has been received, which according to the quantities.

3.Shipment is by Sea, Freight or Courier(DHL/FEDEX/TNT/UPS/EMS/CHINA POST MAIL) as per clients request.





Our Services



  • We provide 18 months warranty for all Mypin products.
  • OEM / ODM service available to meet up to client's requirements
  • Any questions, please mail or call us any time






Company Information



Main product:Panel Meter

                     Counter

                     Weighing indicator

                     Temperature/Humidity Controller

                     Current/Voltage/Power meter,various sensor indicator

                     Frequency / Tacho / Batch / Length /Linespeed Meter

                     Flow / Level /Pressure Controller

                     Proximity/ Photoelectrical Switch

                     Timer,Timer Relay

                     Sensor Controller

                     Signal adjustor

  They are widely used in industrial control and measurement field, such as machinery, electrical cabinet, power sub-station, industrial automation, etc..



  Additonally,OEM service,Design service offer, Buyer laber offer.
