Mypin brand Load cell input weight controller with relay outputLM8E-RRD-12V

  • 1-9 Pieces
    $38.00
  • 10-99 Pieces
    $37.00
  • >=100 Pieces
    $36.00
Type:
Floor Scale Hanging Scale Lift Truck Scale Pocket Scale Truck Scale Mechanical Scale
Rated Load:
9999
Accuracy:
1g/1000g
$
- +
available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
5 day(s) after payment received
Customization:
Customized logo (Min. Order: 100 Pieces)
Customized packaging (Min. Order: 100 Pieces)

More

Graphic customization (Min. Order: 100 Pieces) Less
Contact Supplier
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China
Brand Name:
Mypin
Model Number:
LM8E-RRD
Power Supply:
12V DC
Display Type:
4 digits LED display
Product name:
Mypin weight controller
Feature:
relay output weight controller
Dimension:
48*96*80mm
Power consumption:
<5VA
Sampling speed:
16 times/sec.
Alarm output:
relay
Power:
12V DC
Accuracy:
0.1%
aux power:
5V/80mA
Warranty:
18 Months

Packaging & Delivery

Selling Units:
Single item
Single package size:
10.5X5.5X11.0 cm
Single gross weight:
0.35 kg
Package Type:
each pieces packed in box lined with plastic bag, then every 50 box in carton
Picture Example:
package-img
Lead Time :
Quantity(Piece) 1 - 10 11 - 100 >100
Est. Time(days) 5 7 To be negotiated
Video Description

Mypin brand Load cell input  weight controller with relay output   LM8E-RRD-12V



Product Description



1, Features available



 input:1-4 pcs load cells,force load cells



0.8" inch  red LED 4 digits measurement,0.1%F.S..

     Fast response, stable display, with Tare weight clearance function.

 RS232/RS485 MODBUS RTU interface for your

    choice, which enables to connect with other indicator,PC or PLC.

Signal input and analog output are digitally transferred automatically. Analog range set

    freely by user.

Panel lamp indicator: Alarm 1(AL1), Alarm 2(AL2), Analog output(OUT);

4 no.s of Press-buttons to modify the inner menu.Friendly operation interface, easy to learn.

Anti-shake parameter designing to ensure better performance

Panel press-button RST & terminals RST in the backside to reset.

Boot automatically reset

Strong anti-interference ability, suitable for industrial field. Its widely used in various

     automatic control for build-in filling dosing weighing control system/load scale in industrial

     of Cement,Food packing,Chemical,etc..



2, Specifications



Model no.:LM8E-RRD-12V

Dimensions: 96W×48H×80L mm

Input :1 ~ 4 no.s of load cell

Ouput: 2 no.s of relay output----for control output:Hghg/Low alarm or slow/fast control

Aux. power:5V/80mA

Power supply:12V DC

Gross Weight: about 300g





3, Technical Parameters



Power supply:12V DC,Power consumption≤5VA

Work environment: 0~50°C10~85%RH(No condensate)

Digital display: 4 digits red LED display, range:-1999~9999

Control output: 2 no.s of RELAY, capacity: AC 250V/5A,resistance load,

Isolation resistance:100MΩ(DC 500V  between terminal and outer-shell)

Compression strength: AC 1500 1min(DC 500V between terminal and outer-shell)

Aux. Power:5V/80mA,(4 load cell input at most)

Sampling speed:16 times/sec.

Accuracy:0.1%FS



4, Functions for choice



  •  Analog output:0-10V / 4-20mA
  •  Communication interface: RS232 / RS485
  •  Input signal: 0-10V / 4-20mA
  •  Control output: SSR/RELAY



5, Diagram(subject to that in the real item)

6,More choices



Packaging & Shipping





1.The complement packing contains 1 meter, 1 manual.

2.Items are usually shipped within 3 to 15 business days after payment has been received, which

   according to the quantities.

3.Shipment is by Sea, Freight or Courier(DHL/FEDEX/TNT/UPS/EMS/CHINA POST MAIL) as per

    clients request.
