Peltier Thermoelectric Air Conditioner 100W/200W/300W/400W

  • 1-9 Sets
    $185.00
  • >=10 Sets
    $180.00
Model Number:
FD
Power:
48V
$
- +
available
24V
$
- +
available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
3 day(s) after payment received
Customization:
Customized logo (Min. Order: 100 Sets)
Customized packaging (Min. Order: 100 Sets)

More

Graphic customization (Min. Order: 100 Sets) Less
Samples: $180.00 /Set, 1 Set (Min. Order): Buy Samples
Contact Supplier
Samples - $180.00 /Set, 1 Set (Min. Order): Buy Samples
Loading... Add To Cart
Report Suspicious Activity
Overview
Quick Details
Type:
Peltier Air Conditioner
Mounting:
Optional
Warranty:
3 years
After-sales Service Provided:
Free spare parts, Engineers available to service machinery overseas
Place of Origin:
Guangdong, China
Brand Name:
FuDi
Certification:
RoHS
Operating Voltage:
DC24V
Condition:
New
Applicable Industries:
Hotels, Building Material Shops, Machinery Repair Shops, Farms, Restaurant, Home Use, Energy & Mining
Key Selling Points:
Long Service Life
After Warranty Service:
Online support
Local Service Location:
None
Showroom Location:
None
Cooling Capacity:
35-400W
Voltage:
DC12/24V
Current:
5-21A
Operating Temp:
-10℃--+70℃
Weight::
1.1-8 Kg
Life-Span:
80,000 working hours

Packaging & Delivery

Selling Units:
Single item
Single package size:
30X31X15 cm
Single gross weight:
11.0 kg
Package Type:
Carton box or Customized packaging
Picture Example:
package-img
Lead Time :
Quantity(Sets) 1 - 10 >10
Est. Time(days) 3 To be negotiated

Advantages:

  • Our R&D team has been working in this industry more than 20 years.
  • The products perform steady, efficient and long-span.



Peltier Mini Industrial Thermoelectric Cooler (For TEC etc. Cabinet)



Scope:

Thermoelectric cooler can be widely developed for enclosed area climate control such as telecom, industrial, medical,military and aerospace application areas.



Working principle:

Thermoelectric coolers operate by the Peltier effect (which also goes by the more general name thermoelectric effect). The device has two sides, and when DC current flows through the device, it brings heat from one side to the other, so that one side gets cooler while the other gets hotter. The "hot" side is attached to a heat sink so that it remains at ambient temperature, while the cool side goes below room temperature. In some applications, multiple coolers can be cascaded together for lower temperature.



  Features:

  • Using semiconductor electronic cooling, small volume, light weight.
  • No compressor, no Freon, no pollution, no vibration, no leak.
  • Using no pollution material, compliance RoHS
  • Free mounting, applicable to a variety of places.
  • Working ambient temperature: -10C~+50C
  • Dense fin extrusion heat sink, high efficiency
  • High-dense foam insulation between heat sink and cooled heat sink.
  • Hot-side heat sink overheat protection temperature setting +75C± 5 C
  • Applied in sealing, vibration or rotation places such as compressors do not work.



Specificates:

Item(Th=35℃) Description
Hot SideFan Cooling
Cold SideFan Cooling
Qc max.(W)500W at Dt=0(℃)
Rated PowerDC24V, 40A
Working Temp.-10 ~ 70℃
Temp.ControlOptional





Product Advantages:

  • Small size
  • Immediate effect of cooling / heating
  • Achieves low temperatures
  • Easy power control
  • Silent operation
  • Long life (theoretically unlimited)
  • Can direct cooling to a very small area
  • Combination of cooling and heating

Product Applications:

  •  Battery cabinet in telecom
  •  Precise instrumentation
  •  Precise temperature control
  •  Photonics laser systems
  •  Food and Beverage cooling
  •  Medical instrumentation

Tecnical Manual:

1.Please use 12VDC switching power,and the ripple factor is less than 10%.

2.Don't drop from than 30cm height,the Bi2Te3 will be damaged,

3.Not waterproof,only aplied in indoor or outdoor of rainscreen.(Except IP55)

4.Please keep away from wall or other objects more than 10cm,when install it.

5.No starting up,when the ambient temperature and the heat sink over 70C,or it will be damaged.

6.Please read the specification and other accessories carefully.



Fudi prides itself on being dedicated to providing high-quality standard and customized thermoelectric coolers and superior customer service.



More details,pls contact us without hesitation!
