Professional portable baofeng R5 long range walkie talkie ham radio

Feedback Ratings
US $50.00 / Piece | 10 Pieces (Min. Order)
Color:
US $50.0
- +
available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
5 day(s) after payment received
Contact Supplier
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Fujian, China (Mainland)
Brand Name:
baofeng
Model Number:
R5
Type:
Handheld
Dimensions:
160*43*143mm
Frequency Range:
136-174MHz 400-470MHz
Storage Channel:
16 Channels
Talk Range:
5-10km

Packaging & Delivery

Selling Units:
Single item
Single volume:
60 cm 3
Single gross weight:
1.0 KG
Lead Time :
Quantity(Piece) 1 - 328 >328
Est. Time(day) 5 To be negotiated
Product Description

Baofeng Walkie Talkie BF-R5 Cheaper Two Way Radio Wireless Fm Portable Radio

Common Index Model: BF-K5
Frequency Range 136-174MHz 400-490MHz
Rated Voltage DC 7.2V
Memory Channel 2*128
Channel Spacing 12.5KHz/25KHz
Frequency Sensitivity ±2.5PPM
Antenna Impedance 50Ω
Dimension 109*54*34mm

TRANSMITTER
Output Power 5w
Current ≤1.5A
Modulation Distortion <5% (300-3000Hz)

Maximum Frequency Deviation <5kHz / < 2.5kHz
CTCSS Frequency Deviation 0.75KHz±50Hz
Spurious Radiation ≤7uW
Modulation Mode FM(16KøF3E/11KøF3E)
Remanent Radiation ≤-35dB

RECEIVER
RF Sensitivity 0.25uV
Silent Sensitivity 0.2uV
Audio Frequency Power ≥500mW
Audio Distortion <10%
Spurious Rejection ≥55dB
Adjacent Channel Selectivity ≥65dB ≥60dB
Intermodulation Reject Ratio ≥60dB ≥55dB








Related Products

            M598

                M68


              M-UV1

Our Company

Guangzhou minxing communication equipment co., LTD. Was established in 2008. The company has developed its own products and has deep professional wireless communication solution design strength.
The company is committed to the design, provision, secondary development of relevant products, and engaged in the wholesale and retail of various brand walkie-talkies and vehicle-mounted platforms
Minxing communication co., LTD. Is an individual proprietorship enterprise which integrates production, processing, wholesale and investment agent.
Adhering to the concept of "integrity management", the company has established a long-term and stable cooperative relationship with many enterprises and many taobao online sellers with reasonable price and excellent service.
It can also provide the quality services such as typing, labeling and customization.Warmly welcome all circles to visit, inspect and negotiate business.

Certifications
Packing & Delivery

Packing

We use double - layer packing

Delivery

Shipped in 5 days after payment.

FAQ

1.Are you factory?
We promise we are the factory, and our factory was founded in 2016, we also have our own design team. We have design products by ourselves.

2.Do you have any certification?
Sure, our product passed CE, and we also have our own patents.

3.May i custom roducts?
Of course, we can provide OEM and ODM service according to your design and your standard to make the products.

4.What's the MOQ of OEM?
We can accept any quantuty but the price will be different.

5.Can you offer a sample?
Yes, we can send you sample, but you need pay the shipping fee. Sometimes, we will charge you for a part of the samples' cost . As there are to many people asked for free samples.
