Rotate 360 degree camera for underwater well SD-1070A

FOB Reference Price:Get Latest Price
US $1,500-5,000 / Set | 1 Set/Sets (Min. Order)
Supply Ability:
200 Set/Sets per Month
Shenzhen Port
Report Suspicious Activity
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
Shenzhen Schorder
Model Number:
Well camera
Pan / Tilt / Zoom
Special Features:
Waterproof / Weatherproof
CCD type:
Sony CCD
Camera Horizontal resolution:
480 TVL
Camera head:
70mm Rotate 360 degree head
Display size:
8 inch LCD display
Display resolution:
100-2000m optional
Memory card:
Camera housing material:
stainless steel
12 months
Packaging & Delivery
Packaging Details
3 cases + One carton with foam / set
Delivery Time
7 days

Rotate 360 degree camera for underwater well SD-1070A









Well camera is able to capture video images in a timely manner of high-tech electronic equipment, the product system consists of cameras, transmission cables, the host control box, optical encoder, electric winches, recorders and other equipment. It has a waterproof, resistant to high pressure, high temperature, etc., but also hassimple operation, data is large, clear image, real time image monitoring, collecting, recording, arbitrary zoom, while the far and near the scene auto focus, able to show clear picture of available hard disk or CD-ROM to save monitoring data.Especially in the dry hole and clean water hole conditions, can real-time access to very clear color images, for a variety of holes to provide a reliable basis for incident handling, has a unique visual and authenticity. The product is mainly used for hole formation structure of the division, wall cracks and karst formations discrimination cases to distinguish fractured development zone, to determine the location and distribution of karst hole long-term monitoring and other aspects of work, underground TV in the vertical drilling , horizontal drilling and drilling in an arbitrary
angle monitoring.


Underground TV repair works mainly in casing breakage, falling objects wells, treatment pore blockage detection, it can be real shooting burning deep well casing and the casing wall damage and leaking, etc and will be photographed a clear image using its supporting a special cable to the monitor.


The product is used borehole maintenance, maintenance, repair, cleaning, can be accurate, fast, intuitive, clear and true judge wall abnormalities and location. From the economic aspect of analysis, the use of the product for the detection of bad wells can
reduce costs, reduce unnecessary expenses.






Underground TV is expanding the range of applications, the current system is not only used in the drilling and wells hydrologic restoration work, in the oil fields, coal fields, the field of engineering geology has also been widely used, can also be used in dams and reservoirs maintenance and marine engineering and other underwater operations.







TV system : PAL / NTSC optional


1.   70mm rotate 360 degree camera head
2.   Camera size: 70mm(diameter) * 100mm(length)
3.   Camera angle: 45 degree-60 degree
4.   Image sensor: 1/3 CCD
5.   Resolution: 480TVL
6.   Sensitivity: 0.1LUX
7.   Pixel: 720*576
8.   Camera housing material: stainless steel
9.   Grade: military

10. Display: 8 inch LCD display
11. Working temperature: -10celsius to + 55celsius
12. Power: AC 220V
13. Frame rate: 25 frame / second
14. Light source: 3W and 4.5W LED lights
15. Best inspection diameter:10-25mm
16. 100-2000m watertightness cable optional
17. CD writer and 10 pcs CD
18. Downhole pulley
19. Meter counter
20. Manual winch






70mm Pan and tilt Camera head










Cable reel with manual winch






8 inch LCD Display  controller










Offer 10 pcs CD




Meter counter




Packing : Three cases + one carton with foam
