Slamtec RPLIDAR A3 360 degree Laser Scanner (25 m)

Feedback Ratings
  • 1 Sets
    US $599.00
  • >=2 Sets
    US $565.00
Quantity:
- + Sets available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
30 day(s) after payment received
Contact Supplier
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
China (Mainland)
Brand Name:
SlAMTEC
Model Number:
RB-13K255

Packaging & Delivery

Selling Units:
Single item
Single package size:
15X9X11 cm
Single gross weight:
1.0 KG
Package Type:
Standrad Box
Lead Time :
30

Description

The sample rate of Slamtec RPLIDAR A3 360° Laser Scanner (25 m) directly decides whether the robot can build map quickly and accurately. RPLIDAR A3 improves the internal optical design and algorithm system to make the sample rate up to 16000 times, which is much better than most competitors. With algorithm optimization, the ranging radius of RPLIDAR A3 has been increased to 25 meters, which means more environment outline information is to be collected.



RPLIDRA A3 supports to work under two modes alternatively: enhanced mode and outdoor mode. In enhanced mode, RPLIDAR A3 works with the maximum ranging radius and sampling rate to realize an optimistic mapping performance in indoor environments. While in outdoor mode, RPLIDAR A3 works with a more reliable resistance to daylight interference. It keeps its stable performance when detecting white and black objects. The ranging core of RPLIDAR A3 runs clockwise to perform a 360 degree omnidirectional.



The A3 adopts laser triangulation ranging principle, and with high-speed RPVision ranging
Engine, it measures distance data and then generates an outline map for the environment. With the carefully designed parts and internal mechanical system, the RPLIDAR A3 keeps its
exceptional performance within its 4-cm thick compact size. It is ideal for all kinds of
service robots.

Specifications

Application Scenarios:

  • Enhanced Mode: Extreme performance Ideal for indoor environments with maximum ranging distance and sampling frequency.
  • Outdoor Mode: Extreme reliability Ideal for both outdoor and indoor environments with reliable resistance to daylight.
  • Distance Range: White object: 25 meters, White object: 25 meters, Black object: 10 meters,
  • Black object: 10 meters
  • Sample Rate: 16000 times per second, 10000 times per second
  • Scan Rate: Typical value: 15 HZ (adjustable between 10 HZ-20 HZ)
  • Angular Resolution: 0.3375°, 0.54°
  • Communication Interface: TTL UART
  • Communication Speed: 256000bps
  • Compatibility: Support former SDK protocols
  • 72.50mm x 41mm x 76mm

Packing List

  • 1 x Slamtec RPLIDAR A3 360° Laser Scanner (25 m)

pictures

RB-13K255 Rplidar A3(2)RB-13K255 Rplidar A3(3)

If you need the follow files,pls contact us.

PDF Files:

Slamtec RPLIDAR A3 360° Laser Scanner (25 m) Datasheet
Slamtec RPLIDAR A3 360° Laser Scanner (25 m) Introduction
Slamtec RPLIDAR A3 360° Laser Scanner (25 m) Interface Protocol
Slamtec RPLIDAR A3 360° Laser Scanner (25 m) Development Kit User Manual


GitHub:

Slamtec RPLIDAR A3 360° Laser Scanner (25 m) Link
