Strength Quality Machine Of Metal Chip Briquetting Press

FOB Reference Price:Get Latest Price
$10,000.00 - $30,000.00 / Sets | 1 Set/Sets metal chips briquetting press (Min. Order)
Model Number:
YQJ-650
Lead Time:
Quantity(Sets) 1 - 1 >1
Est. Time(days) 20 Negotiable
Report Suspicious Activity
Overview
Quick Details
Type:
Briquette Machines
Condition:
New
Production Capacity:
15 ton/h
Motor Type:
AC Motor
Power(W):
75 kw
Place of Origin:
Henan, China
Brand Name:
Lantian
Dimension(L*W*H):
as your required type
Certification:
CE, ISO
Warranty:
1 year
Name:
metal chip briquetting press
Color:
green, blue or as your needs
Diameter of roller:
650mm
Feeding materials:
coal, gypsum, iron, aluminum and others
Outlet diameter:
50-230mm
Capacity:
15 ton/h
Outlet shape:
round, oval, pillow,square and others
Material of roller:
durable steel, 65 Mn steel
Service:
equip production line
Featuers:
long life, high pressure,stable performance
After-sales Service Provided:
Engineers available to service machinery overseas
Supply Ability
Supply Ability:
100 Set/Sets per Month metal chips briquetting press
Packaging & Delivery
Packaging Details
Metal chip briquetting press: 1. Single machine will be packed in a standard wooden box with steel frame. 2. Bulk machines will be loaded in the container.
Port
Qingdao, Shanghai, Lianyungang, Tianjin
Lead Time :
Quantity(Sets) 1 - 1 >1
Est. Time(days) 20 To be negotiated



Strength Quality Machine Of Metal Chip Briquetting Press





Other hot selling machines in our factory:





Product Description



♥ Introduction:



1. The metal chip briquetting press is mainly pressing variety of sponge iron scrap, metal powder, ore powder and other materials into varienty of shapes, like oval ball shape, round ball shape, pillow shape, egg shape and others which can meet your requirements. Because of the forcible squeeze for the rollers, the outlet briquettes are of high density, and high hardness.

2. The rollers of metal chip briquetting press are made of durable materials like 65 Mn steel or others, and the hardness can be up to 50 celsius degree after dealing of special heating, which is of good wear resistance. The rollers can be replaced if they are damage in the process of working. Our metal chip briquetting press has the buffer device which can protect the machine avoiding the hard materials hitting.

3. Our this metal chip briquetting press, of high pressure, low electric consumption, usually is used for civil metalluragy, coal industry, refractory industry, industrial gasification and other industries.



ModelDiameter of RollersMain motorPre-pressurePressureType of pressureCapacityDimension
HYQJ-450450 mm45 kw11 kw100 thydraulic6 t/hcustomized
HYQJ-550550 mm55 kw15 kw110 thydraulic10 t/hcustomized
HYQJ-650650 mm75 kw18.5 kw110 thydraulic15 t/hcustomized
HYQJ-850850 mm90-155 kw22 kw120 thydraulic25 t/hcustomized
HYQJ-10001000 mm110-250 kw22 kw300 thydraulic25-30 t/hcustomized











♥ The structure:



1. Feeding system: ration feeding and ensure the iron powder go into the machine evenly.

2. Matched electric motor: electromagnetic speed regulation motor. It can maintain the constant feeding pressure to make sure the stable quality of outlet briquettes when the feeding efficiency of conveyor feeder is equal to the required amount of iron powder of main machine.

3. Transmission system: motor, V-belt, reduction gear, exposed gear and rollers.

4. Hydraulic protection device: when the machine working, the hydraulic pump drives the high pressure oil into the hydaulic cylinder to make the pistion axial displacement. Then the front connector of pistion rod will be on the bearing block, which can meet the requirements of production pressure.





♥ Working principle:



1. Through reducer simultaneously transmitted the power to two pressure rollers and made them rotated in opposite directions.
2. In two pressure rollers rotation, materials naturally enter into the ball molds on pressure roller and materials pressure vary from small to large with the rotation of the pressure roller.
3. When the material is rotated to two rollers line contact points, materials pressure has reached a peak.
4. Under enormous pressure, the powder materials are suppressed into finished ball.











♥ The pictures showcase:






Packaging & Shipping



♥ Shipping and packaging:



1. The single metal chip briquetting press is usually packed by standard wooden box with steel frame as the picture shows.

2. It also can packed according to your requirements.

3. If the machines are shipped and loaded in a container, they can not be packaged.

4. The metal chip briquetting press will be tested well before delivery.









Our Services



♥ Our Services:



1. Pre-sales service:
1). sales person, project manager, technology engineer, accountant staff.
2). pofessional responding team: would be very fastly and exactly to send you offer.
3). choose suitable iron scrap briquette machines and make producing plan according to the raw materials, final shapes and output capacity.
4). offer reasonbal price to meet your budget.
5). invite customers to our factory, demostrate the machines, let you know how the machine work, and compare the quality with other suppliers.
6). producing super and solid quality of machines.
7). arrange shipping and fastly delivery.
8). standard export package or as your requirements.
2. After-sales service:
1). assistance to build factory.
2). repairing and maintain if any problems occur in the warranty.
3). help for installation or clerk training, if necessary, dispatch technicians to your country to install the machines.
4). supply spare and wearing parts of our machines.
5). any feedback of our metal chip briquetting press can be told us, and we will try our best to support you.
6). technology knowlogy shares with you.
7). help for any other machine that we haven't.





Company Information



♥ Brief introduction of our factory:



Lantian Mechanical Plant is a professional factory to produce all kinds of briquette machines. It was founded in 1980s. Through 30 years' development, it stands out in briquette machine industry. Our briquette machines include ball press machine, honeycomb briquette machine, coal/charcoal extruder machine, shisha briquette machine, biomass briquette machine, brick briquette machine, pellet machine etc., and all necessary auxiliary machines. Apart from all kinds of briquettes machines, we also produce carbonization furnace, all kinds of crusher, dryer, mixer,etc.

We’ve got CE, ISO certificate for our machines. And our machines has been sold to Indonesia, Sadi Arabia, Malaysia, India, South Africa, Canada, Australia, Russia, Spain, Greece, Pakistan, Kuwait, Turkey, Egypt and others.





CE ISO Certificate:







Contact



♥ Contact information:



If there is any requirements, please contact me immediately.
