Tungsten stranded wire filament for vacuum coating

FOB Reference Price:Get Latest Price
$70.00 - $150.00 / Kilograms | 1 Kilogram/Kilograms (Min. Order)
Lead Time:
Quantity(Kilograms) 1 - 100 >100
Est. Time(days) 18 Negotiable
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Shaanxi, China (Mainland)
Brand Name:
Hanz
Model Number:
W1
Wire Gauge:
as request
purity:
99.95% min
density:
19.2g/cm3
melting point:
3410℃
boiling point:
5927℃
shape:
twist wire
chemical composition:
tungsten 99.95% min
grade:
W1, W2
surface finish:
hot working surface
application:
edm cutting
name:
Tungsten stranded wire filament for vacuum coating
Supply Ability
Supply Ability:
2 Ton/Tons per Month stranded tungsten wire
Packaging & Delivery
Packaging Details
Vacuum package to prevent oxidation during transportation and storage or as your request for Pure tungsten stranded wire.
Port
Tianjin, Qingdao, Shanghai,Shaanxi
Lead Time :
Quantity(Kilograms) 1 - 100 >100
Est. Time(days) 18 To be negotiated
Product Description

1. Product DetailsTungsten stranded wire filament for vacuum coating

 2. Product DescriptionTungsten stranded wire filament for vacuum coating

Tungsten has a high melting point, high resistivity, good strength, and low vapor pressure and is suitable for use as a heater.The film material is placed in a heater in a vacuum chamber, and under high vacuum conditions, it is heated by a heater(tungsten twisted wire) to evaporate it.



When the mean free path of vapor molecules is larger than the linear dimension of the vacuum chamber, the atoms and molecules of the vapor escape from the surface of the evaporation source and are rarely impacted or obstructed by other molecules or atoms.



Its can be directly reached on the surface of the substrate being plated. The substrate has a lower temperature and condenses into a film.

NameTungsten stranded wire filament for vacuum coating
MaterialPure tungsten and tungsten alloy
 Surfaceblack, sliver, bright, chemical cleaning or electrolytic polishing
ApplicationVacuum Metalizing, Heating Components, Filament, Electric Light Source
Dimension Range

Single wire diameter:0.3mm to 1.5mm

How many tungsten wire twisted together:3-4 wires is popular, 300 wires max.

How to get a Quotation?

1.Single tungsten wire's diameter:0.8mm?

2.How many tungsten wire twisted together:1, 2, 3 or 4 wire?

3.Application details:?

4.Is there any others request about performance:?

5.Details drawing!

Product Show

1. Product ShowTungsten stranded wire filament for vacuum coating



2. Advantage&ApplicationTungsten stranded wire filament for vacuum coating

       Advantage

           Advantages of Stranded tungsten wire elements:

  • High melting point
  • high corrosion resistance
  • Good stability
  • Low cost, long service life
  • High rates with low power
  • Repeatability and easy of use.



  • Application
  • Vacuum Metalizing (picture tubes, mirrors, plastics, metal substrates, ABS, PP materials)
  • Heating Components
  • Filament
  • Electric Light Source



3. Style DescriptionTungsten stranded wire filament for vacuum coating

The size of twisted tungsten wire can be customized according to customer drawings or requirements

Packaging & Shipping

1. TestingTungsten stranded wire filament for vacuum coating

2. Packaging

Packing Details  : Plastic bags and kraft paper as inside, wooden case as outside.

Delivery Details : 3-15 working days after order of twisted tungsten wire.

The package of pure tungsten twisted wire is very professional, careful and safety.

3.Shipping

We will choose the fastest ,cheapest and safest shipment way for you, such as Express, air transportation and sea transportation.



 Before delivery, the pictures of finished products ,packaging details and MTC will be send to our customer, When the customer satisfied with our product, we will promptly deliver goods. There is no deception, the pictures you see are consistent with the goods you receive.

Related Products

       Any new inquiry, welcome to here, we would like to quote to you as a referance.

Our Company

We are committed to this industry for 11 years and can be trusted professional suppliers of tungsten and molybdenum products,We are capable of completing the order tasks according to quantity and customer requirements.



After sale & FAQ

After sale service:

1.When customer finished payment, termly inform the progress of production
2.After delivery, tell customer tracking number, focus on transport steps, inform customer each important step
3. Customer can contact us in any case, need not worry any latent risk, any problems, instruct the customer to solve, by email, telephone, video and so on.
4.Once the tungsten twisted wire or tungsten stranded wire product have quality problem, re-delivery the qualified products to customer or refund.

5.According to different customer groups, help customers make plans and open target market

6.We can solve problems, solve customers' worries, and make business easy, because We are committed to this industry for 11 years and can be trusted professional suppliers of tungsten twisted wire or tungsten stranded wire.



FAQ:

1.Are you able to provide samples? MOQ?

Yes, we can supply you free sample of tungsten twisted wire.  MOQ:1kg

2.What's your best-selling size?
Single wire diameter 0.6mm or 0.8mm, 3 or 4 tungsten wires strand together.

3.Do you accept customed?
Yes, we can according to your application or drawings processing.

4.What's your shipment term?
DHL, UPS, TNT, FedEx, SF-Express, Deppon, EMS, 5-8 days will arrived.

5.What is the shipping cost?
It mainly depends on weight, volume, packing size and destination port.

Best-selling Style

1. Best-Selling Style





Why Choose us?

Why choose us?

Professional reliable, work hard, patience with customers, Let the customer really experience to rest assured, intimate, and save worry new services.

We are confident that once you choose us one time, you will follow us forever.



Do you want to have a fantastic order experience?

Do you want to get a sample?

Any of the following ways can contact me:





B

Baoji Hanz  Metal Material Co., Ltd.



Sales: Renee



China Tel: +86-917-3258886



ChinaFax: +86-917-3258889



Email:baojihanz-06(@)hanztech.cn



Wechat /Skype:13892489913



Cell:+86 18729724492
