Underwater neutrally buoyant umbilical tether cable for ROV vehicle

Feedback Ratings
  • 100-999 Meters
    $1.00
  • 1000-4999 Meters
    $0.95
  • >=5000 Meters
    $0.92
Quantity:
- + Meters available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
10 day(s) after payment received
Customization:
Customized logo (Min. Order: 10 Meters)
Customized packaging (Min. Order: 10 Meters)

More

Graphic customization (Min. Order: 10 Meters) Less
Contact Supplier
Samples - $100.00 /Meter, 1 Meter (Min. Order): Buy Samples
Loading... Add To Cart
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Jiangsu, China (Mainland)
Brand Name:
KaiMei cable
Model Number:
KaiMei ROV
Insulation Material:
PE
Type:
Low Voltage
Application:
Oil resistant
Conductor Material:
Multi-core
Jacket:
PUR
Product Name:
Underwater neutrally buoyant umbilical tether cable for ROV vehicle
PUR cable Color:
Black,Red,Yellow,Blue,
Conductor:
Multi-core
Insulating layer Color:
Red, yellow, blue, green, black, brown, white and grey,,,,
Insulating material:
PVC/PE/F46/PP/TPV/TPE
Jacket material:
PUR/TPEE/PA/PVC
PU performance:
Oil resistance, abrasion resistance, acid and alkali resistance
working temperature:
-40℃--+85℃
Packing requirements:
export carton
Carton Size:
450*380*380mm

Packaging & Delivery

Selling Units:
Single item
Single package size:
200X200X200 cm
Single gross weight:
0.1 kg
Picture Example:
package-img
package-img
Lead Time :
Quantity(Meter) 1 - 1000 >1000
Est. Time(days) 10 To be negotiated

No.
kAIMAIRVUT0265
Voltage
300/500V
Spec.
  cores
Application
Underwater neutrally buoyant umbilical tether cable for ROV vehicle
Cable diameter.
  mm+-1mm
Certification
CE, ISO9001
Conductor material
Bare copper
Torsional

Color
Black/Yellow/blue/green/white/black and TBD
Shield
No
Insulation
PUR
Inner sheath
No
Tensile structure
High tensile strength of Kevlar fiber
Wrapping material
 Quality non-woven
Outer sheath
Import PUR
Temperature range
Fixed laying: -40℃~+90℃. Move installment: -30℃~+80℃



https://www.alibaba.com/product-detail/spiral-cable-PVC-PU_60696117587.html?spm=0.manage.list.4.793b47c9c5RXWR

Our products are bulk pakced in carton boxes and put on palllets, each standard box for metal parts is max 15-18kg. Small bag package or speical packing way can be done if required, but with extra costs.
UPS, Fedex, DHL or TNT are possible to use for express service, cost depends on weights and volumes of the shipments.






Spiral Cable
Structure & Specifications:
Conductor: multi-strands copper wire, 7- core 7 * 1.5 mm2
Insulation material: PVC/PE/PP
Sheath material: PU/TPU/PA/PVC
Diameter: 13.5mm
Expanding length: 1.0 m-25.5m
Color: black
Operating temperature: according to customer requirements, cold -65 degrees; temperature 80 degrees, 105 degrees, 125 degrees
Spring Length: arbitrary (customized according to customer requirements)
Good flexibility and elasticity
Elongation length of up to 3.5-4 times the original length of spring. Have good cold resistance, flame resistance, oil and abrasion resistance. Occasions according to different requirements of production of various kinds of spiral-type spring line.
Application:
For rated AC voltage 300/750V or DC voltage 6V-1000V below the required back and forth up and down movement of aggregate assembly circuit wiring.
We are professional and manufacture all kinds of coiled cord, spiral cable, spring cord, retractable wires. We can provide good quality with competitive price.
