Vacuum heating equipment plasma nitriding furnace with Programmable Controller

FOB Reference Price:Get Latest Price
$15,000.00 - $35,000.00 / Sets | 1 Set/Sets (Min. Order)
Model Number:
LD-30A Nitriding furnace
Lead Time:
Quantity(Sets) 1 - 1 >1
Est. Time(days) 65 Negotiable
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Type:
Arc Furnace
Usage:
Heat Treatment Furnace
Place of Origin:
Hunan, China (Mainland)
Brand Name:
Samy
Voltage:
380V
Dimension(L*W*H):
950*850*3500
Weight:
3500kgs
Certification:
ISO certification
After-sales Service Provided:
Free spare parts, Field installation, commissioning and training, Field maintenance and repair service, Video technical support, Online support, Engineers available to service machinery overseas
Model:
LD-30A Nitriding furnace
Name:
Ionic Nitriding furnace
Output max voltage:
30A
Maximum loading weight:
300kgs
The arc velocity:
≤ 15 second
Frequency:
1000HZ
Control method:
PID control
Occupy space rate:
0-85% continue adjustable
weight:
3500kgs
Power(W):
1KW
Supply Ability
Supply Ability:
20 Set/Sets per Month
Packaging & Delivery
Packaging Details
Export wooden package.
Port
Any Chinese Port
Picture Example:
package-img
Lead Time :
Quantity(Sets) 1 - 1 >1
Est. Time(days) 65 To be negotiated
Product Description

Vacuum heating equipment plasma nitriding pdf with Programmable Controller





Industry pulse nitriding furnace

Product Detail

ModelLD-30A Nitriding furnace
NameIonic Nitriding furnace
Output max voltage30A
Max loading weight300kgs
The arc velocity≤ 15 second
Frequency1000HZ
Control methodPID control
Occupy space rate0-85% continue adjustable
CertificationISO
weight3500kgs
Product Keywordsplasma nitriding pdf

Nitriding furnace introduce:
Glow ionic nitriding furnace includes ionic triding and lon-carbonitriding .glow ionic nitriding furnace can significantly enhances the surface hardness of steel parts,resistance to damage,fatigue and corrosion;because it has the advantages for energy saving, save gas, high efficiency, good quality, no pollution, etc. It has been applied widely in power, machine tools, petrochemical machinery, textile machinery, mold and other industries.

LDMC series pulse power control system main feature

Main circuit of LD, ldmc series power supply system adopts two groups of three-phase half controlled bridge rectifier circuit in series, three-phase rectifier circuit uses modular design, integrated installation; chopper with high power IGBT chopper circuit, over discharge voltage detection circuit and automatic starting circuit and match the current cut-off feedback and current limiting feedback device; using integrated circuit thyristor double pulse phase shift trigger circuit.

LDMC Pulse glow ionic nitriding furnace:

Glow ionic nitriding furnace features:

Main specification:

Vacuum furnace body:

Detail description

Model

LD(MC)-30

LD(MC)-50

LD(MC)-75

LD(MC)-100

LD(MC)-150

Maximum average output current

30A

50A

75A

100A

150A

Maximum peak output current

60A

100A

150A

200A

300A

Max nitride area

60000cm2

100000cm2

150000cm2

200000cm2

300000cm2

Max loading weight

300kgs

500kgs

800kgs

1200kgs

2000kgs

Output supply

30KW

50KW

75KW

100KW

150KW

Output status

Rectangular web

Frequency

1000HZ

The arc velocity

≤20 Microsecond

Control method

Fixed frequency width

Occupy space rate

0-85% continue adjustable

Model

LD(MC)-30

LD(MC)-50

LD(MC)-75

LD(MC)-100

LD(MC)-150

Working chamber

Ø600*800

Ø700*1000

Ø900*1200

Ø1200*1500

Ø1500*1500

Max Working temperature

650

Common working temp

500±50

Ultimate vacuum

≤6.7Pa/30Min

Pressure rising rate

≤0.13Pa/min
