Walkie Talkie Bluetooth Motorola XPR7550/DP4801

  • 1-9 Pieces
    $468.00
  • >=10 Pieces
    $443.00
Color:
- +
available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
10 day(s) after payment received
Customization:
Customized packaging (Min. Order: 500 Pieces)
Contact Supplier
Samples - $468.00 /Piece, 1 Piece (Min. Order): Buy Samples
Loading... Add To Cart
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Fujian, China
Brand Name:
Motorola
Model Number:
XPR7550
Type:
Handheld
Dimensions:
130.3*55.2*41.1mm
Frequency Range:
136-174MHz/403-527MHz
Storage Channel:
1000
Talk Range:
3-5kms
Product Name:
Motorola XPR7550
Output Power:
VHF 5W UHF 4W
Operating Voltage:
7.4V
Battery capacity:
1400mAh
Weight:
365.5g
Channel Spacing:
12.5KHz/20KHz/25KHz
Working Voltage:
6.5V~8.4V(Standard 7.4V)
Warranty:
12 Months
Battery type:
Li-ion Battery 1400mAh
Radio Type:
DMR Professional Radio

Packaging & Delivery

Selling Units:
Single item
Single package size:
27X20X15 cm
Single gross weight:
1.5 kg
Package Type:
1 box with 1pc antenna,1pc battery,1pc charger,1pc adapter
Picture Example:
package-img
Lead Time :
Quantity(Piece) 1 - 100 >100
Est. Time(days) 10 To be negotiated
Products recommended
Walkie Talkie Bluetooth Motorola XPR7550/DP4801



specifications
 Model NumberXPR 7550
GENERAL SPECIFICATIONS

 Band



136-174MHz

350-400MHz

430-512MHz

 High Power Output

5W(136-174MHz)

4W(350-400MHz)

4W(430-512MHz)

 High Power Output1W(136-174MHz)

1W(350-400MHz)

1W(430-512MHz)

 Channel Spacing 12.5/25KHz
 Channel Capacity 1000
 Dimensions(HXWXD)130.3*55.2*41.1mm
 Weight(Radio + Standard 1600mAh Battery) 365.5g
 Digital/Analogue Battery Life(Standard 1600mAh   Battery) 11.5 - 16.0hrs
 Power Supply(Nominal) 7.5V
TRANSMITTER SPECIFICATIONS
 4FSK Digital Modulation

 12.5 kHz Oata:7K60FID and 7K60FXD
 12,5 kHz Voice:7K60FIE and 7K60FXE
 Combination of 12,5 kHz Voice and   Data:7K60FIW

 Digital Protocol ETSI TS 102 361-1,-2,-3
 Conducted/Radiated Emissions(TIA603D) -36dBm<1GHz, -30dBm>1GHz
 Adjacent Channel Power

 60dB(12.5KHz channel),

 70dB(25KHz channel)

 Frequency Stability ±0.5ppm
 AUDIO SPECIFICATIONS
 Digital Vocoder Type AMBE+2
 Audio Response TIA603D
 Rated Audio 0.5 W
 Audio Distortion at Rated Audio 3%
 Hum and Noise -40 dB (12.5 kHz channel), -45 dB (25 kHz channel)
 Conducted Spurious Emissions (TIA603D) -57 dBm
 ENVIRONMENTAL SPECIFICATIONS
 Operating Temperature -30 °C to +60 °C
 Storage Temperature -40 °C to +85 °C
 Electrostatic Discharge IEC 61000-4-2 Level 4
 Dust and Water Intrusion IEC 60529 - IP67
 Packaging Test MIL-STD 810D and E
