Wholesale concrete radiant floor heating mat twin conductor 100/150W per square meter

  • 10-99 Square Meters
    $15.00
  • 100-499 Square Meters
    $14.50
  • >=500 Square Meters
    $14.00
Material:
Anti-flammable PC
- +
available
Other
- +
available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
10 day(s) after payment received
Contact Supplier
Report Suspicious Activity
Overview
Quick Details
Color:
white, black, Red, white, Yellow,Green,Blue
Place of Origin:
Anhui, China
Brand Name:
AnBang
Model Number:
AB-DX-150-2.5
Type:
Floor Heating Parts
Floor Heating Part Type:
Floor Heating Mats
Conductor Material:
Copper Alloy
Insulation Material:
XLPE/FEP
Outer Jacket Insulation:
PVC
Application:
kitchen,bathroom, bedroom,office,living room indoor use
Size:
0.5 meter width, 1.0~45 meters length
Cover:
FEP/PVC
Shield:
Aluminum Foil
Diameter:
3--4mm
Certifications:
CE,ROHS,EAC,SGS,UL,,ISO9001

Packaging & Delivery

Selling Units:
Single item
Single package size:
10X10X10 cm
Single gross weight:
1.0 kg
Package Type:
1,If you want to save the freight,I suggest you use the regular package(White box and export carton) 2,If you want to protect the heating mat better,then,I suggest to use innner box first,and then put them in the carton. 3,If you sell goods in your own brand,then,I suggest you use the color box,which has your own design,such as logo and so on,then put these color box in cartons. Of course,the mat quantity will be different if you put different mat sizes in the cartons.
Lead Time :
Quantity(Square Meter) 1 - 100 101 - 200 201 - 500 >500
Est. Time(days) 10 15 20 To be negotiated
Product Introduction

Wholesale concrete radiant floor heating mat twin conductor 100/150W per square meter

Anbang's heating mat is a good heating system, it is easy to install and suitalbe for various floor decorative materials,whether it is concrete floor,wood floor,the old tiles floor or terazzo floor.It is installed in the tile adhesives and almost doesn't affect the floor elevation.Anbang's heating mat can be directly laid on the original floor without any treatment to the original floor.

Product Applications

Electric Floor Heating Mat for Home Heating

Anbang's heating mat is designed for installation into thin adhesivebeds, levelling compounds or thin screed beds beneath tiled and wooden floor finish.


100w/m2 underground heating mats provide a highly economical floor warming system and used to cover larger areas, 100w/m2 are to cover larger areas. 100w/m2 are not suitable as a primary heating source, only to be used as secondary heating for under tiled floors.

150W/m2 floor heating mats are suitable as a primary heating source providing you have adequate insulation. These are our most commonly used mats for kitchens, dining rooms, large bathrooms and most other areas with tiled floors.

200W/m2 floor heating mat is generally used in areas where high heat loss is a problem, such as conservatories. Indoor heating mats are only suitable under tiled floors, giving a 25% faster warm up time.

Product Parameters
AB-DX-150
Technical Data
Cable constrution
Twins conductor
Insulation
Fluoropolymer
Shield
Aluminum foil
Protective jacket
PVC
Connector
Out splice
Outside diameter
3-4mm
Voltage
110V/120V/220V/230V/240V
Available power
75w-2250w
Cold lines
one line of 2.5mm
Cable linear power
12w/m, 16w/m, 18w/m
Power output
150w/m2
Cable spacing
50mm/80mm (It can be customized)
FEP insulation
-200℃~260℃
Resistance tolerance
+10/-5%
OEM service
Large order or long term cooperate relationship provide the customized service
Sample
Available. just tell us the specifications

Payment terms negotiable
Delivery time
Normally within 7-15 days, large order should be negotiated.
Services
Free design and installation guide
Approval
CE,ROHS,EAC,SGS,UL,ISO9001
Product Details Show
Specifications
Model
Tota Power(watt)
Voltage(V)
Power(w/m)
Resistance(Ω)
Cable length(m)
Area m2
ABDX-150-0.5
75
230
12
705.30
6.25
0.5
ABDX-150-1.0
150
230
12
352.70
12.5
1.0
ABDX-150-1.5
225
230
12
235.11
18.8
1.5
ABDX-150-2.0
300
230
12
176.33
25.0
2.0
ABDX-150-2.5
375
230
12
141.07
31.3
2.5
ABDX-150-3.0
450
230
12
117.56
37.5
3.0
ABDX-150-3.5
525
230
12
100.76
43.8
3.5
ABDX-150-4.0
600
230
12
88.17
50.0
4.0
ABDX-150-5.0
750
230
12
70.53
62.5
5.0
ABDX-150-6.0
900
230
12
58.78
75.0
6.0
ABDX-150-7.0
1050
230
12
50.38
87.5
7.0
ABDX-150-8.0
1200
230
12
44.08
100.0
8.0
ABDX-150-9.0
1350
230
12
39.19
112.5
9.0
ABDX-150-10.0
1500
230
12
35.27
125.0
10.0
ABDX-150-11.0
1650
230
12
32.06
137.5
11.0
ABDX-150-12.0
1800
230
12
29.39
150.0
12.0
Product Packing
Why Choose Us

A.Punctual delivery time:

We promise your order will punctual delivery to you

Sample delivery time within 2 days, the order product delivery time within 15days

Shipping notice and photos sent to you as soon as your order is shipped.

B.After sales service:

We Pay high Attention To Your Feed back after receive the goods.

We Provide 12 months warranty after goods arrive.

We Promise All Parts Available in life time use.

We Positively Revert Your Complain Within 48hours.

C.Professional Sales:

We value every Inquiry Sent To Us, Ensure Quick Competitive Offer.

We Are A Sales Team, With All Technical Support From Engineer Team.

D.Product Logo:

We have professional engineers, and since the company was set up, we are professional in provide OEM and ODM service.


Our Certificates

Company Profile

Welcome to Anbang, built in 2004, Register capital to be a RMB103million. Anbang group is a professional production of various types of electric tracing cables enterprise, located in Tianchang City, Chuzhou, Anhui province, which is 110km far away from Nanjing Airport, Headquarters is located in Beijing world trade center. We are the leading enterprise in the field of electrical heating.


Our factory covers 63000 square meters and own more than 300 employees.Our enterprise through the ISO9001:2008 quality management system certification; ISO14000 environment management certification. The products have CE,ROHS,EMC certification,


We have advanced equipments, high technology and an excellent quality inspection system that strictly performs under the quality control of ISO9001. Our main products: electric heating cable; electric underfloor heating mats; self-regulation heating cable MI heating cable etc. are popular for indoor floor warm use and outdoor snow melting use; pipeline freeze protection. Our mainly markets for America, Europe, The Middle East and Asia neighboring countries.


The company has always attached importance to technical innovation and quality management, focus on the introduction of the outstanding talented person and the advanced equipment, now our products of high quality and because of its superior performance. We sincerely hope to establish business relations with customers from all over the world.



Frequently Asked Questions



1.Can I place a sample order first?

Yes, we will quote you different prices for small, medium and large quantity. You can order with different price for different quantity.



2.How to place the order?

Please send us your purchase order by e-mail, Trade Manager or Skype or you can ask us to send you a Proforma Invoice for your order.



3.What is the lead time for mass production after sample approved?

15 workdays after sample confirmed.



4.How to send us the products?

We usually use DHL, UPS, FedEX to ship samples. For bulk orders, we support shipping by air or by sea.



5.Can you do OEM and ODM for us?

Yes, we are professional in providing OEM and ODM service.We support both standard and customized products and can put your logo on the products. Our experienced R&D team will support technical questions.



6.What is your trading term? And what payment way are accepted?

We always do FOB term, and you could make the payment by T/T, Paypal,Western Union.So just tell us which is easier to you. Then we will send you our bank details. Or as your requirements.
