YE3-225M-6 IE3 3 phase squirrel cage induction 6 pole motor with CCC certificate transmission gearbox

FOB Reference Price:Get Latest Price
$40.00 - $1,300.00 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Jiangsu, China (Mainland)
Brand Name:
NANFANG
Model Number:
Frame 80-280
Output Power:
30kw
Type:
Asynchronous Motor
Frequency:
50HZ/60HZ
Phase:
Three-phase
Certification:
CCC, CE
Protect Feature:
Totally Enclosed
AC Voltage:
220V 380V
Efficiency:
IE 3
Product Name:
HIGH EFFICIENCY MOTOR
Rated Speed:
980 (r/min)
Voltage:
220/380V 380/660V 230/400V 400/690V 440V
Protection class:
IP45/IP54/IP55/IP67/IP77
Power:
30 kw
Structure:
IMB3/B5/B35/V1
Function:
Control
Winding:
100% Cooper Wire
Supply Ability
Supply Ability:
500000 Set/Sets per Year
Packaging & Delivery
Packaging Details
CARTONS OR PLY WOODEN CASES
Port
SHANGHAI


Changzhou Nanfang Motor Co., Ltd. (Herein after Nanfang) was established in 1992 with the registered capital of RMB 38 million.
Nanfang is one of the best motor manufacturers in China with annual capacity of 500,000 sets. It has an area of 30,000 square meters, over 220 staff including 26 professional technicians. Its major products are reducers-exclusive motor, YS series fractional horsepower motor, YE3 series and YX3 series high efficiency motor, YEJ series brake motor, YVP series variable frequency motor, YB3 series explosion-proof motor, YD series double-speed motor, aluminum-shell motors and other specialized motors. Nanfang motor has been certificated by IS0 9001 , 3C and CE since 2001.



YE3 series three phase ac electric asynchronous motor

SUPER HIGH EFFICIENCY
Comparing with YX3 series three phase motor, YE3 series motor has much higher efficiency, which is according to GB18613-2012 2 standard. It helps to save energy can be operated continuously.
ADVANTAGE
Beautiful appearance, energy saving, large starting torque, excellent performance, low noise, low vibration, and high reliability.

WIDELY USED
As drive of various kinds of machines, widely applied in industries including mechanical and electro-mechanical industry, food industry, textile industry and so on.



Product Description

Site conditionsMotors are suitable for most working environment at temperature from -15°C t0 +40°C and altitude below 1000 meters
InsulationThe motors' insulation system is set to Class F(105K), examined by Class B(80K), which ensure the life span and reliability of the motors.
Motor protectionMotors can be installed with PTC, PT100 used as winding and bearing temperature measurement on request.
Voltage and frequencyStandard voltage and frequency is 380V 50HZ, and can be set to any single voltage in the range of 200-660V at a frequency of 50 or 60HZ. The motors work well within variations of ±5% from the rated voltage.
VibrationMotors are designed to vibration class A, vibration class B is available on request.
DutyContinuous(S1)
Cooling and ventilationThe standard cooling method is totally enclosed fan cooled(TEFC) in accordance with IC411 of IEC60034-6. Standard motors are equipped with auxiliary plastic fans.
Winding100% Cooper Wire
Protection classThe standard protection class is IP54/IP55, which can be used in humid and dusty environment. Higher degrees of protection is available.
Quality assuranceFrom the first line of production designing till the finishing procedure, obey ISO9001 documented quality system.







1

Shaft cover11IP55 gasket21Ring for lightening
2V-ring12Mains power connection terminal block22Fan cover
3Motor clamping screws13Terminal block box- base23Motor indentification plate
4Spring ring14IP65 gasket24Motor indentification plate lightening screws
5Shield15Terminal block box- cover25B5 motor casing
6Bearing16Terminal block box- lightening screws26B5 flange
7Motor Shaft17Cable inlet bush27B14 flange
8Rotor18Compensation ring28Sealing ring
9Wound stator19Fan cover lightening screws

29

Shaft key
10Motor casing B3-B520PVC fan



SYNCHRONOUS OUTPUT SPEED=3000RPM FREQUENCY=50HZ VOLTAGE=380V

MODEL

POWER

(KW)

CURRENT

(A)

SPEED

(RPM)

EFF

POWER

FACTOR

RATED

TORQUE

TSTISTTMAX

NOISE

dB(A)

YE3-63M1-20.18kw0.53272063.90.80.632.25.52.261
YE3-63M2-20.25kw0.7272097.10.810.882.25.52.261
YE3-71M1-20.37kw12740690.811.292.26.12.262
YE3-71M2-20.55kw1.4274072.30.821.922.26.12.262
YE3-801-20.75kw1.8283080.70.832.52.272.362
YE3-802-21.1kw2.5284082.70.833.652.27.32.362
YE3-90S-21.5kw3.4284084.20.844.972.27.62.367
YE3-90L-22.2kw4.8284085.90.857.32.27.62.367
YE3-100L-23kw6.3287087.10.879.952.27.82.374
YE3-112M-24kw8.2289088.10.8813.12.28.32.377
YE3-132S1-25.5kw11.1290089.20.8817.928.32.379
YE3-132S2-27.5kw15290090.10.8924.427.92.379
YE3-160M1-211kw21.329309120.8935.628.12.381
YE3-160M2-215kw28.7293091.90.8948.628.12.381
YE3-160L-218.5kw34.7293092.40.896028.22.381
YE3--180M-222kw41.2294092.70.8971.228.22.383
YE3-200-L1-230kw55.3295093.30.8996.627.62.384
YE3-200L2-237kw67.9295093.70.8911927.62.384
YE3-225M-245kw82.12970940.8914527.72.386
YE3-250M-255kw100.1297094.30.8917727.72.389
YE3-280S-275kw134297094.70.892411.87.12.391
YE3-280M-290kw160.22970950.892891.87.12.391



SYNCHRONOUS OUTPUT SPEED=1500RPM FREQUENCY=50HZ VOLTAGE=380V

MODEL

POWER

(KW)

CURRENT

(A)

SPEED

(RPM)

EFF

POWER

FACTOR

RATED

TORQUE

TSTISTTMAX

NOISE

dB(A)

YE3-63M1-40.12kw0.451310rpm55.80.720.872.14.42.252
YE3-63M2-40.18kw0.641310rpm58.60.731.312.14.42.252
YE3-71M1-40.25kw0.811330rpm63.60.741.82.15.22.255
YE3-71M2-40.37kw1.11330rpm65.30.752.662.15.22.255
YE3-801-40.55kw1.41390rpm80.60.753.672.36.52.356
YE3-8002-40.75kw1.91390rpm82.50.755.012.36.62.356
YE3-90S-41.1kw2.71400rpm84.10.767.352.36.82.359
YE3-90L-41.5kw3.61400rpm85.30.77102.372.359
YE3-100L1-42.2kw4.81430rpm86.70.8114.62.37.62.364
YE3-100L2-43kw6.61430rpm87.70.8219.92.37.62.364
YE3-112M-44kw8.61440rpm88.60.8226.32.27.82.365
YE3-132S-45.5kw11.61440rpm89.60.8335.927.92.371
YE3-132M-47.5kw14.61440rpm90.40.8448.927.52.371
YE3-160M-411kw22.61460rpm91.40.8571.527.72.373
YE3-160L-415kw29.31460rpm92.10.8697.427.82.373
YE3-180M-418.5kw35.451470rpm92.60.8612027.82.376
YE3-180L-422kw42.351470rpm930.8614327.82.376
YE3-200L-430kw57.61475rpm93.60.8619427.32.376
YE3-225S-437kw69.81480rpm93.90.8623927.42.378
YE3-225M-445kw84.51480rpm94.20.8629027.42.378
YE3-250M-455kw103.11485rpm94.60.8635427.42.379
YE3-280S-475kw139.71490rpm950.8848126.72.380
YE3-280M-490kw166.91485rpm95.20.8857726.92.380



SYNCHRONOUS OUTPUT SPEED=1000RPM FREQUENCY=50HZ VOLTAGE=380V

MODEL

POWER

(KW)

CURRENT

(A)

SPEED

(RPM)

EFF

POWER

FACTOR

RATED

TORQUE

TSTISTTMAX

NOISE

dB(A)

YE3-71M1-60.18kw0.76850rpm54.60.662.021.94252
YE3-71M2-60.25kw0.97850rpm57.40.682.811.94252
YE3-80M1-60.37kw1.2890rpm680.73.881.95.52.154
YE3-80M2-60.55kw1.7890rpm720.715.681.95.82.154
YE3-90S-60.75kw2.2910rpm78.90.717.58262.157
YE3-90L-61.1kw3.8910rpm810.7311.1262.157
YE3-100L-61.5kw3.8940rpm82.50.7315.126.52.161
YE3-112M-62.2kw5.4940rpm84.30.7421.826.62.165
YE3-132S-63kw7.4960rpm85.60.7429.41.96.82.169
YE3-132M1-64kw9.6960rpm86.80.7439.21.96.82.169
YE3-132M2-65.5kw12.9960rpm880.7553.9272.169
YE3-160M-67.5kw17970rpm89.10.7973.12.172.170
YE3-160L-611kw24.2970rpm90.30.81072.17.22.170
YE3-180L-615kw31.6970rpm91.20.8114627.32.173
YE3-200L1-618.5kw38.1970rpm91.70.811792.17.32.173
YE3-200L2-622kw44.5970rpm92.20.812132.17.42.173
YE3-225M-630kw58.6980rpm92.90.8329126.92.174
YE3-250M-637kw71980rpm93.30.843592.17.12.176
YE3-280S-645kw85.9980rpm93.70.854342.17.32.178
YE3-280M-655kw104.7980rpm94.10.865312.17.32.178



SYNCHRONOUS OUTPUT SPEED=750RPM FREQUENCY=50HZ VOLTAGE=380V

MODEL

POWER

(KW)

CURRENT

(A)

SPEED

(RPM)

EFF

POWER

FACTOR

RATED

TORQUE

TSTISTTMAX

NOISE

dB(A)

YE3-801-80.18kw0.81630rpm560.612.51.83.31.952
YE3-802-80.25kw1.1640rpm590.613.41.83.31.952
YE3-90S-80.37kw1.4660rpm660.615.11.841.956
YE3-90L-80.55kw2.1660rpm700.617.61.84256
YE3-100L1-80.75kw2.4690rpm73.50.6710.21.84259
YE3-100L2-81.1kw3.4690rpm76.50.6914.91.85259
YE3-112M-81.5kw4.4680rpm77.50.7201.85261
YE3-132S-82.2kw6710rpm800.7128.81.86264
YE3-132M-83kw7.9710rpm82.50.7339.21.86264
YE3-160M1-84kw10.2720rpm850.7352.71.96268
YE3-160M2-85.5kw13.6720rpm860.7482.41.96268
YE3-160L-87.5kw17.8720rpm87.50.7598.11.96268
YE3-180L-811kw25.2730rpm890.7514526.5270
YE3-200L-815kw34730rpm90.40.7619626.6273
YE3-225S-818.5kw40.5740rpm91.20.762401.96.6273
YE3-225M-822kw47.3740rpm91.50.782861.96.6273
YE3-250M-830kw63.4740rpm92.20.793901.96.5275
YE3-280S-837kw76.8740rpm930.794781.96.6276



YE3 series three phase ac electric asynchronous motor mounting data

View more details, please click here.



FAQ



More details, welcome to call us!
Q: What are the payment terms?
A: 30% T/T in advance, 70% before shipment, L/C at sight, trade assurance from alibaba.

Q: What is your delivery time?
A: Different models with different time, 10-50 days after order confirmed.

Q: What is your MOQ?
A: It depends on model.
Q: Where is your loading port?
A: Shanghai or Zhangjiagang Port, China.

About how to inquiry and place an order, how to install, operate and maintain motors, please refer to this website.
