ZLP630 6m 630kg Painting Suspended Working Platform

Feedback Ratings
  • 1-3 Sets
    US $1780.00
  • 4-8 Sets
    US $1700.00
  • >=9 Sets
    US $1680.00
Color:
- +
available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
15 day(s) after payment received
Contact Supplier
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Shandong, China (Mainland)
Brand Name:
HUIYANG
Model Number:
ZLP630
Rated Load:
630kgs
Working Platform Size:
6m(2+2+2)
Lifting Height:
100m
Lifting Speed:
9-11m/min
Certificate:
CE, CCC, ISO9001
Material:
Q235 Steel
Surface Treatment:
Painting

Packaging & Delivery

Selling Units:
Single item
Single volume:
3 cm 3
Single gross weight:
950.0 kg
Package Type:
1-5 sets packed in wooden case. 5-13 sets be nude inside the Container.
Lead Time :
Quantity(Set) 1 - 50 >50
Est. Time(day) 15 To be negotiated
ZLP630 Parameters
Working Principle:

The platform is driven by electric hoist and wire rope, running against the building facade while the suspension mechanism was erected on buildings or structures.

Usage and Application:

ZLP series Suspended Platform belongs to high-rise working construction machinery, mainly used to install curtain wall, facade cleaning or other works such as plaster pulp, veneer, paint coatings, oil paint, or cleaning and maintenance, etc., can also be used for large tanks, bridges, dams and other construction operations.

Above all. HUIYANG Platform can increase the efficiency greatly, with simple and flexible operation, easy transfer, convenient and practical, safe and reliable.


The Parameters of ZLP series Suspended Platform
      Type
ZLP500
ZLP630
ZLP800
1.   Rated Load
500kg
630kg
800kg
2.   Lifting speed
9.3m/min
9.3m/min
9.3m/min
3.   Lifting height
100m
100m
100m
4.   Hoist
LTD6.3
LTD6.3
LTD8.0
4.1 Voltage-3 Phase
380V(415V/220V)
380V(415V/220V)
380V(415V/220V)
4.2 Frequency
50Hz/60Hz
50Hz/60Hz
50Hz/60Hz
4.3 Power
1.5kwx2
1.5kwx2
1.8kwx2
5.   Safety Lock
LSG20
LSG20
LSG30
6.   Electric Cabinet Parts
Schneider or CHNT
Schneider or CHNT
Schneider or CHNT
7.   Platform Sise (LxWxH)
(2.5+2.5)x0.69x1.42m
(2+2+2)x0.69x1.42m
(2.5+2.5+2.5)x0.69x1.45m

8.   Steel Wire Rope
4pcs; 100m/pcs
D=8.3mm; 4x31SW+FC
4pcs; 100m/pcs
D=8.3mm; 4x31SW+FC
4pcs; 100m/pcs
D=9.1mm; 4x31SW+FC
9.   Electric Cable
(3x2.0+2x1.0mm2)  100m
(3x2.0+2x1.0mm2 ) 100m
(3x2.5+2x1.5mm2)  100m
10. Suspended Jibs
340kg
340kg
340kg
Lifting  Parts Weight
410kg(Steel)
290kg(Aluminum)
480kg(Steel)
340kg(Aluminum)
530kg(Steel)
380kg(Aluminum)
Counterweight (Optional)
Cement, 750kg
Cement, 900kg
Cement, 1000kg
Qty of 20" Container
13 sets
13 sets
10 sets
Product Description


1. Working Platform:  Steel Q235 + Painting;   Q235 + Galvanised;   Aluminum Alloy + Painting;

 1.1  Working Platform is the workplace at heights for the workers.

 1.2  Size of platform can be adjusted from 1.0m, 1.5m, 2m, 2.5 meter or 3m etc depending upon the needs of your building
 1.3  With Bottom Wheel fitted underneath, the platform is easy to move.


2. Suspension Mechanism:  Steel Q235 + Painting; Q235 + Galvanised;

Suspension mechanism is on the top of the building to suspend the platforms through the steel rope.


3. Components:
LTD6.3 Hoist: 1.5kw, 2 sets;

LSD20 Safety Lock: 2 sets;

Electric Cabine: 1 set;

Steel Rope: 4pcs, 100m/pcs; D=9.1mm;

Electric Cabinet: 1pcs, 100m/pcs, 3x2.5+2x1.5mm sq;

Safety Rope: 1pcs; 100m/pcs;

Counterweight (Optional): 40pcs, 25kg/pcs.

Components Detail

Components 1

Name: Hoist                                  Brand: HUIYANG

Model: LTD6.3                              Quantity: 2 sets

Lifting Speed 9.3±0.5m/min       Lifting Force:  6.3KN


Name: Motor                                 Brand: Tianjin YONGHENG

Power: 1.5kw*2                            Voltage: 3 Phase 380/220V 50/60Hz
Rotational Speed 1420rpm         Weight:48kgx2

Components 2

Name: Safety Lock                   Brand: HUIYANG
Model: LST20                            Quantity: 2 sets
Locking Rope Angle 3°~8°      Allow impulsive force 20KN
Steel Wire Diameter  9.1mm   Weight:5.5kgx2


Safety Lock is the protection equipment. When the platform goes acclivitous, or ropes are broken off and falling, the safety locks will lock the wire ropes automatically and quickly to ensure the safety of the operator from falling and inclining.

Components 3

Name: Electrlic Controll Cabinet        Brand: HUIYANG
Surface: Galvanised                             With manual Switch

Components Brand: Schneider or CHNT

On Electric Control Cabinet, there are 4 buttons and a 220V

50Hz outlet for necessary use.

( Universal Switch, Power Indicator, Start Button and the Emergency Stop Button are in the door board of the cabinet. )

Components 4

Name: Steel Rope        Brand: Fasten

Quantity: 4pcs              Length=100m/pcs

Diameter=8.3mm         Weight:30kgx4

4x31SW+FC


Safety Rope: 1Pcs=100m
Electric Cable: 1Pcs=100m (3x2.0+2x1.0mm2)
Counterweight (Optional) : Cement or Cast Iron

Certifications
Company Introduction

HUIYANG Company Brief.

Ningjin Huiyang Construction Equipment Co., Ltd, established in 2005,located at Dezhou City, is a professional and accurate technique corporation who is professional in the R&D production and sale of suspended access equipment on high operation, and the accessories such as Safety Lock, Hoists, Electric Control Cabinet, Fasten Wire Ropes, and etc.

Now Huiyang becomes the production base and research centre of exporting suspended access equipment in China. The quality of Huiyang Suspended Platform is in the first-class in China and our products have been exported to more than 20 countries, which can be comparable with European famous suspended platforms.

Huiyang Suspended Platform is one of the largest enterprises engaged in well-known suspended platform in China, and annual production capacity is up to 8000 sets. In China, Huiyang suspended platform owns the most complete categories, specifications, and applications compared with same industry. They have been used in every aerial area with the main models ZLP500, ZLP630, ZLP800 and ZLP1000. The Voltage and Frequency could be up to different countries' standard, such as single-phase 220V, triplicate-phase 2200V, 380V etc.


No matter what structure needs, everything is easier with Huiyang.


WhatsApp: 86-13465160009

Our Service

Pre-Sales Service

* Factory Show.

* Consulting Support

* Fast Quotation and PI Feedback

* Deposit

* Sample Testing

After-Sales Service

* Video Training: how to instal the machine.

* Engineer Online Service.

* Email Instruction.

All products purchased from our company are guaranteed to keep in good repair for one year. If quality problems happen in guarantee period, our company will maintain for free.

FAQ.

1. How much is this suspended platform?
    Price will offer you immediately after telling us your requirements of loading capacity, material and voltage.
2. Are you a factory or trading company?
    We are direct factory with 40,4000 square meters factory and supply qualified products with factory price.
3. What quality certificate you own for your products?
    Our products own CCC, CE and ISO9001 certificate.
4. How about the price?
    Please send us inquiry, a consideration solution or preferable will be sent within 24 hours.
5. Payment term?      T/T or L/C at sight.
6. Spare parts & guarantee?
   If any parts get damaged because of quality within 12 months after shipping date.

   We will send new parts to replace right away.
7. Can you make suspended platform with our brand?    Yes.
8. Delivery time? According to order quantity, 10-20 working days will be finished after getting the deposit.
