Intelligent turbidity meter is the degree of obstruction that occurs when suspended objects in water pass through light .When the water contains soil , silt , fine organic matter , other microorganisms and colloids that cause turbidity in the water . During the transmission of the light wave transmitted by the emitter on the sensor , some of the transmitted light can be illuminated to the detectior in 180 °direction and some scattered light to the detector in 90°direction after the absorption , reflection and scattering of the measured object . the intensity of light received at 180 °and 90 °direction detectors is related to the turbidity of the sewage can be calculated by measuring the intensity of transmitted and scattered light .
1.Measuring range:0~500NTU,measurement range can be customizable.
5.Control interface :two groups of ON/OFF contact individual high and low alarm signal photoelectric isolation output
6.Signal isolation output :photocoupler isolation protection 4-20mA analog output.
7. Relay : relay lag value can be set freely , relay load 3A 220VAC/24VDC
8. Working condition : environment temperature 0~60℃, relative humidity≤90%
9.Output load: load<750Ω 4-20mA
10. working voltage:instrument :AC 220V10%,50/60Hz, sensor: DC 12V
11. hole size:92*92mm
12. protection grade:IP65
◇ The internal structure effectively eliminates the water bubble and improves the accuracy and stability of the measurement.
◇ Opening the outlet connection module can clean the inner wall of the optical lens and the flow slot and maintenance is more convenient .
◇ Sensor internal upgrade , prevention of internal circuit moisture and dust , avoid damage to internal circuits
◇ Buit-in zero position regulating potentiometer , sensor can be adjusted mechanically.
◇ The new shell waterproof , dust-proof and moisture-proof .
◇ Wide range , stable measurement , high accuracy , good reproducibility and strong anti-jamming.
◇ Communication function : RS - 485 communication port witch can optional , photoelectric isolation 4-20mA current output , the corresponding value can be set freely.
◇ Relay lag value can be set freely , avoid frequent action of switch relay. It has the function of setting the switch on and off.
◇ Adopting two-point correction method , the instrument measurement range can be modified.
◇ Watchdog function : Make sure the instrument dose not crash.
Nanning Nobo Instrument Co., Ltd. is a leading high-tech enterprise for about 10 years ,which including design , research & development , production , sales and service . We are focus on researching and developing intelligent water quality analysis instrument .
Such as , PH/ORP meter , conductivity meter , dissolved oxygen meter , residual chlorin meter , dissolved ozone meter , ion meter , turbidity meter , salinity meter , sludge concentration meter ect.
We will apply the Internet cloud service technology and offer the solution of internet of things system .Such as , multi-parameter water quality monitoring network system , smart city , smart agriculture and so on . If you have any request pls don't hesitate to contact us , OEM and customized are available ! We sincerely hope to cooperation with you ! Email : nobo_fsy @ nobowisd.com Mobile :+86-186 7716 3814 Tel.:+86-0771-6717697 ext 803 Web.: www.nobotech.com
Why Chooes US
1. Our company was established in 2009 with many years of experience make us excellence and professional. 2.We have our own factory with strong R&D center and QA team which can totally make sure the quality . 3. We have a completed after-sale service . 4. High quality! competitive price! Quick response! Excellent service experience!
1.Product Name: Intelligent Turbidity Meter 2.Brand Name: NOBOTECH 3.Model Number: ZS-600 4.Place of Origin: Nanning, China 5.Delivery Time: 7 to 15days after payment
Packing & Delivery
Product Name: Online turbidity meter
Brand Name: NOBOTECH
Model Number: ZS-600
Place of Origin: Nanning, China
Delivery Time: 3 to 4 weeks after payment
Q: How do you guarantee the quality? A: Firstly, we have our own factory with strong R&D center and QA team which can totally make sure the quality of every single product. Secondly, we have a completed after-sale service .
Q: Is OEM available? A: Yes, all goods can be customized according to your requirements, including packing, LOGO print, etc.
Q: Can it buy only 1 set of the meter? A: Yes. No matter how many products you buy, we are grateful all along.
Q: How to deliver the goods for trial order or small order? A : At customer's request ,we prefer to choose international express, such as DHL, EMS.TNT.Fedex.
