factory supply! A100-T15-S2-C DN15 AC110-230v normally closed 3 pieces motorized valve

Feedback Ratings
  • 1-9 Pieces
    $60.00
  • 10-99 Pieces
    $59.00
  • >=100 Pieces
    $58.00
Quantity:
- + Pieces available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
8 day(s) after payment received
Customization:
Customized logo (Min. Order: 1 Pieces)
Contact Supplier
Samples - $60.00 /Piece, 1 Piece (Min. Order): Buy Samples
Loading... Add To Cart
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Zhejiang, China (Mainland)
Brand Name:
Tonheflow
Model Number:
A100-T15-S2-C DN15
Application:
General
Material:
Stainless Steel
Temperature of Media:
High Temperature
Pressure:
High Pressure
Power:
motorized valve
Media:
Water
Port Size:
1/2 inch 2 way
Structure:
Ball
Product name:
A100-T15-S2-C DN15 AC110-230v normally closed 3 pieces motorized valve
Certificate:
CE, Rohs, IP67
Body material:
stainless steel
Color:
Customer's Request
Torque:
15N.M
Voltage:
AC110-230v
Working current:
≤1A
Open/close time:
≤15 Sec
Seal Material:
EPDM & PTFE

Packaging & Delivery

Selling Units:
Single item
Single package size:
17X13X9 cm
Single gross weight:
1.3 kg
Package Type:
10pcs/CTN
Picture Example:
package-img
Lead Time :
Quantity(Piece) 1 - 30 31 - 500 >500
Est. Time(days) 8 30 To be negotiated
Video Description
Product Description



 A100-T15-S2-C DN15 AC110-230v normally closed 3 pieces motorized valve

A100 torque 15NM,with manual override,

Technical Parameters



Output axis specification

Female octagonal 9*9 or 11*11

Maximum working pressure

3.0MPa,30Ba

Rated voltage

AC10-230v ;

Wiring diagram

CR501,CR201

Life time

70000 times(testing pressure is 0.4MPa, medium is water)

Actuator material

Engineering Plastics PPO

Torque force

15 N.m

Cable Length

0.5m;1.5m                                           (Optional )

Environment temperature

-15℃~60℃

Liquid temperature

2℃~90℃

Manual operation

No

Open/close indicator

Yes

Protection class

IP67

Company quality management system

ISO 9001:2015


Specifications:






Wiring diagram





Application

Suitable conditions:
1. IC card water meters, heat energy meters, solar instrument.
2. The central air conditioning fan coil, fire sprinkler
3. Water saving irrigation, automatic control system, industrial mini automatic control equipment.
4. Agriculture Irrigation equipment
5. Drinking water equipment, Water heater, washing machine, AHW etc.




Pls confirm the above different versions of actuators



When you inquiry the valve, pls confirm the detail  technical data :

1, valve size , materail

2, working voltage AC110-230v

3, wire control

4, valve manual override & indicator

5, actuator cable length 0.5m or 1.5m


Pre-sale service

1.We have full stock and can deliver within short time.

2.OEM and ODM order are accepted, Any kind of logo printing or design are available.

3.Good Quality + Factory Price + Quick Response + Reliable Service, is what we are trying best to offer you.

4.All of our products are produced by our professional workman and we have our high-work-effect foreign trade team, you can totally believe our service.

After you choose:

1. We will count cheapest shipping cost and make invoice to you at once.

2. Check quality again, then send out to you at 1-2 working day after your payment

3. Email you the tracking no., and help to chase the parcels until it arrive you.

After-sale service

1.We are very glad that customers give us some suggestion for price and products.

2.If you have any question,please contact us freely by E-mail or Telephone.




TONHEV is a manufacture in China specilized in mini motorized shut off ball valve (1/4”~2’’).And valve actuator which are approved CE certification and SS valve approved NSF61 international certification.

we buy a PICC insurance for our products in 2016. I belive they are more reliable and guaranteed for your customer or the user.
Our company also approved SGS ISO9001 in 2013 .











Packaging & Shipping





FAQ

Q. what is your payment term?

 A: T/T 30% down payment, balance to be paid before shipment. or L/C.



Q: what is your main market?

A: North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe



Q: How about your products and company approved?

 A: Our products are approved CE, NSF61, Rohs, protection class IP67, Our company also approved SGS ISO9001 since 2013.



Q: Can I get samples from your factory?

A: Yes, Samples can be provided.



Q: If products have some quality problem, how would you deal with?

A: We will responsible for all the quality problems, we buy a PICC insurance for our products in 2016. I belive they are more reliable and guaranteed for your customer or the user.
