good display 4 inch 4.3 inch e-ink display usb for digital price tags

  • 1 - 99 Pieces
    $23.00
  • >=100 Pieces
    $20.39
Type:
EPD
Supplier Type:
Original manufacturer
Lead Time:
Quantity(Pieces) 1 - 50 >50
Est. Time(days) 7 Negotiable
Customization:
Customized packaging (Min. Order: 5000 Pieces)
Samples:
$23.00 /Piece | 1 Piece (Min. Order) | Buy Samples
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
China
Brand Name:
GooDisplay
Model Number:
GDE043A2
Display Size:
4.3 inch
Type:
Dot Matrix
Resolution:
800x600
Outline Size(mm):
126.5x74.6x1.17
Active Size(mm):
88*66
Pixel Pitch(mm):
0.11x0.11
Operating Temp.:
0℃~50℃
Storage Temp.:
-20℃~70℃
Contrast Ratio:
above 8:1
Max Grayscale:
16
Color:
Black,White
Supply Ability
Supply Ability:
200000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
TBD
Port
DALIAN
Lead Time :
Quantity(Pieces) 1 - 50 >50
Est. Time(days) 7 To be negotiated
he collection store can let you know that the store provides time-limited discount, product reduction, coupons, hot sales, new products, low MOQ, free proofing and other information that is beneficial to you. Methods: such as the picture to see "❤", Click it on the PC or APP. That way you could see all of the feeds at the bottom of the APP. Welcome to collect. thank you
Products Description
What's included in the package
NO.
Standard Accessory Name
Qty
1
 4.3 inch 800x600 pixel EPD Parallel e-ink display
1
2
FPC Connector
1
3
Come with helpful development demo kit with resources and manual (Please contact our sales, we will send the you the documents by email, thanks)
1
Main Parameters

good display 4 inch 4.3 inch e-ink display usb for digital price tags
Part Number
GDE043A2
Type
Dot Matrix
Resolution
800x600
Outline Size(mm)
126.5x74.6x1.17
Active Size(mm)
88x66
Pixel Pitch(mm)
0.11x0.11
Operating Temp.
0℃~50℃
Storage Temp.
-20℃~70℃
Color
Black,White
Interface
Parallel
Max Grayscale
16
Current of the refresh(mA)
181
Power consumption of the refresh(mW)
600
Standby power consumption Pc(mW)
0.4
Time of refresh(s)
1
Time of partial refresh(s)
1
Drawing


You could click the following picture to buy this e-paper display with matched development kit and connector board.
Matched Demo Kit

Development Kit for Parallel interface dot matrix e-ink Display.
We can provide you demo kit and technical support.
Please click the picture for more details.

*Notice that the above price does not include the Demo Kit.
Particulars
Other Products
Size: 4.3 inch
Interface: Parallel
With Touch Panel
Size: 4.2 inch
Resolution: 400x300
Interface: SPI
Size:  6 inch
Interface: Parallel
Touch Panel Optional
