high efficiency 156mmx156mm 6" 2BB/3BB polycrystalline solar cells with competitive price

FOB Price: US $0.28 - 0.46 / Watt Get Latest Price
Min.Order Quantity: 1000 Piece/Pieces for solar cell
Supply Ability: 200000 Piece/Pieces per Month for solar cell
Port: Shanghai
Payment Terms: L/C,T/T,Western Union,MoneyGram
Add to My Favorites

Quick Details

Place of Origin:
Jiangsu China (Mainland)
Brand Name:
RESUN
Model Number:
RS-156 Poly
Material:
Polycrystalline Silicon
Size:
156X156
Number of Cells:
1pcs or more
Max. Power:
4.38W/pc
dimension:
156X156
Color:
Blue and dark blue
Efficiency:
16.6%~19%
Grade:
A grade / B grade
Bus bar:
2BB / 3BB/4BB
Packaging:
100pcs in one box,1000pcs per carton, standard export carton

Packaging & Delivery

Packaging Detail: 100 pieces per box, 10 boxes per carton for solar cell
Delivery Detail: within 5 working day for solar cell

Specifications

1. High efficiency >18.6%
2. Long-term electrical stability.
3. For solar module solar cell
4. Sample acceptable

156x156mm (6x6 inch) polycrystalline solar cell, 2 bus bar, 3 bus bar and 4 bus bar



Features



1.High conversion efficiencies resulting in superior power output performance.



2.Outstanding power output even in low light or high temperature conditions



3.Optimized design for ease of soldering and lamination



4.Long-term stability,reliability and performance



5.Low breakage rate



6.Color uniformity



Production and Quality Control



1.Precision cell efficiency sorting procedures



2.Stringent criteria for color uniformity and appearance



3.Reverse current and shunt resistance screening



Specifications

   Product Pictures





Shipping


1. Items are only shipped after PAYMNET is received.



2. Usually our solar cells are 100 pieces per box, 10 boxes per carton.



3. Please check out your ADDRESS carefully when processing order.



4. Please CONTACT us ASAP if you haven't received the parcel.



Shipping will be made via  EMS, DHL, Fedex, UPS etc.

Verified Information

This information was Verified by TÜV Rheinland and is valid for the following period: 2014/04/30 --- 2015/04/29
The information below covers both the Gold Supplier and its related companies, which are defined according to china laws and regulations, and which will also be clearly displayed in the full report >>

The competitive advantage of product line:

The products are exported to Southeast Asia, Eastern Asia and Western Europe etc.

Production Capacity:

Product Line Name Production Line Capacity Actual Units Produced(Previous Year)
Solar Energy Products Solar Panel 60,000 Pieces / Month, Solar System 300 Sets / Month, Solar Light 100 Pieces/ Month, Solar Cell 5,000 Pieces / Month, Solar Frame 60,000 Sets /Month

Export Market Distribution:

Market Revenue(Previous Year) Total Revenue (%)
Southeast Asia confidential 60.31
Africa confidential 0.98
Oceania confidential 3.0
Eastern Asia confidential 14.56
Western Europe confidential 5.0
Southern Europe confidential 0.25
South Asia confidential 0.53
Domestic Market confidential 15.37

Production Machinery:

Machine Name Brand & Model No. Quantity Number of Year(s) Used Condition
Sawing Machine 1 XIZHANGZE 4 2.0 Acceptable
Sawing Machine 2 XIAHZNGZE 2 2.0 Acceptable
Punching Machine J23 6 3.0 Acceptable
Laser Cutting Machine SUNIC 4 3.0 Acceptable
Cutting Machine ZHANGJIAGANG 1 1.0 Acceptable
Laminating Machine YUDA 2 3.0 Acceptable
Framing Machine No Information 1 4.0 Acceptable

Testing Machinery:

Machine Name Brand & Model No. Quantity Number of Year(s) Used Condition
Solar Cell Tester JDSGC-8BG 2 4.0 Acceptable
Multimeter MS8215 1 4.0 Acceptable
Solar Cell Module Tester JDSGC-8CM 1 4.0 Acceptable

Production Flow:

  • Raw Material Inspecting
    Raw Material Inspecting
  • Cutting
    Cutting
  • Sorting
    Sorting
  • Soldering
    Soldering
  • Laying
    Laying
  • Laminating
    Laminating
  • Sawing
    Sawing
  • Punching
    Punching
  • Framing
    Framing
  • Final Inspecting
    Final Inspecting
  • Packing 1
    Packing 1
  • Packing 2
    Packing 2

Certification:

Certified Picture Certification Name Certified By Certificate No. Product Name & Model No. Available Date --- Expired Date
CE TUV NORD 44 799 12 406749-013 Crystalline Silicon Terrestrial Photovoltaic (PV) Modules 2012/07/20 --- 2049/12/31
IEC TUV NORD 44 780 12 406749-047 Mono-crystalline Solar Cell Modules 2012/07/20 --- 2017/05/29
IEC TUV NORD 44 780 12 406749-046 Mono-crystalline Solar Cell Modules 2012/07/20 --- 2017/05/29
