high voltage circuit breaker tester good quality circuit breaker dynamic analyzer circuit breaker price philippines

FOB Reference Price:Get Latest Price
$1,000.00 - $3,300.00 / Pieces | 1 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Hebei, China
Brand Name:
HuaZheng
Model Number:
HZC-3980
Type:
High Voltage
Poles Number:
3
Product name:
Circuit Breaker Analyzer
Power supply:
220V 50Hz
Warranty:
1 Year
Certificate:
ISO
Function:
Circuit Breaker Analyzer
Output power:
DC30~250V
Standard:
BS.EN.ASTM
Current Range:
20.00A, resolution: 0.01A
Time Range:
4000.0ms
Weight:
9KG
Supply Ability
Supply Ability:
100 Piece/Pieces per Year Circuit Breaker Analyzer
Packaging & Delivery
Packaging Details
Portable Circuit Breaker Analyzer Packaging:
1.HS code is 9030820000.
2.Wooden or carton box with foam inside.
3.No fumigation,not influence the delivery.
4.Standard of CE ISO IEC.
5.Customer OEM packing is also available
Port
Tianjin

high voltage circuit breaker tester good quality circuit breaker dynamic analyzer circuit breaker price philippines



Performance Characteristics

1. Performance

a. Time: 12 inherent in the fracture points, closing time, with the same period, and white the same period.
b. Reclosing: each fracture together - sub, sub - together, sub - Hopewell - sub-process time: one point, a time is the time of the two-in-gold short time, current time value.

c. Speed: just now, just closing speed, maximum speed, time - stroke characteristic curve.
d. Stroke: total trip, open distance, over-travel, the overshoot travel, rebound amplitude.
e. Current: points, closing coil points, closing the current value, the current waveform diagram.
f. Operating Voltage: DC30 ~ 250V/20A digital machine adjustable breaker operation power supply, to automatically complete low voltage operation test of the breaker, measuring the value of the operating voltage of the circuit breaker.

2. Characteristics

a. All models suitable for domestic and foreign production of SF6 switchgear, GIS combination of electrical, vacuum switch, oil switch mechanical properties test

b. Super anti-jamming capability, 500KV substation the bypass bus charged case can easily test to accurately measure.
c. Universal speed sensor, straight line linear sensor, rotary sensor, extremely easy to install and simple.
d. Switching operation once obtained the switch mechanical properties testing of all data and the corresponding waveform Spectrum.
e. The host field test data, the machine can be stored in the real-time clock, easy to the archive save the test date, time.
f. Host big screen, wide temperature, direct perspective, backlight LCD Chinese display all data and maps, LCD contrast electronic adjustment, power and memory.
g. Chinese menu operation, easy to use. Instrument built-in printer, fast print all data and maps at any time.
h. The instrument with data analysis and management software, with PC online operation, the test results can be output to the various types of dot matrix, laser or ink-jet printer to print the test report, the field trials computerized.

Well-exported HZ-3980 oil circuit breaker test set  in China marketProduct Parameter:


Service condition

Input power

220V±10% 50Hz±10%

Atmospheric pressure

86~106kpa

Temperature

-10~40

Humidity

<80%RH

Safety Performance

Insulation resistance

>2MΩ

Dielectric strength

Power to chassis frequency voltage withstands 1.5KV, 1 min, no flashover and arcing.

Basic parameters

Time

Range: 4000.0ms, resolution: 0.1ms
error:
< 100ms, 0.1ms±1d

>100ms, 0.1%±1d

synchronous

Speed

Range: 20.00m/s,  resolution 0.01m/s
error:
0~2m/s : ±0.1m/s±1d

>2m/s, ±0.2m/s±1d

Range

Vacuum Circuit Breaker: range-50.0mm, resolution-0.1mm, error-1%±1d
SF6 Circuit Breaker:  range-300.0mm, resolution-1mm, error-1%±1d
Oil-minimum breaker: range-600.0mm, resolution-1mm, error-1%±1d

Current

Range: 20.00A, resolution: 0.01A

Output power

DC30~250V digitally adjustable /20A (Instantaneous)

Dimension

360×280×300mm3

Weight

9kg

Certifications



Quality Control



Packaging & Shipping



Company Information

HuaZheng Electric Manufacturing (Baoding) Co.,Ltd is  founded in 2008,the supplier of the State Grid in China.It means we are the supplier of the Chinese Government.And our products spread throughout the whole China.

Our main products : Insulation Oil Tester, Cable Fault Locator, High Voltage Generator,transformer tester, relay protection tester,insulation resistance  tester,Power Quality Analyzer and so on.

Close to Tianjin port, the transportation is convenient. our customers come from More than 50 countries, like America, England, Bulgaria, Brazil, Chile, Malysia, Vietnam and so on.

What's more, gurantee 1 year,life long maintance .Products through the CE, ISO, IEC certification, quality and reliable, factory price.

Warmly welcome all partners to join us for mutual benefits cooperation.
