independent audio 1080P60 USB/HDD storage Arthroscope hdd medical video recorder

FOB Reference Price:Get Latest Price
$1,470.00 - $1,765.00 / Pieces | 1 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Beijing, China
Brand Name:
TCHD
Model Number:
MVR
Properties:
The Basis of Surgical Instruments
Type:
Recorder
Product name:
Medical Video Recorder
Application:
Arthroscope,Endoscope,B-mode ultrasound
Function:
Surgery image recorder
Input:
HDMI/SDI/VGA/YPbPr/S-video/CVBS
Output:
removable HDD, USB HDD, USB flash disk. RTSP
Resolution:
1920x1080P60
Audio:
independent audio
Feature:
Backup video and photos
Supply Ability
Supply Ability:
20 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
Carton box
Port
Beijing
Lead Time :
3days after receiving payment

Independent audio 1080P60 USB/HDD storage Arthroscope hdd medical video recorder

Introduction

The HD MediDVR is a medical grade all interface in one full HD Video Recorder. It combines superior image and video quality all versatile inputs extensive easy control various removable storage medias.
It can record high-definition crisp1080p video from endoscope arthroscopy surgical camera C-Arms ultrasound etc. Saves extremely clear still images and videos to an internal removable HDD external USB HDD USB Flash SD Card or network. On board gain adjustable omnidirectional microphone buzzer and full color LED feedback are also available. Meanwhile MediDVR supports real time streaming by connecting to the hospital network. It enables the live transmission of procedures to other practitioners or students outside of the operating theater for training or monitoring purposes.

Features


* Easily record crisp 1080p video and images
* High quality HD video in H.264 or MPEG format
* Simple to use, no special training required
* Universal interface, works with almost all video interface on the market
* Universal storage works with all major USB Flash, SD Card, USB HDD and SATA HDD
* Support Full HD video up to 1080p@60
* DVI preview output and SDI loop output
* 3 level gain adjustable omnidirectional microphone
* Still Image Photo
* Unique LANC remote control interface
* Foot pedal supported
* Internal removable SATA HDD
* Rugged aluminium bullet shape housing
* Keyboard to input patient data
* Network supported for live video streaming
* Real-time Clock, time/date stamp and OSD
* Small size and low cost
* Upgradable firmware
MediDVR is fully certified for using medical environments. The unit is protected by a rugged metal case and fluid resistant membrane.

 Item

 Parameter

 Video Input

 SDI

 HDMI

 YPbPr

 S-Video

 CVBS

 DVI

 VGA

 Input Resolution

 SDI:1080p/1080i/720p/576i/480i

 YPbPr:1080p50/25/1080i50/720p50/1080p60/30/1080i60/720p60

 DVI:1080p/1080i/720p

 HDMI:1080p/1080i/720p

 VGA:1920x1200/1920x1080/1600x1200/1680x1050/1400x1050/

 1280x1024/1024x768/800x600/640X480

 CVBS:576i/480i

 S-Video:576i/480i

 Frame Rate

 30

 25

 60

 50

 24

 Video Signal

 Auto

 Manual

 Preview

 1920x1080

 1280x720

 1280x1024

 1024x768

 Playback

 LCD

 Monitor

Advantages
