low price portable sea water ultrasonic flow meter with rs232 protocol

Feedback Ratings
  • 1-9 Units
    $400.00
  • >=10 Units
    $390.00
Material:
plastic
- +
available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
7 day(s) after payment received
Contact Supplier
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Shandong, China (Mainland)
Brand Name:
AUTO
Model Number:
TUF-2000H
Linearity:
0.50%
Repeatability:
0.20%
Accuracy:
Better than ±1% for velocity above 0.2m/s
Flow Range:
±32m/s
Measuring Pipe Size:
25mm-6000mm
Totalizer:
7-digit totalizer for net, positive and negative flow respectively
Display:
4*16 character
Transducer Cable:
10M/5m x2
Product Name:
sea water ultrasonic flow meter

Packaging & Delivery

Selling Units:
Single item
Single package size:
38X28X17 cm
Single gross weight:
9.0 kg
Package Type:
carton
Lead Time :
Quantity(Unit) 1 - 10 >10
Est. Time(days) 7 To be negotiated

low price portable sea water ultrasonic flow meter with rs232 protocol

Product Description

OEM portable wall mount ultrasonic flowmeter/flow sensor 100mm for water can be applied to a wide range of pipe flow measurements. Applicable liquids include pure liquids as well as liquid with small quantity of tiny particles.such as Water (hot water, chilled water, city water, sea water, waste water, etc.);Sewage with small particle content;Oil (crude oil, lubricating oil, diesel oil, fuel oil, etc.);Chemicals (alcohol, acids, etc.);Plant effluent;Beverage, liquid food;Ultra-pure liquids;Solvents and other liquid.



High Accuracy:Accuracy better than 1%.

Wide Measurement Range:Measurement range from DN15~DN6000mm

Rechargeable Power Supply:Built-in high-capacity NiMH rechargeable battery can work 20 hours(Fully charged).

Non invasion measurement:Can achieve measurement with clamp on sensors

Data Storage:32K BIT built-in data storage,can store two thousand rows of data

LCD display:LCD dispaly can display the instant flow,totoal flow,flow velocity and working condition

low price portable sea water ultrasonic flow meter with rs232 protocol

  • Water, including hot water, chilled water, city water, sea water and more.
  • Sewage and drainage water with small particle quantity
  • Oil, including crude oil, lubricating oil, diesel oil, fuel oil, etc.
  • Chemicals, including alcohol, acids and more.
  • Solvents
  • Beverage and food processors
  • HVAC hot and cool water, water/glycol solutions
  • Water and waste treatment
  • Power plants (nuclear, thermal & hydropower) heat energy boiler feed water
  • Energy consumption supervision and water conservation management
  • Metallurgy and mining applications (e.g., acid recovery)
low price portable sea water ultrasonic flow meter with rs232 protocol
Technical Parameters
ItemsSpecification
Linearity0.50%
Repeatability0.20%
AccuracyBetter than ±1% for velocity above 0.2m/s
Response Time0-999 second, user-configurable
Flow Range±32m/s
Measuring Pipe Size25mm-6000mm
UnitsEnglish (U.S.) or metric
Totalizer7-digit totalizer for net, positive and negative flow respectively
Liquid TypesAny single uniform liquid which can transmit ultrasonic
SecuritySetup values Modification Lockout. Access code needs unlocking
Display4×16 character
CommunicationInterfaceRS-232 interface. 75-57600bps, compatible with Fuji ultrasonic flowmeter and other UFM on enquiry.
TransducersModel M1 for standard, other 4 models for optional
Transducer CableStandard 5m x2 or can be extended to 10m x2
Power Supply3 AAA built-in Ni-MH batteries (for over 12 hours of operation). 100V-240VAC adapter
Data LoggerBuilt-in data logger can store over 2000 lines of data
Manual Totalizer7 digit, calibrating by key
Housing MaterialFlaming retarding ABS
Size200×93×33mm
Handset Weight400g with batteries

low price portable sea water ultrasonic flow meter with rs232 protocol

V-method installation is the most widely mode for daily measurement with pipe inner diameters
ranging from 15 mm to 400 mm. It is also called reflective mode.

Z-method is commonly used when the pipe diameter is above 200mm



low price portable sea water ultrasonic flow meter with rs232 protocol

package:carton box

inner package as following:

low price portable sea water ultrasonic flow meter with rs232 protocol



FAQ
Q:Can you accept OEM service ?
A:We professional provide OEM &ODM service for low price portable sea water ultrasonic flow meter with rs232 protocol


Q:How about the quality of the oil oval gear flowmeters?
A:We have the certification of ISO,CE ,we could send the certification test of our company to you.


Q:Could you provide me the shortest lead time?
A:We have materials in our stock,if you really need,you can tell us and we will try our best to satisfy you.


Q. How about the payment?

A: TT. Western union, paypal, LC. etc.


In order to recommend you the most suitable flow meter and make an accurate quotation, please

provide the following information and send it to our sales when you are going to make an inquiry, thanks !


1. What is your medium?
2. How about the pipe size? Flow range?

3. How about the temperature and pressure?



    If you are interested in low price portable sea water ultrasonic flow meter with rs232 protocol

                                   Please contact us!
