modbus rs485 cheap small made in china controller plc
-
1-9 Pieces$158.90
-
10-19 Pieces$156.00
-
20-49 Pieces$153.00
-
>=50 Pieces$148.62
- Quantity:
- Shipping fee:
- Depends on the order quantity.
- Lead Time:
- 5 day(s) after payment received
- Customization:
-
Customized logo (Min. Order: 10 Pieces)Customized packaging (Min. Order: 10 Pieces)
More
Graphic customization (Min. Order: 10 Pieces) Less
- Place of Origin:
-
jiangsu, china
- Brand Name:
-
Mochuan
- Model Number:
-
MU1H-3624MR
- Input/Output:
-
36/24
- Special Function:
-
support 2pcs analog module
- User Program:
-
12K
- MOQ:
-
NO, one pcs is ok
- Output:
-
relay
- Communication protocol:
-
modbus
Packaging & Delivery
- Selling Units:
- Single item
- Single package size:
- 21X10X9 cm
- Single gross weight:
- 2.5 kg
- Package Type:
- Inner plastic box + outer hardness box.7days refund in case of bad quality
- Lead Time :
-
Quantity(Piece) 1 - 1 2 - 50 51 - 100 >100 Est. Time(day) 5 10 15 To be negotiated



Certificate Number | 1105217 |
Origanization | EC DECLARATION OF CONFORMITY |
Declare the product | PLC Programmable logic controller |
Date & Time | 02/06/2011 |
Test Standard | EN60950-1:2006+A11:2009 |
Certificate for | EC Low Voltage |
Kindly reminder:
All our certifications are REAL ONE.
NOT FAKE, NOT FAKE, NOT FAKE!!!
PLEASE CONTACT US TO SHOW YOU!!!
WORLD-WIDE CUSTOMERS COMMEND & FEEDBACK
Here is some of comments from our world-wide customers.
You can check all the comment at our company profile by www.mochuan.en.alibaba.com-" company profit"-"Rating& Rewiews" Then you can see all comments from our clients.
( Know please, all our customer comments are real one, NOT FAKE.)
TRUST YOU WILL LIKE OUR SERVICE, QUALITY AND PRICE

Alibaba.com suppliers platform show that:
1. We never got any complain.
2. More than 5000 customers contacted us.
3. Star supplier with more than 10000 points.

MU2V | MU2H | MU1H | |
I/O Point | 16/16, 28/28 | 16/16, 32/32 | 08/06, 12/08, 16/10, 16/14, 36/24 |
Max Logical I/O | 512 | 512 | 512 |
Max Special Function Module | 8 | 8 | 2 I/O and analog module |
Program Capacity | 32K | 24K | 12K |
Pulse output | 8x200KHz 4differential output | 3x100KHz( transistor output) | 2x100KHz( transistor output, relay input) |
One-phase Counting Channel | 8x200KHz | 2*50KHz, 4x10KHz | |
Two-phase Counting Channel | 4x200KHz | 1x25KHz, 2x5KHz | 1x20KHz, 2x10KHz |
Sum of Counter Frequency | 800KHz | 100KHz | 80KHz |
PLC N:N | support | ||
RTC | support(power down keeping at least 3years) | ||
Constant Sanning Mode | support | ||
Digital Filter | 0.8, 1.6, 3.2, 6.4, 12.8, 25.6, 51.2, adjustable | ||
Feature | Description | ||
Programming Software | Free MCprogrammer | ||
Program Security | download, upload, program password | ||
Programming Language | ladder, instruction, SFC | ||
Communication Protocol | programming protocol, Modbus, CAN and free port, MXLink | ||
Expansion Module | I/O extension module, AD/DA, thermal resistance, thermal couple, pulse, weighting, et | ||
For more details data sheet of them,kindly contact us. |

MU1H Models: | ||||||
Model | I/O | RS485 | CAN | Output Type | Integrated | Dimension mm |
MU1H-0808MR/T/R1/T1 | 08in 06out | support | - | R:relay T:transistor | 4AD-2DA | 126*90*72 |
MU1H-1208MR/T | 12in 06in | - | ||||
MU1H-1208MR1/T1 | 2AD-1DA | |||||
MU1H-1208MR2/T2 | 1AD-1PT-1DA | |||||
MU1H-1208MR3/T3 | 2PT-1DA | |||||
MU1H-1614MR1/T1 | 16in 14out | 2AD-1DA, support 2pcsc I/O and analog module | 158*90*74 | |||
MU1H-1614MR/T | support 2pcs I/O and analog module | 126*90*72 | ||||
MU1H-1410MR/T | 14in 10out | |||||
MU1H-2416MR/T | 24in 16out | 158*90*74 | ||||
MU1H-3624MR/T | 36in 24out | |||||
There are analog/thermocouple/ thermal resistance/ pulse/ high precision analog/ weight..module. Please contact us |
MU1H-0816MTD-6LC, MU1H-0814MTD-4L, MU1H-9LC integrates temperature control:
1.Supports all functions of MU1H series main module.
2. Integrates multi road temperature sampling and control;
3. Support self-turnning function and power off keeping function.
4. Flexible configuration for output, could be used as temperature control output, aslo the general output.

Super Extender System: Max extended I/P points pf MU1H plc is 256points, with integrated 2AD-1DA/ 2PT-1DA and supported 2pcs I/O or specification function module.

Integrates PID function: MU2H series main module integrates temperature control function, matched with MU2H series TC, PT module, Max 32road TPID could not made supporting the self-determining function of TPID parameter.

Three Programming Language: ladder, instruction list, SFC which could be interconverted. As for conversion between ladder and instruction list, annotation could be kept.
