shanghai qipang wire straightening and cutting machine with tungsten wire straightener bearing

  • 1 - 4 Pairs
    $650.00
  • >=5 Pairs
    $630.00
Model Number:
DJZQQ-18/32
Customization:
Customized logo (Min. Order: 1 Pairs)
Customized packaging (Min. Order: 1 Pairs)

More

Graphic customization (Min. Order: 1 Pairs) Less
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Place of Origin:
Shanghai, China
Type:
Wire Drawing Machine
Use:
Other
Brand Name:
qipang
Voltage:
380V/220V
Power(W):
Electrical
Dimension(L*W*H):
980*760*750
Weight:
5KG
Certification:
ISO9001
Warranty:
1 YEAR
After-sales Service Provided:
Online support, Engineers available to service machinery overseas
Applicable Industries:
Energy & Mining
diameter of wires:
10-12mm
quantity:
18rollers
diameter of rollers:
50
Product Keywords:
hydraulic busbar cutting punching bending machine
Supply Ability
Supply Ability:
1000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
Carton boxes, packing boxes, wooden and foam
Port
shanghai
Video Description
Product Description





Technical specification of Power straightener

Material of straightening wire:Carbon steel, aluminum, copper and solid material.

Adjustment of straightening wheel:The mobile part of straightening wheel is independent.

Dimension of straightening device:.



Packaging: Wooden case.

A----- A type straightening wheel is the overall opening and closing form;

B----B type is single straightening wheel independent mobile regulation;

T---- T type is a special straightening device



Straightening adjustment method: It is related to the center distance between the straightening wheels, either the horizontal or vertical straightening wheel, in the longitudinal direction (i.e., along the forward direction of the copper tube), the distance between two adjacent wheels should be small (but not equal to zero), and the straightening effect will be better, however, the center distance in this direction is fixed and can not be adjusted. However, the center distance in the other direction (For the horizontal straightening wheel is horizontal; for the vertical straightening wheel is vertical ) is adjustable. In this direction, the center distance between adjacent wheels is adjustable. In this direction, the center distance between the two rounds is too large or too small is not enough. Too large is not straight, when too small, after the completion, it will appear the wave shape in the full length. Since the copper tube is hard, the elasticity is bigger, you can adjust the center distance between the two wheels to slightly smaller than the theoretical size, when transferred to a certain extent, it will be straight.



Product Detail

diameter of wires10-12mm
quantity18rollers
diameter of rollers50
Product Keywordshydraulic busbar cutting punching bending machine

Quality assurance:

1.wire straightening is equiped with world advanced computer driving production lines
2.The whole set of equipment have induction or PLC device
3 Have high quality guaranteed, exported to overseas countries

Product modelWire diameterRoller numberRoller diameter
JZQ0.1-.3/24,AVφ0.1-0.3247
JZQ0.3-.5/34,AVφ0.3-0.53412
JZQ0.5-0.8/26,AVφ0.5-0.82616
JZQ08-2.0/18,BVφ0.8-2.02623
JZQ2.0-4.0/18,AVφ2.0-4.01830/32
JZQ4.0-7.0/18,AVφ4.0-7.01844/50
JZQ7.0-12.0/18,AVφ7.0-12.01847/40
JZQ12.0-20.0/18,AVφ12.0-20.01870
JZQ0.8-4.0/5,AVφ0.8-4.0523/30/32
JZQ4.0-10.0/5,AVφ4.0-10.0542
JZQ4.0-10.0/18,BVφ4.0-10.01842
JZQ10.0-20.0/18,BVφ10.0-20.01870

Straightening machine through the straightening roll extrusion of bar to the change of straightness. There are generally two row of straightening roll, any number. There are also two roll straightener, rely on two roll (middle concave, hyperbola roll) the Angle of the change on the materials of different diameter straightening. Main types of pressure straightening machine, balance roll straightening machine and shoes roll straightening machine and so on.
