smps adapter 24v 0.75a power adapter
Features Universal AC input / Full range No load power consumption< 0.3W 2 pole EURO plug, could be customised Protections:Short circuit/Over load/Over voltage/ Over temp Fully enclosed plastic case Class II power(with earth pin) 3 years warranty Capacity: 100,000pcs/month Lead time: 15 working days led driver/power supply Payment: TT,L/C,Paypal ect,. Sample is available Provide customizing service
ORDER NO. ADS-U018S24 OUTPUT DC VOLTAGE 24V RATED CURRENT 0.75A CURRENT RANGE 0~0.75A RATED POWER 18W RIPPLE & NOISE (max. 80mVp-p VOLTAGE TOLERANCE +/-3.0% LINE REGULATION +/-1.0% LOAD REGULATION +/-3.0% SETUP, RISE, HOLD UP TIME 500ms,20ms,30ms/230VAC 500ms,20ms, lOms/115VAC(at full load) INPUT VOLTAGE RANGE 90~264VAC l35~370VDC FREQUENCY RANGE 47~63Hz EFFICIENCY (Typ.) 78.50% AC CURRENT 0.31A/ 115VAC 0.l6A/ 230VAC INRUSH CURRENT (max.) COLD START 25A / 115VAC 45A / 230VAC LEAKAGE CURRENT (max.) 0.25mA/240VAC PROTECTION OVERLOAD >105% rated output power Protection type : Hiccup mode, recovers automatically after fault condition is removed OVER VOLTAGE 115%°C~135% Protection type : Clamp by zener diode OVER TEMPERATURE U1 Tj 140°C typically (U1) Detect on main control IC Protection type : Shut down o/p voltage, recovers automatically after temperature goes down ENVIRONMENT WORKING TEMP. 0 ~ +50°C (Refer to "Derating Curve") WORKING HUMIDITY 20% ~ 90% RH non-condensing STORAGE TEMP., HUMIDITY --20 ~ +85°C , 10 ~ 95% RH TEMP. COEFFICIENT +/-0.03%/°C(0~40°C) VIBRATION 10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes SAFETY & EMC SAFETY STANDARDS TUV EN60950 -1 approved WITHSTAND VOLTAGE I/p-0/P: 3KVAC ISOLATION RESISTANCE I/p-0/P: 100M Ohms / 500VDC / 25°C / 70% RH EMC EMISSION Compliance to EN55022, EN61204-3, EN61000-3-2,3, FCC part15 class B EMC IMMUNITY Compliance to EN61000-4-2,3,4,5,6,8,11, EN61204-3, light industry level, criteria A OTHERS MTBF ≥ 1414.6Khrs MIL-HDBK-217F ( 25°C ) DIMENSION 65*47*26.5mm (L*W*H) PACKING 0.l5Kg CONNECTOR PLUG Standard type P1I: 2.1 * 5.5 * 9.5mm turning fork type, center positive for stock ; Other type available by customer requested CABLE Standard type UL1185 6ft (4FT only for 5V output) for stock ; Other type available by customer requested
Production Process 1.Purchasing the materials:each of our materials must be tested before putting into producing.
2.SMT(Surface Mout Technology):we have our own SMT department to finish this step perfect.
3.Soldering:make the parts fixed by man-made
4.Assembling:each little parts need to assemble by man-made and need to test
5.Aging: To test the products working life and make each product can be used as possible as long time.
Certificates Amost all of our products get CE/CCC etc certificates,and if you have Special requirements of certificates,we can help to apply for you.
Our Company Shenzhen Excellent Top Electronics Co., LTD is an excellent power solution provider, with more than 10 years' experience in R & D and production of power supplies. We are committed to provide the highest quality products and services with the best prices and the most punctual delivery time.
Our products are 100% through high temperature ageing, which accords with CCC, CE, UL and many other authoritative organization security authentication standard. In order to ensure timely delivery, we always keep standard product inventory. If you can't find the right type from our product display or you can't find the right product in the market, please contact us, we will develop satisfactory customized products for you.
