software cheap hmi enclosure panel master touch screen for plc

Feedback Ratings
  • 1-9 Perches
    US $105.00
  • 10-29 Perches
    US $99.99
  • 30-49 Perches
    US $95.00
  • >=50 Perches
    US $90.00
Quantity:
- + Perches available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
2 day(s) after payment received
Customization:
Customized logo (Min. Order: 20 Perches)
Customized packaging (Min. Order: 20 Perches)

More

Graphic customization (Min. Order: 20 Perches)
Supporting to print client's label (Min. Order: 20 Perches) Less
Contact Supplier
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Jiangsu, China (Mainland)
Brand Name:
Mochuan
Model Number:
MC4070C
Size:
7 inch
Touch Panel:
4 wire resistive hmi
Processor:
600MHz ARM
Protection Level:
IP65
Communication Protocol:
Standard Industry Modbus
MOQ:
NO MOQ

Packaging & Delivery

Selling Units:
Single item
Single package size:
21X15X5 cm
Single gross weight:
2.0 kg
Package Type:
Inner plastic box + outer hardness box.7days refund in case of bad quality
Lead Time :
Quantity(Perch) 1 - 1 2 - 20 21 - 50 >50
Est. Time(day) 2 7 10 To be negotiated
Video Description
Pay Attention
Certificate
Test Report No.
SHEM150900340401TXC
Origanization
SGS
Type
HMI-Human Machine Interface
Date & Time
10/25/2015
Test Standard
EN61000-6-4:2007+A1:2001
EN61000-6-2:2005
Certificate for
EMC

Kindly reminder:

All our certifications are REAL ONE.

NOT FAKE, NOT FAKE, NOT FAKE!!!


PLEASE CONTACT US TO SHOW YOU!!!


WORLD-WIDE CUSTOMERS COMMEND & FEEDBACK

Here is some of comments from our world-wide customers.

You can check all the comment at our company profile by www.mochuan.en.alibaba.com-" company profit"-"Rating& Rewiews" Then you can see all comments from our clients.


( Know please, all our customer comments are real one, NOT FAKE.)

TRUST YOU WILL LIKE OUR SERVICE, QUALITY AND PRICE

Alibaba.com suppliers platform show that:

1. We never got any complain.

2. More than 5000 customers contacted us.

3. Star supplier with more than 10000 points.


Our Advantage
Product Description
Item
MC4043C
MC4070C
MC4070CE
MC4070iE
MC4097C
MC4097iE
Programming Software
Mochuan Studio
Compatible OS for Software
WIN7/WIN10/WIN XP
CPU
600MHz ARM Cortex-A8
Touch Screen
4 wires resistive touch screen
Display
Screen Size
4.3'' TFT
7'' TFT LCD
9.7'' TFT LCD
Resolution
480x272
800x480
1024x768
Colors
24-bit colors
Brightness
420cd/m²
360cd/m²
350cd/m²
Backlight Lift
50000 Hours
RTC
Built-in
Storage
Flash
128M
RAM
128m
Ports
SD Card
N/A
Supporting
N/A
Supporting
Ethernet
N/A
10M/100M
N/A
10M/10M
USB Port
USB Host 2.0*1,  USB Device 2.0*1
Download Project
U-Disk/ USB Device
U-Disk/USB Device/
SD Card/Ethernet
USB Host/Device
U-Disk/USB Device/SD card/Ethernet
Serial Port
COM1:RS232/485/422 COM3:RS232
COM1/2:RS232/485/422 COM3/4:RS232
COM1:RS232/RS485/RS422; COM3:RS232
COM1/2:RS232/RS485/RS422; COM3/4:RS232
Power
Power Supply
D24, Input range:DC9V~28V
DC24V, Input Rage DC18~28v
DC24V, Input range DC9v~28v
DC24V, Input range DC18v~28V
Power
<5W
<10W
<10W
Power Down Allowed
<5mS
Dimensions
Vibration Endurance
10-25Hz(X/Y/Z 2G/30Min)
Shell
ABS
Dimension
128x102x32mm
204x145x44.5mm
276x213x39mm
Panel Cutout(W*H)
120x93
192x138mm
259x201mm
Weight(g)
500g
650g
800g
1000g
Environment
Cooling
Natural air cooling
Protection
Front IP65(with NEMA Panel), Back IP20
Temperature
Operating Temperature: 0~50℃;
Storage Temperature: -20~60℃
Humidity
10~90%( No condensation)
Certification
Complied with EN61000-6:2:2005, EN61000-6-4:2007
RoHs
Surge Immuity:±1KV, EFT:±2KV, ESD:4kv, Air:8KV
Programming Software
Above Mochuan Studio v1.0
Feature

Security Management of Project File:

Including decompilation, project file code, and ID. When ID could not match HMI's, project file will not work.

Operating Records:

1.Record all the operating steps, including day, time, content, etc and clearly control fault operation.

2. Could be stored as CSV file to analysis operating records.

3. Could be printed to paper statment.

We still have more on feature. If you want to learn more, please contact us. We will send you.
What&How Mochuan is

With more than 15-years domestic market development since 2002 and around 3-years foreign business  since 2015 .Development, and the sufficential support and cooperate from all our valuable customers.


Mochuan  Drives have been integrated manufacturer and engineering company in PLC, HMI Panel, VFD, IE4 ac 3phase pmsm motor and position sensor. Our one-step service has the honor to serve more than 100 industries in China and more than 200 foreign customers.


Our value message is QUALITY IS OUR CULTURE.

90% of our prodution equipment is imported from Japan and Germany to offer our customers the best competitive advantage PRODUTS.


"With us your MONEY in safe, your BUSINESS in safe".

WELCOME TO BE ONE OF OUR TOP"VIP" CUSTOMERS.

WE BELIEVE THAT " THE QUALITY IS THE SOUL OF AN ENTERPRISE."

Related Products
Hot Promotion


Hot Promotion


1. Buy 20pcs GET 1pcs in FREE.
2. Try one sample to get 10$
3. Support 7Days refund without any CONDITIONS.
4. Refund all the items did not sold out within 6months.

If this type is not you ask, please contact us, We still have more type, whole catalogue and price wait YOU.
Packaging Details
