1/2 NPT G float switch

FOB Reference Price:Get Latest Price
$9.00 - $10.00 / Acres | 10 Acre/Acres (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Zhejiang, China (Mainland)
Brand Name:
SONOR
Model Number:
C14-S
Certification:
CE, LVD, RoHS
Current:
1.5A(220V),0.5A(110V)
Voltage:
220V,110V
Contact form:
NO,NC
Reed Switch:
OKI,MKA,COTO,HAMLIN
water level control:
automatic water level controller
Supply Ability
Supply Ability:
1000 Acre/Acres per Week
Packaging & Delivery
Packaging Details
CARTON
Port
NINGBO SHANGHAI
Lead Time :
in 10days

14 years manufacture experience
Certificated:CE&RoHS
Paypal is OK.



Horizontal Magnetic Float Switch:  water tank level sensor  water tank float level switch



Stainless float switch data: magnetic stainless water leveler control/water level control

Data Scan:

1A1

2A1

Max Contact Rating

10W

50W

Max Switching Voltage

100VDC

220VDC

Max Switching Current

0.5A

1.5A

Mac Breakdown Voltage

220VDC

300VDC

Max Carry Current

1.0A

3.0A

Max Contact Resistance

100mΩ

100mΩ

Temperature Rating

-30~+125℃

-30~+125℃

Float Ball Material

SS304,SS316

SS304,SS316

Float Body Material

SS304,SS316

SS304,SS316

PP float switch data:

Data Scan:

1A

2A

Max Contact Rating:

10W

50W

Max Switching Voltage:

100VDC

220VDC

Max Switching Current:

0.5A

1.5A

Mac Breakdown Voltage:

220VDC

300VDC

Max Carry Current:

1.0A

3.0A

Max Contact Resistance:

100mΩ

100mΩ

Temperature Rating:

-30~+85

-30~+85

Float Ball Material:

P.P

P.P

Float Body Material:

P.P

P.P





Our factory can provide  below 450 ° C Liquid float switch , all kinds of non-standard flanges, different sizes

If the products is not your expecting,please tell me your detail requirements.



Customized Float Switches





Product Description

 Working Systems



float switch  Working principle water tank level sensor  water tank float level switch



When the float ball rises or falls with the liquid to the level of the switch, The magnetic force of magnet which inside of the float

ball will cause the reed switch to turn ON. When the float ball move away from the reed switch, the reed switch will turn OFF.


Vertical Float Switch and Horizontal Magnetic Float Switch installation: Horizontal Magnetic Float Switch/side entry float switch
