1.2mm self-adhesive bitumen flashing tape/flash band

FOB Reference Price:Get Latest Price
  • 3000 - 7999 Square Meters
    $1.20
  • >=8000 Square Meters
    $1.00
Customization:
Customized logo (Min. Order: 500 Square Meters)
Customized packaging (Min. Order: 500 Square Meters)

More

Graphic customization (Min. Order: 500 Square Meters) Less
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Shandong, China (Mainland)
Brand Name:
BOGUAN
Model Number:
self adhesive
Type:
Waterproof Membrane
Width:
from 50mm to 1m
Thickness:
0.8mm-4mm
Packing:
Shrink plastic bag,then Carton
Keyword:
Self adhesive bitumen tape
top surface:
PE Film/Sand/Aluminium Foil/ Mineral
bottom surface:
siliconized release film
Sales mode:
Factory sales directly
Application:
Self adhesive directly
Feature:
Good rubber elasticity and elongation
Supply Ability
Supply Ability:
100000 Square Meter/Square Meters per Month
Packaging & Delivery
Packaging Details
Paper tube inside per roll,Strong seaworthy carton packing or as your special need. Or with the logo you want.
About 10000 sqms per 20'ft container
Port
QINGDAO
Product Description

 Our company adopt the German technology, and the most advanced international formulations suitable for the manufacture of light steel structure waterproof anti-corrosion materials, low cost, higher than the life of the steel structure itself 1-2 times, environmental materials to fill gaps in the domestic steel structure waterproofing,   bitumen waterproof  seal bitumen tape is the best one !



Product description:



bitumen waterproof seal bitumen tape is a kind of polymer modified asphalt materials, using polyester carpet or glass mat for the matrix, the surface covered with polyethylene film, aluminum foil or fine sand, the back is covered with a release sheet,keep the self adhesive modified bitumen flexible and waterproof. The product has a good self-adhesive and bending properties.



Application:



Construction and other base face is simple, clean, and can be widely used in roofing, basement, bathroom, etc. waterproofing works, and for legislation to pave and stick and pipe wall (except heat pipes), bridges , and other complex environment, especially in open flame is prohibited, covert fire waterproofing works.



Product Features:



Self-adhesive modified bitumen membrane with a self-adhesive surface of the waterproofing, sealing material, divided into with base membrane and without base membrane.And one side with self-adhesive layer and two sides with layers two kinds.The self-adhesive layer has covered with release sheept. the material of realease sheet also has a few kinds. all the self-adhesive layers no need glue, just because the adhesive of itself, which is acaused by the modified bitumen. Low-temperature-resistant properties of the product, and the MTR, tunnels and the scene of the fire with the best waterproof, moisture resistance and sealing materials, also apply to pipeline waterproof, anti-corrosion works.



The detailed information:



Thickness: 1mm, 1.2mm, 1.5mm, 2mm, 2.5mm, 3mm, 4mm



Width: 1m or any wide with 1m(that's mean we can cut into any rolls)



Length: 10m, 15m, 20m, 25m



Reinforcement: polyester, fiberglass or without anything





Technical data:



Physical





Thickness(mm)

width(mm)

Area(m2)

1.2

1000

20

1.5

20

2.0

15



Property



The product meets the industry standard JC 840-1999 “self-adhesive plastic bitumen waterproofing membrane”. The requirements to main physical properties are listed in table 2.

Table 2 physical properties

No.





 1

PE

AL

N



2

Water impermeability



Pressure,MPa     ≥

0.2

0.2

0.1



Retention time,min  ≥

120,water impermeable

3

Heat resistance°C

-----

80 No slippage, flowing, dropping.

--



4

Tensile force N/50mm                ≥

130

200





5

Elongation at break,%              ≥

450

200

450



6

Softness

-20°C,Φ20mm,3s,180°C. No crack.

--

7

Shear performance

N/mm

Between membranes ≥

2.0 or fracture on the external agglutination section

fracture on the external agglutination section

Between membrane and aluminum plate ≥

8

Peel strength,N/mm            ≥

1.5 or fracture on the external agglutination section

fracture on the external agglutination section

9

Puncture resistance



water impermeable

10

Aging by artificial climate

Appearance



No crack, no bubble.

---

Tensile force retention percentage,%



80

---

Softness at low temperature,°C



-10°C,Φ20mm,3s,180°C, No crack.

---
