1.5HP Convertible Water Jet Pump for Household Water System

FOB Reference Price:Get Latest Price
US $48-57 / Pieces | 1 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Zhejiang, China (Mainland)
Brand Name:
FLUENT
Model Number:
FGPxxJBD
Theory:
Jet Pump
Structure:
Single-stage Pump
Usage:
Water
Power:
Electric, 600w to 1200w
Standard or Nonstandard:
Standard
Fuel:
Electric
Pressure:
High Pressure
Application:
water jet pump
Name:
1.5HP Convertible Water Jet Pump for Household Water System
Voltage:
230v/50Hz or 110V/60Hz
Max Q Rat:
2800l/h to 3500 l/h
Max H Rat:
35m to 46m
Bar(min~max):
1.2-3.0
Output connector:
1''
Pressure Tank:
19L or 24L
Cable:
H07RN-F 3G1.0mmx1.2m
Color:
Green, Blue or any other color
Supply Ability
Supply Ability:
40000 Piece/Pieces per Month 1.5HP Convertible Water Jet Pump for Household Water System
Packaging & Delivery
Packaging Details
cardboard surrounded and master carton, 1pcs/ctn
1.5HP Convertible Water Jet Pump for Household Water System
Port
NINGBO
Lead Time :
30 days, 1.5HP Convertible Water Jet Pump

1.5HP Convertible Water Jet Pump for Household Water System



Operating Limits:
-Fluid temperature up to 35°C
-Maximum ambient temperature 40°C



Pump's construction:

-Pump body: Plastic or stainless steel

-Impeller: PP/stainless steel

-Motor shaft: 45# Steel or Stainless steel

-Mechanical seal: Ceramic and graphite

-Insulation class: B/F

-Protection Class: IPX4



Idea For:
- Water supply from rain barrels
- Pressure booster, irrigation system
- Installations/ apparatus industry, industrial applications
- Rain water utilisation, filter sytems, lowering of ground water
- WC flushing supply with washwater from wells or tanks



Pump's Application:

- The automatic booster systems consists of a water pump, a membrane tank, a pressure gauge and a pressure switch.

- Garden jet pump can be uses as a boost up household water pressure on clear water, such as gardening, water supply and washing. Stainless steel housing prevented rust and long lasting.

-These pumps should be installed in a covered area, protected against the weather.

-It's always advisable to install a foot valve or non-return valve on the suction opening.



Specification:



Rated Power600W800W1000W1200W
V&Hz230V/50Hz230V/50Hz230V/50Hz230V/50Hz
Max. Flow2800L/H3000L/H3200L/H3500L/H
Max. Height35M40M44M46M
Max. Suction7M8M8M8M
Bar(min~max)1.2-3.01.2-3.01.2-3.01.2-3.0
CertificationsROHS/LVD/GS/CE/EMC
Dia. Of Pipe1"1"1"1"
CableH05RNF3G
1.0mm2x1.2m
H05RNF3G
1.0mm2x1.2m
H05RNF3G
1.0mm2x1.2m
H05RNF3G
1.0mm2x1.2m

 110V/60Hz is also available
