100dB 105dB Diameter 42mm Wire Active Car Piezo Buzzer 12v 24v

FOB Reference Price:Get Latest Price
$0.42 - $1.00 / Pieces | 1 Piece/Pieces (Min. Order)
Lead Time:
Quantity(Pieces) 1 - 500 501 - 5000 >5000
Est. Time(days) 12 21 Negotiable
Samples - $0.60 /Pieces, 1 Pieces (Min. Order): Buy Samples
Loading...
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Jiangsu, China (Mainland)
Brand Name:
MANORSHI
Model Number:
MSPS42A
Type:
Buzzer
Product name:
automobile buzzer
Rated Voltage:
12V
Current:
10mA
Color:
Black
terminal:
wire
Dimension:
42MM
SPL:
100DB/105dB
Frequency:
2800Hz
Application:
widely
Material:
ABS
Packaging & Delivery
Picture Example:
package-img
Lead Time :
Quantity(Pieces) 1 - 500 501 - 5000 >5000
Est. Time(days) 12 21 To be negotiated
Video Description
Product Description
TYPE
MSPS42A28W12
MSPS42A31W24
Sound pressure Level
105dB Min. at 12Vdc/10cm
100dB Min. at 12Vdc/10cm
Resonant Frequency
2.8±0.5kHz
3.1±0.5kHz
Rated current
10mA Max.
20mA Max.
Rated Voltage
12.0Vdc
24.0Vdc
Operating Voltage
3 – 20Vdc
18 – 30Vdc
Operation Temperature
-20C - +85C
-20C - +85C
Lead Wires
UL1007, AWG28
UL1007, AWG28
Housing Material
ABS
ABS
Dimensions(mm)
See the Drawing
See the Drawing
Weight
15g
15g
Packing & Delivery
Series Products

BUZZER SERIES

SPEAKER SERIES

ULTRASONIC SENSOR SERIES


Customer Feedback
About US




Strict quality control and Advanced testing equipment.

 Full QC inspection process performed from incoming raw materials to  final shipment.




Automated production line to improve production capacity.




Professional sales team, Your new inquiry and questions will get our immediately reply.

FAQ
1.What's your MOQ?
MOQ depends on different series of products, pls contact with us.
2.Do you support OEM and ODM services?
Yes, we can customize products according to the drawing.
3.How about freight fee?
We cooperate with different express companies, enjoy the lowest discount.
4.Do you support after sales service?
The professional after-sales service team will solve all problems for you.
