100w 48v dc power supply

Feedback Ratings
  • 1-99 Pieces
    $14.50
  • >=100 Pieces
    $14.30
Quantity:
- + Pieces available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
7 day(s) after payment received
Customization:
Customized logo (Min. Order: 1000 Pieces)
Customized packaging (Min. Order: 1000 Pieces)

More

Graphic customization (Min. Order: 1000 Pieces) Less
Contact Supplier
Samples - $14.50 /Piece, 1 Piece (Min. Order): Buy Samples
Loading... Add To Cart
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Jiangsu, China (Mainland)
Brand Name:
VL
Model Number:
VL100-5
Output Power:
100W
Output Type:
Single
Input Voltage:
90-265VAC/120-370VDC
Output Voltage:
48V
Output Frequency:
50-60Hz
Output Current:
2.3A
OEM:
Yes
Approval:
CE
size(mm):
106*97*30
weight:
500g
warranty:
3years

Packaging & Delivery

Selling Units:
Single item
Single package size:
11X10X3 cm
Single gross weight:
0.55 kg
Package Type:
carton
Picture Example:
package-img
Lead Time :
Quantity(Piece) 1 - 10 >10
Est. Time(days) 7 To be negotiated
Product Description

Features:

Universal Input Voltage range

Metal enclosed power supply

Protected against Over Current & Over Voltage faults

Adjustable Output Voltage

Uses Double-sided pcb to reinforce reliability

UL approved & certified (PENDING)

3 Years Warranty (@Input AC230V, Full Load, 8 hours usage per day)

Safty Standards
UL IEC 62368
CE LVD ROHS-2
Insulation Strength
Withstand In-Out 3.6kVac 1min
In-FG 2kVac 1min
EMI Comply to
EN-55022 ClassB
EMS Immune to
EN61000-4-2,4,5,11
EN61000-3-2 ClassA
Environment
Storage Environment
-40~85℃,10~95% RH
Operating Environment
-30~70℃(See Derting Curve-TBD),20~90% RH
Vibration
10-55Hz, 2G 1min/cycle, 1hr each x,y,z axis
Operating Altitude
3000m max
Temperature Coefficient
0.03%/℃
Size(L*W*H)
106*97*30mm
Certifications
Detailed Images
Item Model
VL100-5
VL100-12
VL100-24
VL100-48
Input
Input Rated Voltage
100-240Vac
Input Voltage Range
90-265Vac/120-375Vdc
Input Rated Frequency
50-60Hz
Input Frequency Range
47-63Hz
Input Current(max)
2.05A
Inrush Current(max)
50A@Cold Start & Input 230V
Leakage Current(max)
0.75mA@Input 240Vac
No Load Input Power(max)
0.5W
Efficiency
85%
87%
89%
90%
Output
Output Rated Voltage
5V
12V
24V
48V
Output Voltage Range(adjustable)
±10%
±15%
±20%
±10%
Output Rated Current
20A
8.5A
4.5A
2.3A
Output Min Current
0A
0A
0A
0A
Output Rated Power
100W
102W
105W
108W
Output Ripple & Noise p-p
100mV
120mV
150mV
200mV
Load Regulation
1.50%
1.50%
1.50%
1.50%
Line Regulation
0.50%
0.50%
0.50%
0.50%
Riseup Delay
600ms
Holdup Time
30/12ms 115/230Vac
OCP(trigger range)
>110% of Output Rated Current
OVP(trigger range)
>5.5
>13.8
>28.8
>55.2
Our Service

Pre-Sales Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.

After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.

Packing & Delivery
Packaging
Size
106(L) * 97 (W) * 30 (D)
Weight
0.5KG



Packaging Details
The normal package is carton.
