With plastic paper firstly then outside by iron frame (Export standard packaging)
1.Sound production management and Reliable sea forwarder for many years guarantee the timely delivery.
2.Experienced package guarantee the quality of equipment and ensure customers' satisfying.
Packing details: packing with steel stainless and wood cases, standard export package
Delivery details: delivery time within 35 days from Qingdao.
10hl/10bbl complete beer brewery equipment
Jinan Humber Equipment Technology Co.,Ltd. was established in 2009.Company has won the "China excellent science and technology innovation enterprise" "quality qualified product of national definitive testing" and "quality credit AAA enterprise”, etc...The company passed the ISO9001:2000 international quality management system certification, CE certification, DI, DII pressure vessel certification, 15 patents. We produce 50L, 60L, 100L, 200L, 500L, 1000L, 2000L, 5000L, 10000L, 1bbl, 5bbl, 10bbl, 20bbl, 30bbl, 50bbl and more bigger complete beer brewery equipment and exported all over the world the word.
10hl/10bbl complete beer brewing equipment maily consists of malt milling system, brewhouse, fermenting system, cooling system, CIP system, and controlling system and other auxiliary system.
Malt milling system:
Function: Use for grain crushing.
If you need 10hl/10bbl complete beer brewing equipment, then Crushing ability of miller is 300~500kg/h for option, the material is Carbon steel ,and rollers material is Alloy. Double roller, and rollers distance can be adjustment very easily, the faster roller speed:700RPM. This is machine can remove the iron and dust by automatically, and low noise.
2-vessels: Mash tun/lauter tank, brew kettle/whirlpool tank
Lower cost; easy operate; Wort will burn easilier;
Heat evenly and stable; it’s good for the beer taste; but need to buy extra steam boiler.
It is difficult to control the temperature; unsafe, easy to scorch the wort.
Round stainless steel manhole with sight glass
False bottom (lauter tank)
Laser cutting T-wire false bottom, stronger enough and help you get clear wort.
PID digital display controller: show brewhouse temperature, control all motors & pumps; PLC touch screen: Step heating is automatically, all motors/pumps operated on the panel; Remote control by computer or mobile;
Anti-explosion motors With speed controller
Necessary:Work platform,Heat exchanger, Yeast adding tank
Optional: Hot water tank(hot water pump), Cold water tank,Hops adding tank.
With complete set accessories, such as thermo detector, ball valve, Aeration device, liquid level, Saccharimeter, and so on.
Regarding the cooling system of brewery, normally we will equip glycol water tank, chillers, and pumps, used for wort cooling and all fermenters / BBT / lagers cooling
It include Disinfection tank, Alkali tank,CIP pump.
If you want to need large equipment, we can offer 3 tanks Acidic tank and Alkai tank and Disinfection tank
This system is used to clean the whole beer brewery euipment.
The motor of the pump is ABB, it is imported from Switzerland.
Function: Use for brewery controlling.
1.)It shows the temperature of the mash/lauter, boiling/whirlpool/hot water tank/glycol tank’s temperature.
2.) the mash tun step heating is automatic, and it controls all the pumps and motor and others.
3.)And step heating during mashing in mash tun, mashing process is saved automatically, you can lead-in and lead-out. It with fault monitoring alarm and timer. PLC controller, adopt Siemens brand. All fermenters temperature can be controlled.
1. All tanks will be packaged with soft protection material and mounted on strong carbon steel frame 2. All accessories and spare parts will be packaged with separate box. 3. After loaded into containers, all equipments will be well fixed to the containers.
Shipping container: FCL(20'GP, 40'GP, 40'HQ). 5.Transportation mode: ocean, railway or air transportation.
1. Free of charge the consultation service before, during, and after sales .
Your questions would be replied within 24 hours by our sales team.
2.There are professional engineers and technicians in our company, so we can customize the equipment, and we can provide beer production technology and brewing formula, equipment design, installation and debugging, and personnel training service;
3.Providing 3D and CAD layout drawing within 5working days after get buyer’s building plan.
4. Provide 5years complete warrantee for tanks body and life-time maintenance service; All of the accessories and auxuliaries facilities are guaranteed for one year; The seller is responsible for the nature damage of the machinery in the warranty period except for man-made damage. All spare parts and wearing parts are included with the brewery for free.
1. Q: Are you manufacturer or trading company? A: We are a professional manufacturer. 2. Q: Where is your factory located? A: Our factory is located in Erhuang East Road, Licheng District, Jinan, Shandong, China, 2 hours to Beijing. 3. Q: How could we confirm the details of the products? A: We will provide all the drawings for you to confirm. 4: Q: How long the warranty will be? A: 5 years warranty for the main beer brewery equipment, 1 year for the accessories and auxiliaries. 5. Q: How about the installation? And what if the machine goes down A: Yes, we will do that. There are two optionsa. We could appoint our engineer to your company to debug and repair, as for the cost of this trip such as ticket, visa, accommodation and labor cost shall be on your side.b. On-line service will be provided. If still under guarantee period, the necessary accessories and parts will be provided free, but the transportation cost of it shall be on you side.
