120W 220v to 18v voltage converter 12V 24V 36V 48V universal power supply

FOB Reference Price:Get Latest Price
$1.00 - $10.00 / Pieces | 1 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
ETOP
Model Number:
LPS-U121SXXL
Output Power:
101 - 200W
Output Type:
Single
Input Voltage:
100-240VAC
Output Voltage:
12Vdc 18V 24V 36V 48V
Output Frequency:
47-63Hz
Output Current:
10A 5A 7.5A 2A 3A
Dimession:
103*64.5*34.5MM
Power:
120w
Efficiency:
80%
Protection:
OVP OCP OTP SCP
Working tem.:
0~+40 degree
Material:
FR4 pcb ,RoHS plating, 105 degree long life capacitors
Weight:
0.2Kg
Application:
LCD CCTV,HDDBOX, DVR,LED-TV, MiNi sound box, Robot cleaner,
Certification:
CE ROHS
Product Name:
120W SMPS 24V 5A DC Power Supply 12V 10A Circuit
Supply Ability
Supply Ability:
100000 Piece/Pieces per Month 120W SMPS 24V 5A DC Power Supply 12V 10A Circuit For LCD & State
Packaging & Delivery
Packaging Details
PP bag, small carton box and standard carton box(refer to the detail about the package at product detail description)120W SMPS 24V 5A DC Power Supply 12V 10A Circuit For LCD & State Lighting
Port
Shenzhen
Product Description
120W 110v ac to 24v dc 5A tv power supply module 12v 28v 36v 48v


Features:

1.Universal AC input/full range;

2.100% full load burn-in testing;

3.LED indicator for power on;

4.Constant voltage type;

5.Fully enclosed plastic case;

6. No load consumption < 5W;

7. Class I power(with earth pin);

8. Three pole IEC320-C14 communication interface.


Parameters:

Model
Output
Ripple&Noise
Tolerance
    Line Regulation
    Load Regulation
Efficiency
LPS-U121S12L
12V/10A
200mvp-p
5%
1%
5%
80%
LPS-U121S24L
24V/5A
240mvp-p
5%
1%
3%
87%
LPS-U121S48L
48V/2.5A
480mvp-p
5%
1%
3%
88%
LPS-U121S20L
20V/7.5A
240mvp-p
5%
1%
3%
86%
LPS-U121S24L
24V/6.25A
240mvp-p
5%
1%
3%
80%
LPS-U121S48L
48V/3.12A
480mvp-p
5%
1%
3%
88%
Power
120w
Input Volt & Freq
100-240vac  47-63hz
Start ,Rise time
2000ms,30ms/230vac,3000ms,30ms/115vac  full load
Working enviroment
0~40 degree ,20~90% RH non considering
Temperature coefficient
0.03%
Protection
Over load     >105%-150%,hiccup mode auto recovery
Over voltage >115%-135%,hiccup mode auto recovery
Over temp
EMC Standard
EN55022,ClassB, EN61000-3-2,EN61000-4-2,3.4,5.6,8.11
Safety Standard
EN60950-1,CCC,GB4943,J60950
Withstand voltage
I/P-O/P:1.5KVAC    I/P-PG:1.5KVAC
Leakage current
0.75mA/240vac
Dimesion
103*64.5*34.5mm
