15HP 11KW 8bar Combined Screw Air Compressor Include Air Tank and Air Dryer

FOB Reference Price:Get Latest Price
$2,800.00 - $4,000.00 / Unit | 1.0 Unit/Units (Min. Order)
Power(W):
11 KW
Lead Time:
Quantity(Units) 1 - 1 2 - 3 >3
Est. Time(days) 15 45 Negotiable
Customization:
Customized logo (Min. Order: 1 Units)
Customized packaging (Min. Order: 1 Units)

More

Graphic customization (Min. Order: 1 Units) Less
Report Suspicious Activity
Overview
Quick Details
Condition:
New, New
Applicable Industries:
Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Construction works , Energy & Mining
After Warranty Service:
Video technical support
Local Service Location:
Egypt, Viet Nam, Brazil, Indonesia, Pakistan, India, Russia, Thailand, Malaysia, Australia, South Africa
Showroom Location:
Egypt, Viet Nam, Brazil, Indonesia, Pakistan, India, Russia, Thailand, South Africa, Malaysia, Australia
Type:
Screw
Configuration:
Stationary
Power Source:
AC Power
Lubrication Style:
Lubricated
Mute:
Yes
Place of Origin:
Shanghai, China
Brand Name:
ELANG
Voltage:
380v/3ph/50hz(or Customized)
Dimension(L*W*H):
1955*800*1800mm
Weight:
785kg
Certification:
ISO9001 CE TUV SGS ASME
Warranty:
1 YEAR
After-sales Service Provided:
Field maintenance and repair service
Working Pressure:
7 bar, 8 bar, 13 bar, 10 bar, 7-13bar
Air capacity:
1.3 - 1.8 m3/min
Machinery Test Report:
Provided
Video outgoing-inspection:
Provided
Marketing Type:
Ordinary Product
Warranty of core components:
1.5 years
Core Components:
engine, pump
Product Name:
15HP 11KW 8bar Combined Screw Air Compressor
Driven Method:
Belt Driven
OEM:
Offered/Accepted
Cooling Method:
Air cooling/Water cooling
Application:
Packing Industrial Air Compressor
Motor Cooling:
IC44
Motor Power:
11kw15HP
Insulation Class:
F
Capacity:
1.8m3/min(63.6cfm)
Product Certification certification
TUV Certified.
Supply Ability
Supply Ability:
300 Set/Sets per Month 15HP 11KW 8bar Combined Screw Air Compressor Include Air Tank an
Packaging & Delivery
Packaging Details
Standard exporting packing for 15HP 11KW 8bar Combined Screw Air Compressor Include Air Tank and Air Dryer.
Port
Shanghai, any port in China
Picture Example:
package-img
package-img
Lead Time :
Quantity(Units) 1 - 1 2 - 3 >3
Est. Time(days) 15 45 To be negotiated
Video Description
Product Description

15HP 11KW 8bar Combined Screw Air Compressor Include Air Tank and Air Dryer

Elang belt driving screw air compressor is mainly used in general industry such as oil &gas,shipyard,coating,blow molding,laser cutting,furniture,plastics,rubber,color sorter machine,painting etc.

Item Name
air compressor,air dryer,air tank,fine filter/OEM
Air Compressor Series
ERC10SA,ERC15SA,ERC20SA,ERC25SA,ERC30SA
Air Delivery
0.7m3/min-1.3m3/min, 24.7cfm-134.2cfm
Minimum Order Quantity (MOQ)
1set


Material Details
1.You can choose ABB intelligent control.
2.PLC touch screen,0-100% stepless adjustment air inlet valve.
3.ELANG/Aerzen/GHH air end.
4.High efficiency motor for IP54/IP55 and insulution class F,ABB/siemens motor for choose.
Certification
ISO9001 CE TUV UL SGS ASME
Quality Guarantee Period
1year
Voltage
110V - 660V 50Hz/60Hz 3ph,Support one machine for two voltages
Delivery Time
Shipped in 25 days after payment

Our service
1.No matter when or where,24 hours service for you
2.We have agents in many countries.If you need , we can provide you with technical support.

Highly-quality shaft coupling elastic body can buffer and compensate for the imbalanced moment of operation. The elastomer is designed into and involute cambered surface, which effectively avoids stress concentration and improve the buffering effect of the elastomer to increase its bearing capacity. In addition, the high-quality materials ensure excellent durability for the elastomer and can better absorb the vibration arising from the rotation to remove noise. Since no wearing parts are used for the double-screw compressor air end, it can operate for up to 40000-80000 hours between failure if well maintained.

Main Features

1.Large displacement:
Displacement 10% higher than ordinary piston compressor.
2. Energy-saving:
Compared with piston air compressor, this series of models for the new national standard two energy efficiency products, excellent energy saving.
3. Easy to operate:
24 hours unattended all day work, free load automatically start, full load automatically shut down.
4. Strong stability:
Under long time working, displacement and pressure stable, no crash phenomenon, low failure rate.

Technical Data:

Model
                                                                  ERC-15SA Combined
Working Pressure
psig
100
116
145
181
bar
7
8
10
12.5
Air Delivery
cfm
63.6
58.3
53
45.9
m3/min
1.8
1.65
1.5
1.3
Motor Power
kw/hp
11/15
Motor Efficiency
Class
Ultraefficient/IE3/IE2 as per your required
Motor Protection Class
IP23/IP54/IP55 or as per your required
Type of Driving
Belt Driven
Type of Cooling
Air Cooling/Water cooling

Dimension(mm)
L
1955
W
800
H
1800
Weight
kg
785
Caliber
1"
Volume of Receiver
m3
0.5
Model of Drier
ELH-15A
Treatment Capacity
m3/min
2.4
Model of Precision Filter
END024
Certification
CE/ISO9001:2015/TUV/UL/SGS/ASME
Voltage
380V/3PH/50HZ/60HZ
220V/3PH/50HZ/60HZ
440V/3PH/50HZ/60HZ
415V/3PH/50HZ/60HZ
Dual voltage is also ok
Exhaust Oil Volum
<3ppm
Noise
db
72±5 test according the national standard GB/T4980-2003
Outlet Air Humidity
ambient temperature+15℃
Cooling Air Volume
m3/min
50
Cooling Water Volume
L/min
14.5
Related Products

       VSD air compressor

100% Response Rate

       Oil free air compressor

100% Response Rate

     Low pressure air compressor

100% Response Rate

 Hot Products

Direct driven compressor                 Diesel air compressor              Two-stage air compressor                 Servo air compressor

Certifications
Our Company

ELANG group is located in Nanxiang Industrial Development Zone, Jiading District, Shanghai, which is the hightech enterprises in Shanghai and China's quality service integrity AAAclass corporation. As one of the world's largest air compressor system suppliers, ELANG currently develops all the Rotary Screw Air Compressors.
German standard, Made in ELANG. As the industry's leading technology enterprise, ELANG has always being focused on the talent cultivation and quality pursuit. We have a good batch of talent team with solid foundation of air dynamics and always active in mechanical application and technology R&D, that make ELANG achieved unparalleled advantages in the technology R&D and product innovation and customized etc.

Behind such a huge system, it is ELANG people constant persist. Choose ELANG, without worry for fifty years. ELANG give 10 years quality guaranty concept for its sold products, 24-hour after-sales service, full-way after-salestracking and lifelong maintenance.

ELANG Company with Germany Standard and 10 years exporting experience help us won more than 50

loyal foreign agents, worldwide agents guarantee installation, after service maintenance available in time,
our sales department 24hours on-line service, also welltrained engineers available to overseas service.
So whenever you have any question about air compressor, please don't hesitate to contact us.

Quality Control
Packing & Delivery
Our Customes
FAQ

Q1: Why customer choose us?
A: ELANG INDUSTRIAL (SHANGHAI) CO., LTD., with 18 years old history, we are specialized in Rotary Screw Air Compressor. Germany Standard and 10years exporting experience help us won more than 50 loyal foreign agents. We warmly welcome your small trial order for quality or market test.

Q2: Are you a manufacturer or trading company?
A: We are professional manufacturer with big modern factory in Shanghai,China. Both OEM & ODM service can be accepted.

Q3: What's your delivery time?

A: Generally 3 to 7 days, if urgently order, pls contact our sales in advance.

Q4: How long is your air compressor warranty?
A: One year for the whole machine and two years for screw air end, except consumble spare parts.

Q5: How long could your air compressor be used?
A: Generally, more than 10 years.

Q6: What's payment term?
A: T/T, L/C, D/P, Western Union, Paypal, Credit Card, and etc. Also we could accept USD, RMB, Euro and other currency.

Q7: How about your customer service?
A: 24 hours on-line service available. 48hours problem sovled promise.

Q8: How about your after-sales service?
A: 1. Provide customers with intallation and commissioning online instructions.
2. Well-trained engineers available to overseas service.
3. Worldwide agents and after service avaiable
